Explorer I
C. Clearances to Combustibles
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS in inches (Millimeters)
SINGLE WALL PIPE
DOUBLE WALL PIPE
INSTALLATION: 90 DEGREE ELBOW OFF TOP OF APPLIANCE THROUGH BACKWALL
SINGLE WALL PIPE
DOUBLE WALL PIPE
SINGLE WALL PIPE
DOUBLE WALL PIPE
For alcove only: Six inch diameter listed Double wall air insulated connector pipe with UL103 HT listed factory built Class A
chimney or masonry chimney. Maximum depth of Alcove shall be no more than 48 inches (1219mm) and the referenced alcove
clearances. Canada must comply with CAN/ULC-S269 M87 for the 650° factory built chimney.
BACKWALL / SIDEWALL
A B
C
D
ALCOVE SIDE VIEW
G
A
WARNING
Fire Risk.
• Comply with all minimum clearances to
combustibles as specified.
• Failure to comply may cause house fire.
10
Note: A, C, and F Dimensions are to the center of the flue collar
INSTALLATION: FULL VERTICAL
A B
17 (432) 12-1/2 (165) 24 (607)
13-1/2 (343) 9 (229) 23 (584)
17 (432) 12-1/2 (165) 24 (607)
12-1/2 (165) 8 (203) 23 (584)
INSTALLATION: HORIZONTAL THROUGH THE WALL
N/A 8 (203) 24 (607)
N/A 8 (203) 24 (607)
* FOLLOW PIPE MANUFACTURES CLEARANCES AS REQUIRED
CORNER INSTALLATION
APPLIANCE TO CEILING
CLEARANCE
G
EXPLORER-I
C D E
11 (279) 7-1/2 (191)
10 (254) 3 (77)
11 (279) N/A
10 (254) N/A
11 (279) N/A
11 (279) N/A
F
E
H*
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having
jurisdiction
7062-197G
F G
18 (457) 53-1/2 (1359)
13-1/2 (343) 53-1/2 (1359)
N/A 53-1/2 (1359)
N/A 53-1/2 (1359)
N/A 53-1/2 (1359)
N/A 53-1/2 (1359)
ALCOVE TOP VIEW
HORIZONTAL THROUGH
THE WALL WITH TOP
AND SIDE VIEW
24"
(610mm)
53-1/2"
(1359mm)
11"
(280mm)
H*
N/A
N/A
18 (457)**
18 (457)
N/A
N/A
C
MANTEL
12" MAX
8"
(204mm)
August 13, 2018
