REMOTE CONTROL
MOTORIZED
ROLLER SHADES
INSTALLATION INSTRUCTIONS
REMOTE CONTROL MOTORIZED
ROLLER SHADES
INSTALLATION INSTRUCTIONS
Thank you for purchasing your new Remote Control
Motorized Roller Shades. They have been custom-
made from the highest quality materials to the
dimensions you specified. With the proper installation
and care, it will provide you with many years of beauty
and trouble-free use.
Please read all instructions before you start so you will
be familiar with the overall process.
Make sure you measure your window to ensure the
motors and shades will fit properly before beginning.
Getting Started
Remove the motor and shade from the packaging.
Keep the packaging until you have successfully installed the
motorized shade.
TOOLS REQUIRED.
• Pencil
• Awl
• Tape Measure
• Level
• Ladder or Stepstool
PLEASE NOTE:
This is a very powerful heavy motor and the brackets have
to be secured and attached to wood studs.
FASTENERS CANNOT BE USED!
Often, wood headers are found above the windows. If this
is not possible, and you can't secure the shade brackets to
the wood studs, then plan on using a Headbox.
Headbox brackets can be located and attached to the
wood studs.
page 1 of 3
• Power Drill with the following bits:
- ¹⁄₁₆" Drill Bit
- ¹⁄₄" Hex Driver
- Standard Screwdriver
- Masonry Drill Bit (if drilling into concrete
or brick)
Advertisement
Summary of Contents for Fabritec designs REMOTE CONTROL MOTORIZED ROLLER SHADES
-
Page 1: Getting Started
REMOTE CONTROL MOTORIZED ROLLER SHADES INSTALLATION INSTRUCTIONS Thank you for purchasing your new Remote Control Motorized Roller Shades. They have been custom- made from the highest quality materials to the dimensions you specified. With the proper installation and care, it will provide you with many years of beauty and trouble-free use. - Page 2 BEFORE YOU BEGIN, VERIFY THAT YOU HAVE ALL THE NECESSARY STEP 1 - INSTALLING THE BRACKETS (continued). PARTS AND PIECES: b) Next, install and mount the motor end bracket. • PACKAGE - Contains an motor end bracket and a idler end See illustration below.
- Page 3 Caring for your Remote Control of shade Motorized Roller shades Your Remote Control motorized roller shades will provide you with years of beauty and pleasure with minimal care and cleaning. b) After installing the motor end, slip the retainer clip onto the motor end.
