SONESSE (Ultra Quiet)

506 MOTOR

INSTALLATION INSTRUCTIONS

SONESSE (Ultra Quiet) 506

MOTORS

INSTALLATION INSTRUCTIONS

Thank you for purchasing your new Sonesse (Ultra

Quiet) 506 Motor. They have been custom-made from

the highest quality materials to the dimensions you

specified. With the proper installation and care, it will

provide you with many years of beauty and trouble-

free use.

Please read all instructions before you start so you will

be familiar with the overall process.

Make sure you measure your window to ensure the

motors and shades will fit properly before beginning.

Getting Started

Remove the motor and shade from the packaging.

Keep the packaging until you have successfully installed the

motorized shade.

• Pencil

• Awl

• Tape Measure

• Level

• Ladder or Stepstool

PLEASE NOTE:

This is a very powerful heavy motor and the brackets have

to be secured and attached to wood studs.

FASTENERS CANNOT BE USED!

Often, wood headers are found above the windows. If this

is not possible, and you can't secure the shade brackets to

the wood studs, then plan on using a Headbox.

Headbox brackets can be located and attached to the

wood studs.

page

• Power Drill with the following bits:

- ¹⁄₁₆" Drill Bit

- ¹⁄₄" Hex Driver

- Standard Screwdriver

- Masonry Drill Bit (if drilling into concrete

or brick)

Need help?

Do you have a question about the Sonesse (Ultra Quiet) 506 Motor and is the answer not in the manual?

Questions and answers

Summary of Contents for Fabritec designs Sonesse (Ultra Quiet) 506 Motor

Page 1: Getting Started
SONESSE (Ultra Quiet) 506 MOTORS INSTALLATION INSTRUCTIONS Thank you for purchasing your new Sonesse (Ultra Quiet) 506 Motor. They have been custom-made from the highest quality materials to the dimensions you specified. With the proper installation and care, it will provide you with many years of beauty and trouble- free use.
Page 2 BEFORE YOU BEGIN, VERIFY THAT YOU HAVE ALL THE NECESSARY STEP 1 - INSTALLING THE BRACKETS (continued). PARTS AND PIECES: b) Next, install and mount the motor end bracket. • PACKAGE - Contains an idler end bracket and a motor end See illustration below.
Page 3 STEP 2 - INSTALLING THE IDLER END OF SHADE STEP 3 - INSERT THE MOTOR END. (continued). a) Place the idler end into the idler end bracket. a) Slip the motor end into the bracket. Make sure the cord is positioned toward the back of the bracket.
Page 4 STEP 4 - CONNECT YOUR POWER SOURCE AND TEST THE Caring for your Sonesse (Ultra Quiet) 506 SHADE. Motors & Roller shades Please note, your shades are preset at the factory. If limit adjustments are required, refer to the programming Your Sonesse (Ultra Quiet) 506 motors and roller shades will instructions.
