INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
EXPLORER II WOOD APPLIANCE
MODEL(S):
EXPLRMED-PBK
EXPLRMED-PDB
EXPLRMED-PFT
EXPLRMED-PMH
EXPLRMED-MBK
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instructions is not
followed exactly, a fire could result causing
property damage, personal injury, or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void your
warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house
fire.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
To obtain a French translation of this manual, please contact
your dealer or visit
www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez
7061-197P
WARNING
WARNING
WARNING
NOTE
www.quadrafire.com
August 13, 2018
Advertisement
Table of Contents
Related Manuals for Quadra-Fire Explorer II series
Summary of Contents for Quadra-Fire Explorer II series
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not followed exactly, a fire could result causing property damage, personal injury, or death.
-
Page 2: Table Of Contents
B. Hearth Protection Requirements ....9 C. Clearances to Combustibles ....10 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7061-197P... -
Page 3: Important Safety Information
11, UL 737-11, (UM) 84-HUD and NPFA211 in the U.S.A. and the ULC S627-00 and CAN/CSA-B365 Installation Codes in Canada. NOT APPROVED FOR MOBILE HOME INSTALLATIONS IN CANADA! The Quadra-Fire Explorer II Wood Appliance (ACC) meets the U.S. Environmental Protection Agency’s crib wood emission limits for wood appliances sold after May 15, 2015. -
Page 4: Mobile Home Approved (Usa Only)
Explorer II C. Mobile Home Approved (USA only) WARNING • This appliance is approved for mobile home installations; when not installed in a sleeping room and Fire Risk when an outside combustion air inlet is provided. Hearth & Home Technologies disclaims any •... -
Page 5: Getting Started
Explorer II Install Guide Getting Started A. Design and Installation Considerations B. Fire Safety To provide reasonable fire safety, the following should be Consideration must be given to: given serious consideration: • Safety 1. Install at least one smoke detector on each floor of •... -
Page 6: Tools And Supplies Needed
Explorer II F. Removal of Appliance from Shipping To minimize the effects of negative air pressure: • Install optional outside air kit with the intake facing Materials prevailing winds during the heating season 1. Remove box and 2x4 structural boards being careful •... -
Page 7: Install Checklist
Explorer II G. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not istead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________ Date Installe: ______________________________________________________________________________ Lot / Address: ________________________________________________________________________... -
Page 8: Dimensions And Clearances
Explorer II Dimensions and Clearances A. Appliance Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 29 (737mm) 13-3/8 (340mm) 7/8 (22mm) 2-3/8 (60mm) 12-1/4 (514MM) (737mm) 20 (508mm) 27 (686mm) Figure 8.2 Top View Figure 8.1 Front View 3/8 (9mm) 25 (635mm) 21-3/4 (552mm) -
Page 9: Hearth Protection Requirements
Explorer II B. Hearth Protection Requirements In Canada, similar floor protection must be provided 18 inches (457mm) in front and 8 inches (203mm) from the EMBER PROTECTION: It is necessary to install a Type I sides and rear of the appliance unless the hearth pad is floor protector. -
Page 10: Clearances To Combustibles
Explorer II C. Clearances to Combustibles MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS in inches (Millimeters) Note: A, C, and F Dimensions are to the center of the flue collar EXPLORER-II INSTALLATION: FULL VERTICAL SINGLE WALL PIPE 10-1/2 (267) 6-1/2 (165) 20-1/4 (514) 6-1/2 (165) 7 (178) 17-1/4 (438) -
Page 11: Chimney Systems
Explorer II Chimney Systems A. Locating Your Appliance & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect • Locate termination cap away from trees, adjacent performance. -
Page 12: Chimney Termination Requirements
Explorer II B. Chimney Termination Requirements NOTICE: LOCATING THE APPLIANCE IN A BASEMENT OR IN A LOCATION OF CONSIDERABLE AIR Follow manufacturer’s instructions for clearance, securing MOVEMENT CAN CAUSE INTERMITTENT flashing and terminating the chimney (Figure 12.1 & 12.2). SMOKE SPILLAGE FROM APPLIANCE. DO NOT •... -
Page 13: Chimney Height / Rise And Run
Explorer II D. Chimney Height / Rise and Run Chimney: The chimney can be new or existing, masonry or This product was designed for and tested on a 6 inch prefabricated and must meet the following minimum (152mm) chimney, 14 to 16 feet (420-480cm) high, requirements and as specified in Section 4F. - Page 14 Explorer II Thimble Listed Termination Cap Site constructed for masonry chimney installation: Storm Collar Components A minimum length of 12 inches [305mm] (longer for thicker Flashing walls) of solid insulated factory-built chimney length constructed to UL 103 Type HT 6 inch (152mm) inside diameter.
-
Page 15: Installing Chimney Components
FULL Vertical installations. Figure 15.2 H. Proper Draft To be sure that your Quadra-Fire insert burns properly, the chimney draft (static pressure) should be approximately -0.10 inches water column (W.C.) during a high burn and -0.04 inches W.C. during a low burn, measured 6 inches (152mm) above the top of the insert after one hour of operation at each burn setting. -
Page 16: Appliance Set-Up
Explorer II Appliance Set-Up A. Outside Air Kit Installation WARNING A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is Fire Risk. consumed by the fire must be replaced. Air is replaced via Asphyxiation Risk. -
Page 17: Blower (Optional)
Explorer II B. Blower (Optional) The convection air top assembly can be raised to redirect Tools Required: #2 Phillips head screwdriver air over the top of the appliance by removing 4 screws 1. Locate bolts supplied with the blower. and lifting assembly to align with upper mount holes and 2. -
Page 18: Optional Fire Screen
Explorer II C. Optional Fire Screen An optional fire screen is available for the Explorer III. Flue collar Optional Fire Screen Part SCR-7061 may be used ONLY in Convection U.S. residential installations. Follow all safety warnings to chamber top prevent any hazards. WARNING Fire Risk. -
Page 19: Mobile Home Installation
Explorer II Approved for USA Installation only! Mobile Home Installation You must use a Quadra-Fire Outside Air Kit Part 10. Burn seasoned cord wood only. Other types of fuels may generate poisonous gases (e.g., carbon OAK-ACC; which is available from you dealer, for monoxide). -
Page 20: Reference Materials
Explorer II Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service 7061-197P August 13, 2018... -
Page 21: Accessories
7061-011PMH Porcelain Mahogany Matte Black SRV7061-027 Explorer II Porcelain Black SRV7061-031 B. Accessories SRV7061-032 Component Pack Porcelain Dark Blue Porcelain Frost SRV7061-033 Explorer II Service Parts SRV7061-028 Porcelain Mahogany Leveling Assembly 7000-000 Beginning Manufacturing Date: March 2014 Matte Black 812-0910 Ending Manufacturing Date: Active Porcelain Black 1-00-0022... - Page 22 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL...
