EMV1200 FHD / EMV800 FHD
12CH/8CH Hybrid Mobile DVR
Quick Installation Guide
Copyright © EverFocus Electronics Corp.
Release Date: May, 2018
All the images including product pictures or screen shots in this document are for example only.
The images may vary depending on the product and software version. Information contained in
this document is subject to change without notice.
Advertisement
Table of Contents
Related Manuals for EverFocus EMV1200 FHD
Summary of Contents for EverFocus EMV1200 FHD
-
Page 1: Quick Installation Guide
EMV1200 FHD / EMV800 FHD 12CH/8CH Hybrid Mobile DVR Quick Installation Guide Copyright © EverFocus Electronics Corp. Release Date: May, 2018 All the images including product pictures or screen shots in this document are for example only. The images may vary depending on the product and software version. Information contained in... -
Page 2: Minimum System Requirements
The EMV800 FHD / EMV1200 FHD can support both of analog (AHD/TVI/SD) and IP cameras, delivering up to 1080p (analog) and up to 4MP (IP) image quality. -
Page 3: Packing List
• IR Remote Control (with two AAA batteries. See Note 4) x 1 • Power Harness Cable x 1 • Video Cable x 3 (EMV1200 FHD); x2 (EMV800 FHD) (see 3.2 Video Cable / Power-Out Cable) • Audio Cable x 1 (see 3.3 Audio Cable) •... -
Page 4: Front Panel
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR Front Panel EMV800 FHD / EMV1200 FHD No. Name Description Lock to power on the HDD. After locking the HDD Tray Lock (No.2), lock the HDD Power Lock to power on the HDD. The HDD power indicator will light in blue to indicate the HDD power is on. -
Page 5: Rear Panel
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR • Alarm: Turns on when the connected alarm I/O is triggered; turns off when the alarm I/O stops being triggered. • GPS: Turns on continuously when the mobile DVR is receiving GPS data. - Page 6 EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR No. Name Description By default, this port is set to a Main monitor output. Connects to a Main monitor using a VGA cable. Main Monitor Note: You can optionally switch this port from Main monitor to (VGA) Call monitor.
-
Page 7: Getting Started
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR Getting Started 2.1 Installation Before installation, choose a location in the vehicle where it can: • Provide convenient access for installing or removing the hard disk • Allow air to flow around the fan vents. Inadequate or improper air flow can impede proper... -
Page 8: Hard Disk Installation
This would protect and extend the operating life of the hard disk. 2. Please go to the EMV800 FHD / EMV1200 FHD Web page on our website http://www.everfocus.com.tw to see the latest Storage Compatibility List. It’s recommended to use the HDD/SSD models listed in the Storage Compatibility List to ensure your storage will be compatible. - Page 9 EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 1. Make sure the mobile DVR is powered-off. Unlock the HDD Power Lock using the supplied HDD Power Lock Key. Use the supplied HDD Tray Lock Key to unlock the HDD Tray.
-
Page 10: Sd Card Installation
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 5. Insert the HDD Tray into the drive bay and close the Locking Arm until you hear a click. 6. Lock the HDD Tray Lock and HDD Power Lock before you power on the mobile DVR. - Page 11 EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR The Mobile DVR will automatically detect when a new SD card has been inserted and the below SD card format message will pop-up. Click Yes to format the SD card. The formatting process will take about 30 ~ 60 seconds.
-
Page 12: Basic Connection
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR Basic Connection After installing the mobile DVR in the vehicle, you can start connecting the mobile DVR to the external devices. The instructions below describe the basic connection to the mobile DVRs. -
Page 13: Power Harness Cable
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 2.4 Power Harness Cable You can connect the mobile DVR to a power source between 9 VDC ~ 36 VDC. (The following figure uses EMV1200 FHD as an example). EMV1200 FHD (Rear Panel) 9-12 CH... -
Page 14: Video Cable / Power-Out Cable
You can use the supplied Video Cables to connect the analog cameras to the MDVR. EMV800 FHD has 2 Video In Ports for connecting to 8 analog cameras; while EMV1200 FHD has 3 Video In Ports for connecting to 12 analog cameras. -
Page 15: Audio Cable
Audio Cable. The Audio Cable is labeled with AIN 1~ AIN 12. Please be noted that Microphones with a (built-in) amplifier and external power supply are required. The following figure uses EMV1200 FHD as an example. The EMV1200 FHD provides 12 audio inputs; while the EMV800 FHD provides 8 audio inputs. - Page 16 RS-485_B (-) Note: 1. If you want to connect OBDII or CAN bus, please use RS-232 #1 (D-Sub connector). The OBDII and CAN bus should be the EverFocus approved ones. Please contact EverFocus for more details. ts@everfocus.com.tw 2. For TPMS connection, please use RS-232 #2 (PIN19/PIN20).
-
Page 17: Ethernet Cable
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 2.8 Ethernet Cable The Ethernet Port (M12) on the rear panel can be used to connect to LAN network for connecting to IP cameras. Pin Assignment M12-4P MDI0- MDI1+ MDI0+ MDI1- 2.9 USB Cable... -
Page 18: Monitor Connection
The two call monitor outputs provide the identical functionality. Make sure that the connected monitor's specifications comply with these resolution requirements. (This figure uses EMV1200 FHD mobile DVR as an example). Front Panel Rear Panel... -
Page 19: Turning On/Off The Power
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 2.12 Turning On / Off the Power Before powering on the mobile DVR, please make sure the internal HDD have been installed properly. Once you have completed the basic cable connections, you are ready to turn on the mobile DVR. -
Page 20: Vehicle Connection
DVR in all kinds of vehicles support the above power voltage. The diagrams below are examples to illustrate the connection inside a car / truck with 12VDC / 24VDC. * The following figures are using EMV1200 FHD for example; the differences between the two models are the numbers of video input and audio input. -
Page 21: Connecting To A Car With 12Vdc
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 3.2 Connecting to a Car with 12VDC Glove box (inside or underneath) Trunk Passenger seat (underneath) Driver seat (between the seat and side panel) EMV1200 FHD (Rear Panel) 9-12 CH Power Harness Cable... -
Page 22: Accessing The Mobile Dvr
EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR 4. Accessing the Mobile DVR You can look up the IP address and access the Web interface of the mobile DVR using the IP Utility (IPU) program, which is included in the software CD. The IP Utility can also be downloaded from EverFocus’... - Page 23 EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR Note for the first time login: The “Download ePlayer Instruction” page will only be prompted for the first time login in order to update the system to the latest plugin version. When the Plug-in blocked appears on the browser, select Always allow plug-ins on xxx, click Done and then reload the webpage.
- Page 24 EMV1200 FHD / EMV800 FHD Hybrid Mobile DVR If your PC or laptop is running with Windows, it’s required to run the browser as administrator when first entering the remote web page of the device. Go to C:\Program Files (x86)\Internet Explorer, right-click the browser and then click Run as administrator.
- Page 25 FAX: +81 3 5625 8189 sales@everfocus.com www.everfocus.co.jp info@everfocus.co.jp Ihr EverFocus Produkt wurde entwickelt Your EverFocus product is designed and und hergestellt mit qualitativ manufactured with high quality materials hochwertigen Materialien und and components which can be recycled Komponenten, die recycelt und wieder and reused.
