Connections and controls
1 [CH 1], [CH 2]
Inputs for line or microphone level signals (XLR / 1/4" combo sockets).
2 [LINE/MIC]
Switch for the signal level at the input. Switch released: Line level, switch pressed: microphone level.
3 [VOLUME]
Volume control for the respective channel
4 [REVERB]
Control for the reverb effect in the respective channel
5, 6, 7 [LOW], [MID], [HIGH]
Volume control for the respective channel
8 Volume for the Bluetooth channel
9
Indicator LED for the Bluetooth pairing
16
PA system
