Elecom M-BL2DB Series User Manual

5-button wireless Blue LED mouse
M-BL2DB Series
User's Manual
Thank you for purchasing the ELECOM M-BL2DB Series 5-button wireless Blue LED mouse.
This manual describes the operating instructions and safety precautions for using the
M-BL2DB Series. Ensure that you have read this manual before using the product. After
reading this manual, store it somewhere safe for future reference.
* Except in certain cases, the M-BL2DB Series is referred to as "this product" in this manual.
Safety Precautions
WARNING
Meaning of symbols Do not drop or hit this product.
„ „
If this product is damaged, immediately
Failure to observe precautions
stop using the product and disconnect the
may result in serious personal
WARNING
receiver unit from the PC, and remove the
injury or death due to fire,
battery from the mouse.
electric shock, or other causes.
If you continue to use the product under
Failure to observe precautions
these conditions, it may cause a fire or
may result in personal injury
electric shock.
CAUTION
due to electric shock or other
Do not attempt to disassemble, modify
causes, and may damage
or repair this product by yourself, as this
other equipment.
may cause a fire, electric shock or product
Prohibited action damage.
Do not put this product in fire, as the
Mandatory action
product may burst, resulting in a fire or
Situation that needs attention
injury.
Do not connect or disconnect the receiver
Notes and reference information
unit with a wet hand, modify the receiver
Information that is handy to know
unit or bend it forcibly, as this may cause a
fire or electric shock.
Observe these precautions carefully to avoid
The receiver unit contains small parts that
personal injury, damage, fire, and other problems.
could be swallowed by a child. Ensure that
the unit is stored in an area where it is not
WARNING
accessible to children.
If a foreign object (water, metal chip, etc.)
enters the product, immediately stop using
CAUTION
the product and disconnect the receiver
unit from the PC, and remove the battery
Do not place this product in any of the
from the mouse. If you continue to use the
following environments:
product under these conditions, it may
• In a car exposed to sunlight, a place
cause a fire or electric shock.
exposed to direct sunlight, or a place that
If an abnormality is found with this product
becomes hot (around a heater, etc.)
(emission of heat, smoke or abnormal smell
•
In a moist place or a place where conden-
from the product), immediately stop using
sation may occur
the product, shutdown the PC, and after
• In an uneven place or a place exposed to
thoroughly checking that heat from the
vibration
product will not cause burns, disconnect
• In a place where a magnetic field is
the receiver unit from the PC, and remove
generated (near a magnet, etc.)
the battery from the mouse. After doing
• In a dusty place
this, contact the retailer from whom you
This product does not have a waterproof
purchased the product.
structure. Use and store this product in a
place where the product body will not be
splashed with water or other liquid.
Rain, water mist, juice, coffee, steam or
sweat may also cause product damage.
Part Names
y When you no longer need to use this product and
the battery, be sure to dispose of it in accordance
with the local ordinances and laws of your area. Mouse
„ „
y If this product is malfunctioning, do not use it with
b
any equipment which has an important function or
c
could cause a serious negative influence.
y If this product is used on a transparent surface a
such as glass or a highly reflective surface such as a
mirror, the optical sensor will not function correctly
and mouse cursor movement will become unstable.
d
e
Batteries
„ „
CAUTION
For this product, use AAA alkaline batteries, AAA
manganese batteries or rechargeable AAA nickel hydride
batteries.
If this product will be unused for a long period of time,
remove the battery to avoid battery leakage and failure.
„ Receiver unit „
Cleaning the Mouse
„ „
If the product body becomes dirty, wipe it with a soft, dry cloth.
Use of a volatile liquid (paint thinner, benzene, alcohol,
etc.) may affect the material quality and colour of the
a Left button
product.
