Description
3.2.1
Connectors
Fig. 2
No
1
2
3
4
®
Anybus
CompactCom Starter Kit Reference Guide
2
1
1
2
Description
Power switch
Power connector (24 V)
1:
24 V
2:
GND
RS232 connector
USB2 connector
3
4
8 (20)
HMSI-27-224 2.0
