- Page 1 Advantix base unit for Advantix shower channel Instructions for Use for bonded sealing (tiled shower) with sealing mat Model Year built: 4982.10 from 04/2016 en_INT...
- Page 2 Advantix base unit for Advantix shower channel 2 from 33...
-
Page 3: Table Of Contents
Determine height 3.2.2 Mount base unit 3.2.3 Align shower channel 3.2.4 Connect shower channel 3.2.5 Preparing for further work 3.2.6 Sealing the shower channel Care 3.3.1 Care tips 3.3.2 Cleaning Disposal Advantix base unit for Advantix shower channel 3 from 33... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
German/European directives specified in this manual: The information herein is not binding for other countries and regions; as said above, they should be understood as a recommendation. Advantix base unit for Advantix shower channel 5 from 33... -
Page 6: Product Information
Typical domestic wastewater DIN 1986-3 Regulations from section: Sound protection Scope / Notice Regulations applicable in Ger- many Fulfilled noise protection require- DIN 4109 ments Fulfilled noise protection require- VDI 4100 ments Advantix base unit for Advantix shower channel 6 from 33... -
Page 7: Intended Use
95–155 mm 50 mm 0.5 l/s 0.55 l/s Model 4982.93 70–110 mm 25 mm 0.4 l/s 0.45 l/s Model 4982.94 95 mm and up 50 mm 0.9 l/s 1.1 l/s Advantix base unit for Advantix shower channel 7 from 33... -
Page 8: Product Description
The following parts are not included in the scope of delivery and must be ordered separately: odour trap adjustable feet mounting frame Grate sealing material Ä Chapter 2.5 „Required accessories“ on page 11 Advantix base unit for Advantix shower channel 8 from 33... -
Page 9: Technical Data
Ä „Regulations pliance with the valid standards and regulations, see: from section: Sealing“ on page 6 . Advantix base unit for Advantix shower channel 9 from 33... - Page 10 Fig. 3: Construction diagram of the bonded seal - min. screed incline 1–2 % 1 - Grate 2 - Top piece with adhesive flange 3 - Tile 4 - Tile cement 5 - Bonded sealing 6 - Screed Advantix base unit for Advantix shower channel 10 from 33...
-
Page 11: Fire Protection
(see catalogue) Sealing tape for Advantix shower channels, model 4964.95, art. no. 619 121 if required: mounting adhesive, model4938.22, art. no. 571 788 Advantix base unit for Advantix shower channel 11 from 33... - Page 12 Water seal level 50 mm Construction height 95 mm and up Drainage capacity Accumulation height 10 mm: 0.9 l/s Accumulation height 20 mm: 1.1 l/s Fig. 7: Odour trap model 4982.94 Advantix base unit for Advantix shower channel 12 from 33...
- Page 13 For installation height 95–155 mm Fig. 8: Adjusting feet set model 4982.90 For installation height 70–110 mm Fig. 9: Adjusting feet set model 4982.91 Mounting frame Rectangular design Fig. 10: Mounting frame model 4982.30 Advantix base unit for Advantix shower channel 13 from 33...
- Page 14 Product information Round design Fig. 11: Mounting frame model 4982.40 Rectangular design, standard Fig. 12: Mounting frame model 4982.45 Advantix base unit for Advantix shower channel 14 from 33...
-
Page 15: Handling
Position the shower channel in such a way that the grate is remov- able. After assembly: The shower channel must be fully lined with mortar. Coordinate all relevant installation details, especially regarding the bonded sealing, with those responsible for the subsequent work. Advantix base unit for Advantix shower channel 15 from 33... -
Page 16: Installation Dimensions
736 965 736 972 736 989 736 996 1000 1000 737 009 1200 1120 1200 linear dimension of the base unit inner dimension of the base unit (grate size) Advantix base unit for Advantix shower channel 16 from 33... -
Page 17: Tools And Materials
Depending on the selected odour trap, different installation heights can be implemented. A - Model 4982.92 B - Model 4982.93 C - Model 4982.94 ≥ 95 ≥ 70 ≥ 40 Determine screed height. Advantix base unit for Advantix shower channel 17 from 33... -
Page 18: Mount Base Unit
Lay the greased O-Ring into the casing. Observe the proper orientation of the O-ring (see arrow). Press the drain straight into the connection element until it snaps home. Mounting the adjustable feet and drain sockets Advantix base unit for Advantix shower channel 18 from 33... - Page 19 B – Model 4982.91, installation height: 70–95 mm 95 - 160 70 - 95 Mount the adjustable feet. Regarding mounting, refer to the instructions for use for the adjusting feet set. Put in the odour trap insert. Advantix base unit for Advantix shower channel 19 from 33...
