Explorer II Medium Wood Stove
Model(s):
EXPLRMED-PBK
EXPLRMED-PDB
EXPLRMED-PFT
EXPLRMED-PMH
EXPLRMED-MBK
FRONT PAGE
WARNING
Fire.Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should
be performed by qualifi ed personnel. Hearth &
Home Technologies recommends NFI certifi ed
professionals, or technicians supervised by an
NFI certifi ed professional.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instruc-
tions is not followed exactly, a
fi . re.may.result.causing.property.
damage,.personal.injury,.or.death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Hot.glass.will.cause.burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High. temperatures. may. ignite. clothing. or. other.
fl . ammable.materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafi re.com
7061-197H
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
NOTE
November 10, 2015
Advertisement
Table of Contents
Related Manuals for Quadra-Fire XPLRMED-PBK
Summary of Contents for Quadra-Fire XPLRMED-PBK
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER:.Leave.this.manual.with.party.responsible.for.use.and.operation.. OWNER:.Retain.this.manual.for.future.reference.. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc- Explorer II Medium Wood Stove tions is not followed exactly, a fi . re.may.result.causing.property. damage,.personal.injury,.or.death. Model(s): EXPLRMED-PBK • Do not store or use gasoline or other fl am- EXPLRMED-PDB mable vapors and liquids in the vicinity of this or any other appliance.
-
