- Page 1 5PX 1500i RT2U 5PX 2000i RT2U 5PX 2200i RT2U 5PX 3000i RT2U 5PX 3000i RT3U 5PX EBM 48V RT2U 5PX EBM 72V RT2U 5PX EBM 72V RT3U Installation and user manual Copyright © 2010 EATON All rights reserved. Service and support:...
-
Page 2: Special Symbols
Flickers emission: IEC 61000-3-3 edition 2: 2008 The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC Declaration of Conformity, contact Eaton Power Quality or check Eaton website: www.powerquality.eaton.com Special Symbols... -
Page 3: Table Of Contents
Contents 1. Introduction ..................4 1.1 Environmental protection....................4 2. Presentation ..................5 2.1 Standard positions ......................5 2.2 Rear Panels ........................6 2.3 Control panel ........................7 2.4 LCD description .......................8 2.5 Display functions ......................9 2.6 User settings ........................9 3. Installation ..................11 3.1 Unpacking and contents check ..................11 3.2 Installation in tower position .................. -
Page 4: Introduction
Before installing 5PX, please read the booklet presenting the safety instructions. Then follow the indications in this manual. To discover the entire range of EATON products and the options available for the 5PX range, we invite you to visit our web site at www.eaton.com or contact your EATON representative. -
Page 5: Presentation
Tower position Rack position Description Weights (kg/lb) Dimensions (mm/inch) D x W x H 5PX 1500i RT2U 27.60 / 60.90 522 x 441.2 x 86.2 / 20.6 x 17.4 x 3.4 5PX 2000i RT2U 28.50 / 62.80 5PX 2200i RT2U 28.50 / 62.80... -
Page 6: Rear Panels
2. Presentation 2.2 Rear Panels 5PX 1500i / 2000i (1) USB communication port (2) RS232 communication port (3) Connector for automatic recognition of optional battery modules (4) Slot for optional communication card (5) Connector for ROO (remote ON/OFF) or RPO (Remote Power Off) control (6) Connector for optional battery modules (7) 16 A outlet for connection of... -
Page 7: Control Panel
2. Presentation 2.3 Control panel The UPS has a five-button graphical LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. Power On On battery Alarm Indicator (green) Indicator (yellow) Indicator (red) Normal mode 100% 100% 2.7kW 17min... -
Page 8: Lcd Description
2. Presentation 2.4 LCD description As default, or after 5 minutes of inactivity, the LCD displays the screen saver. The backlight LCD automatically dims after 10 minutes of inactivity. Press any button to restore the screen. Operation status Normal mode 100% 100% Load/equipment status... -
Page 9: Display Functions
2. Presentation 2.5 Display functions Press the Enter ( ) button to activate the menu options. Use the two middle buttons ( ) to scroll through the menu structure. Press the Enter ( ) button to select an option. Press the button to cancel or return to the previous menu. - Page 10 2. Presentation Description Available settings Default settings Load segments [Disable] [0s] [1 s] [2 s]…[65354 s] Group 1: Disable - Auto shutdown During a power outage, authorises Group 2: Disable delay to keep some equipment running while turning off other equipment. This feature allows to save battery power.
-
Page 11: Installation
3. Installation 3.1 Unpacking and contents check (30) 5PX UPS Elements supplied depending on the version or optional (31) connection cable to AC-power source (5PX 2200 and 3000 models only) (41) 2 supports for tower position (RT 2U version only) (32) 2 connection cables for the protected equipment (42) FlexPDU module (optional) -
Page 12: Installation In Tower Position
Note. The two supports for the tower position are used on the RT 2U version only. 3.3 Installation in rack position Follow steps 1 to 4 for module mounting on the rails. The rails and necessary hardware are supplied by EATON. Page 12 614-07977-00_EN... -
Page 13: Communication Ports
(34) to the USB (1) or RS232 (2) communication port on the UPS. The UPS can now communicate with EATON power management software. Installation of the communication cards (optional, standard on the Netpack versions) It is not necessary to shutdown the UPS before installing a communication card. -
Page 14: Connection With A Flexpdu (Power Distribution Unit) Module (Optional)
3. Installation 3.5 Connection with a FlexPDU (Power Distribution Unit) module (optional) 1. 5PX 2200i / 3000i: connect the UPS input socket (10) to the AC-power source using the cable (31) supplied. 5PX 1500i / 2000i: use the power cable of the protected equipment. 2. -
Page 15: Ups Connection Without A Flexpdu Or Hotswap Mbp Module
3. Installation HotSwap MBP module operation The HotSwap MBP module has a rotary switch (55) with two positions: Normal the load is supplied by the UPS, LED (53) is on. Bypass the load is supplied directly by the AC-power source. LED (54) is on. -
Page 16: Operation
4.1 Start-up and Normal operation To start the UPS: 1. Verify that the UPS power cord is plugged in. 2. The UPS front panel display illuminates and shows EATON logo. 3. Verify that the UPS status screen shows 4. Press the button on the UPS front panel for at least 2 seconds. -
Page 17: Return Of Ac Input Power
4. Operation Low-battery warning indicator illuminates solid. The audio alarm beeps every three seconds. The remaining battery power is low. Shut down all applications on the connected equipment because automatic UPS shutdown is imminent. End of battery backup time LCD displays "End of backup time". All the LEDs go OFF . -
Page 18: Maintenance
5. Maintenance 5.1 Troubleshooting Operation status Possible cause Action Batteries disconnected The UPS does not recognise If the condition persists, contact the internal batteries your service representative The batteries are disconnected Verify that all batteries are properly connected. If the condition persists, contact your service representative. -
Page 19: Battery-Module Replacement
5. Maintenance 5.2 Battery-module replacement Safety recommendations The battery can cause electrocution and high short-circuit currents. The following safety precautions are required before servicing the battery components: remove watches, rings, bracelets and all other metal objects from the hands and arms, use tools with an insulated handle. -
Page 20: Maintenance On A Ups Equipped With The Hotswap Mbp Module
Mounting the new battery module Carry out the above instructions in reverse order. To ensure safety and high performance, use only batteries supplied by EATON. Take care to firmly press together the two parts of the connector during remounting. 5.3 Maintenance on a UPS equipped with the HotSwap MBP module... -
Page 21: Appendices
6. Appendices 6.1 Technical specifications Transformer Filter "AVR" Charger Inverter Battery 5PX 1500i RT2U 5PX 2000i RT2U 5PX 2200i RT2U 5PX 3000i RT2U 5PX 3000i RT3U Output Power 1500 VA 2000 VA 2200 VA 3000 VA 3000 VA 1350 W... -
Page 22: Glossary
6. Appendices 6.2 Glossary Backup time Time during which the load can be supplied by the UPS operating on battery power. Battery test Internal UPS test to check battery status. Cold start The devices connected to the UPS can be started even if AC input power is not available.