-
Page 20: Align Shower Channel
Insert the immersion pipe of the odour trap to fasten the odour trap insert. 3.2.3 Align shower channel Set the feet to screed height to adjust the base unit. Align the base unit horizontally in all directions. Advantix base unit for Advantix shower channel 20 from 33... -
Page 21: Connect Shower Channel
The drainpipe has an internal profile seal. Proceed as follows: Insert the drain socket into the flanged pipe as far as it will go. 3.2.5 Preparing for further work Advantix base unit for Advantix shower channel 21 from 33... - Page 22 Remove the hard foam block from the packaging. Insert the protective insert made of hard foam. The protective insert acts as a mounting aid and protection against contamination. Advantix base unit for Advantix shower channel 22 from 33...
- Page 23 INFO! Screed and floor tiles must be laid at an incline of 1–2 % in the direction of the shower channel. Line the shower channel up to the upper edge of the flange with screed. Advantix base unit for Advantix shower channel 23 from 33...
-
Page 24: Sealing The Shower Channel
The mounting adhesive is not included in the scope of delivery. We rec- ommend model 4938.33, Art.-No. 571 788. Sealing with bonded sealing, without mounting adhesive Remove the site protection. Cut the sealing tape generously. The strips should overlap when stuck on. Advantix base unit for Advantix shower channel 24 from 33... - Page 25 Stick the overlapping tape strips together at the corners with bonded sealing. Thoroughly press the adhesive joints together with a roller. Apply the second layer of bonded sealing generously onto the sealing tape and floor screed. Advantix base unit for Advantix shower channel 25 from 33...
- Page 26 (Assembly without profile trim)“ on page 30 . Sealing with bonded sealing and mounting adhesive Remove the site protection. Cut the sealing tape generously. The strips should overlap when stuck on. Advantix base unit for Advantix shower channel 26 from 33...
- Page 27 Unscrew the cartridge and cut it so that you can apply the adhesive in a strip of approx. 8 mm width. ca. 8 mm Apply the mounting adhesive to the flange. Advantix base unit for Advantix shower channel 27 from 33...
- Page 28 Overlap the corners in the process. 10 mm Stick the overlapping strips together at the corners with mounting adhesive. Thoroughly press the adhesive joints together with a roller. Advantix base unit for Advantix shower channel 28 from 33...
- Page 29 (Assembly without profile trim)“ on page 30 . Mounting with Viega mounting frame Regarding mounting, refer to the instructions for use for the mounting frame. 4982.40 4982.30 4982.45 Assembly with cover trim Advantix base unit for Advantix shower channel 29 from 33...
- Page 30 – on cover trim profiles Polish the tile edge. Finally, a grate must be mounted. See catalogue for suitable grates. Regarding mounting, refer to the instructions for use for the grate. Advantix base unit for Advantix shower channel 30 from 33...
-
Page 31: Care
We recommend using a mild cleaning agent, a cloth and a washing-up brush for cleaning. Cleaning the drain Remove the grate, for example with the removal tool model 4965.90, art. no. 689 704. Remove the sieve and clean under running water. Advantix base unit for Advantix shower channel 31 from 33... - Page 32 Clean the sieve and immersion pipe. Remove the odour trap insert. Clean the base unit. Replace the odour trap insert. Replace the immersion pipe. Replace the sieve. Replace the grate. Advantix base unit for Advantix shower channel 32 from 33...
-
Page 33: Disposal
Replace the grate in the shower channel. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Advantix base unit for Advantix shower channel 33 from 33...