Used for left-click operation.
b Right button
Cautions for Wireless Equipment
Used for right-click operation.
c Wheel
This product is wireless equipment using the entire range of the
The wheel can be turned back and forward with your finger or
2.4 GHz band and it is possible to avoid the band of mobile object
pressed like a button to operate the PC.
identification systems. GFSK is used for the radio wave method. The
interference distance is 10 m. d Back button/ e Forward button
The 2.4 GHz band is also used by medical equipment, Bluetooth, and
Forward button
wireless LAN equipment conforming to the IEEE802.11b/11g/11n
Performs the forward action in a
standard.
web browser.
• Before using this product, check that there are no other "radio
Back button
stations"* operating nearby.
Performs the back action in a
• If electromagnetic interference occurs between this product and
web browser.
other "radio stations", move this product to another location or stop
using this product.
* Other "radio stations" refer to industrial, scientific and medical
devices using the 2.4 GHz band like this product, other radio
stations of this type, licensed radio station premises for mobile
object identification system that is used in factory production lines,
certain non-licensed low power radio stations and amateur radio
stations.
Forward button
WARNING Proceeds to the next
browser screen
● Do not use this product with a device that may have a
serious function or influence. There are rare cases where
an external radio wave at the same frequency or the
Preparation before Use
radio wave emitted from a mobile phone causes this
product to malfunction, slow down, or fail to operate.
● Do not use this product in a hospital or other locations
where the use of radio waves is prohibited. The radio
Installing·Replacing the Battery
waves of this product may affect electronic and medical
devices (e.g. pacemaker). Before using this product, install two AAA batteries in the mouse
● The use of a wireless mouse in an aircraft is prohibited by body.
aviation law because doing so may interfere with flight
Remove the battery cover.
safety. Turn off the power of the mouse body before
boarding an aircraft and do not use it in the aircraft.
* ELECOM is not liable for any accident or social
damages incurred by the failure of this product.
Insert the batteries.
Package Contents
Make sure that the
y
This product's packaging contains the items listed below. Before polarity is correct.
using the product, check that all items are present. We make
every effort to ensure that all products are packaged correctly.
However, in the event that an item is missing or damaged,
contact the retailer from whom you purchased the product.
Install the battery cover
•
Mouse x1
as before.
•
Receiver unit x1
•
AAA alkaline battery x2
•
User's Manual x1
Replacing the Battery
„ „
Remove the battery cover.
Remove the batteries using
the battery removal sheet.
Insert the batteries.
y Do not mix different
types of batteries or
use old batteries with
new batteries to avoid
battery leakage and
failure.
Install the battery cover as before.
To use the Back and Forward buttons with a Mac, you need
f
to install the ELECOM Mouse Assistant 2 Mac OS X version
n g
that can be downloaded from the ELECOM website.
Using the button allocation functions and flying
scroll function (See reverse)
h
i
f R e m a i n i n g b at te r y l eve l i n d i c ato r l a m p /
Resolution switch indicator lamp
j
y Indicates when to replace the batteries.
* When a battery has been inserted, if there are sufficient
remaining battery levels, it will illuminate in red for a
certain period of time. If the remaining battery level
k
becomes low during use, it will flash continuously in red
for a certain period of time.
l
y Flashes when the resolution (mouse cursor speed) is
changed.
m
* Flashes twice when switching from 800 to 1600
Flashes once when switching from 1600 to 800
g Optical sensor
o
Lights blue when the mouse is powered on.
When the mouse body is moved, this sensor detects mouse
movement.
* Avoid looking directly at the light of the sensor as doing so may
cause eye damage.
h Power switch
Used to turn the mouse body on and off.
i Resolution switch
Switches the resolution (mouse cursor speed) between 800 and
1600 each time the button is pressed.
j Receiver unit housing
Used to store the receiver unit.
k Battery cover
This cover is removed to install batteries.
l Battery housing
Batteries are inserted here.
m Battery removal sheet
Used to remove the batteries from the battery housing.
n Maintenance switch
For factory use only.
o USB connector (Male)
Connected to a PC USB port.
Back button
Returns to the previous
browser screen
Turning On and Off the Mouse
Turning on the mouse
„ „
When using this product, turn the mouse body
power on.
Slide the power switch to the ON position.
