Eaton 5PX EBM 72V RT2U Installation Manual

Eaton 5PX EBM 72V RT2U Installation Manual

Extended battery module

Advertisement

www.powerquality.eaton.com
1 x EBM
Weights (kg/lb) Dimensions (mm/inch)
72.30 / 32.80
5PX EBM 48V RT2U
5PX EBM 72V RT2U
102.3 / 46.39
5PX EBM 72V RT3U
97.6 / 44.26
The connected power cord between UPS and EBM must be provided by original manufacturer,
but not other manufacturers.
D
H
W
5PX EBM 72V (2U/3U)
Compatible with 5PX 3000 (2U/3U)
2 x EBM
D x W x H
20.6 x 17.4 x 3.4 / 522 x 441.2 x 86.2
25.5 x 17.4 x 3.4 / 647 x 441.2 x 86.2
19.6 x 17.4 x 5.1 / 497 x 441.2 x 130.7
D
H
W
5PX EBM 48V
Compatible with 5PX 1000/1500/2000/2200
EATON 5PX EBM
Installation manual
Manuel d'installation
614-21119-01