The remaining battery level indicator lamp is illuminated in red for a
certain period.
* When the remaining battery level is low, the remaining battery
level indicator lamp is flashed in red for a certain period.
Turning off the mouse
„ „
When not using this product, turn the mouse
body off to save battery power.
Slide the power switch to the OFF position.
Restoring from sleep state
„ „
Click the right mouse button.
To reduce battery drain, the mouse enters sleep mode
automatically if it is left without being operated for a
certain period of time with the power or switch turned on.
Inserting and Taking Out the Receiver Unit
Inserting the receiver unit
„ „
Place the receiver unit into the
receiver unit housing.
Taking out the receiver unit
„ „
Take the receiver unit out of the
receiver unit housing.
- 1 -
When using Windows®
3
1
S Checking wheel operation
S Check USB ports
tep tep
Check that the mouse vertical scrolling functions are working
Check the USB port on your computer.
correctly in Windows® Internet Explorer.
From the [Start] menu, select [All Programs], and
USB port
then [Internet Explorer].
Internet Explorer will launch.
Any USB port may be used.
y
This product can be connected to a USB hub. However, Display your favourite web site in Internet Explorer
y
it may not work depending on the power supply
and change the size of the window so that the
capability of the USB hub.
vertical scrollbar appears.
* The sample website used here is the ELECOM homepage.
2
S Installing the Receiver Unit
tep
Activate the PC
If Windows® prompts you to choose an account (a user
●
name) when it starts up, be sure to log on using an
administrator account.
● Wait until Windows® has started up completely.
Scroll the wheel back and
Insert the receiver unit into the USB port of the PC
forth. The mouse is operating
Insert here.
normally if the screen moves
up and down as you scroll
the wheel.
USB port
In applications that do not support scrolling, the
Receiver unit screen will not move when you scroll the wheel.
Click either of the links on the page to proceed to
y Carefully check the orientation of the connector
the next page.
and the place where you will connect the receiver
Operation is normal if pressing the Back button (
unit.
takes you to the previous page and pressing the Forward
y If you feel strong resistance when inserting
the receiver unit, check that the shape and button (
orientation of the connector is correct. Using
excessive force may damage the connector and
cause injury.
The mouse driver is installed automatically.
In certain applications, the function will not work when
you press the Back or Forward buttons.
When using Mac OS X
1 3
S Check USB ports S Checking wheel operation
tep tep
Check that the mouse vertical scrolling functions are working
Check the USB port on your computer.
correctly in Safari.
Click the Safari icon in the Dock.
USB port
Safari will launch.
Any USB port may be used. If Safari is not in the Dock, double-
y
This product can be connected to a USB hub. However, click the Safari icon in the Applications
y
folder.
it may not work depending on the power supply
capability of the USB hub.
Display your favourite web site in Safari and
change the size of the window so that the vertical
2
S Installing the Receiver Unit
tep
scrollbars appear.
* The sample website used here is the ELECOM homepage.
Activate the Macintosh.
● Wait until Mac OS X has started up completely.
Insert the receiver unit into a USB port on your
Macintosh.
Insert here.
Scroll the wheel back and
forth. The mouse is operating
normally if the screen moves
up and down as you scroll the
USB port
wheel.
Receiver unit
Carefully check the orientation of the In applications that do not support scrolling, the
y y
connector and the place where you will screen will not move when you scroll the wheel.
connect the receiver unit. To use the Back and Forward buttons with a Mac,
y
If you feel strong resistance when inserting
y you need to install the ELECOM Mouse Assistant
the receiver unit, check that the shape and
2 Mac OS X version that can be downloaded from
orientation of the connector is correct. Using
the ELECOM website.
excessive force may damage the connector and
Proceed to "Using the button allocation functions
cause injury.
and flying scroll function" on the reverse of this
sheet.
The mouse driver is installed automatically.
Up and down scrolling operation in MAC OS X 10.7
works in reverse from typical models. This can be
changed in the mouse settings screen.
Scrollbar
)
)takes you to the next page.
Scrollbar
