Bradley WF3203 Installation Instructions Manual

Terreon series
Hide thumbs Also See for WF3203:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
TDB3103
WF3203
215-1579 Rev. D; EN 10-00-002
© 2010 Bradley Corporation
Page 1 of 24
1-26-10
Installation
Instructions
TDB3103
Terreon
®
36" Semi-Circular
Deep Bowl Washfountain with
TouchTime
®
Control
WF3203
Terreon
®
Extra Height 36" Semi-
Circular Classic Washfountain with
9" Deep Bowl and TouchTime

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . 2
Washfountain Rough-Ins . . . . . . . . . . . . . . . . . . 5-7
Installation Instructions . . . . . . . . . . . . . . . . . . .7-12
TouchTime® Troubleshooting . . . . . . . . . . . . . . .14
Terreon® Cleaning/Maintenance . . . . . . . . . . . . .15
Solenoid Valve Troubleshooting . . . . . . . . . . .21-22
IMPORTANT
Main water supply to the unit
should be ON at all times.
This installation manual and parts
list should be filed by the owner's
maintenance department.
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY
http://www.bradleycorp.com
®
Control
FAX 262-251-5817

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF3203 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bradley WF3203

Summary of Contents for Bradley WF3203

  • Page 1: Table Of Contents

    Model TDB3103 Washfountain Dimensions ..3 Model WF3203 Washfountain Dimensions ..4 Washfountain Rough-Ins ....5-7 Installation Instructions .

  • Page 2: Pre-Installation Information

    • Teflon tape or pipe dope • 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied • OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature allows no accidental water delivery during regular maintenance and service.

  • Page 3: Model Tdb3103 Washfountain Dimensions

    Subtract 2" 14 or 15, Grades 6 thru 8 or 9 30" TAS Ages 4 thru Subtract 4" 10 or 11, Grades 6 thru 8 or 9 & Proposed Juvenile Height ADA Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...

  • Page 4: Model Wf3203 Washfountain Dimensions

    Terreon® Deep Bowl 36" Semi-Circular Washfountain with TouchTime ® Metering Control TDB3103, WF3203 Installation Instructions Semi-Circular Washfountain Dimensions Top view Model WF3203 36" Semi-circular - side view 6" (152) Back view Bottom View Figure 1b 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 5: Washfountain Rough-Ins

    TAS Ages 11 thru 14 or 15, Subtract 2" Grades 6 thru 8 or 9 30" TAS Ages 4 thru 10 or 11, Subtract 4" Grades Pre-K thru 5 or 6 & Proposed Juvenile Height ADA Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 6 NOTE: Supply lines for one to two *17 - 21" washfountains should be 1"; for three DRAIN THROUGH WALL (432 - 533) Figure 3 washfountains, 1-1/4". For more than three washfountains, pipe sizes should be increased proportionately. 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 7: Installation Instructions

    6. Using 1/4" wing nuts and washers, secure the bowl to the pedestal, three places (see Figure 4). CAUTION: BOWL SURFACE IS SMOOTH. APPROXIMATE WEIGHT OF BOWL IS 75 POUNDS. HANDLE WITH CARE! Figure 4 Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 8 Tighten nut to secure tube to fitting (make sure nut is securely tightened). • If connector leaks, reseat tubing according to above procedure. If leaking persists, replace male connector, or call your Bradley representative for assistance. 4. Connect P-Trap (supplied by installer) to tailpiece and drain outlet.
  • Page 9 FOR “A” UNIT: Connect flexible hoses to supply stops using suitable fittings. FOR “O” UNIT: Install 1/2" nom. copper tubing supply lines (pass through holes in cover, down through support column) and connect flexible hoses to supply stop valves using suitable fittings. Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 10 Part no. varies with color of bowl. Contact your 125-011 local Bradley Representative for assistance. VALVE ASSY. SEE FIGURE 8 FOR PART NUMBER PEDESTAL ASSY. ACCESS PANEL S17-287 186-1260 A/O UNITS Figure 7 (A shown) 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...
  • Page 11 SPACER COUPLING NUT AND SET SCREW MODULE 4-1/4" COVER TIE ROD 176-118 18-1/8" TIE ROD COUPLING 176-008 NUT AND SET SCREW ACTUATOR TIE BAR MODULE ASSEMBLY SUPPORT TUBE SPRAYHEAD Figure 8 Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 12 TOUCHTIME VALVE WITH TEMPERED LINE (NOT SHOWN ) S45-2234 NOTE: FLUSH SUPPLY LINES BEFORE MAKING CONNECTIONS. DO NOT APPLY PIPE SEALANT TO COMPRESSION FITTINGS. Touch Time Module (S83-180) Transformer Circular TT (S83-134) Module Assembly Supply Tube Figure 10 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 13: Vernatherm Adjustment Instructions

    8. Clean sprayhead if necessary. See page 18 for sprayhead maintenance and repair parts. Adjust the volume control valve, if necessary, to control the flow of water. 9. Attach pedestal access panel with hardware provided. TEMPERATURE TEMPERATURE ADJUSTMENT LOCKING STEM Figure 11 Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...

  • Page 14: Touchtime® Troubleshooting

    If, after checking the transformer, the solenoid valve and the wiring, you are unable to activate the sprayhead by pressing the Touch Time push button, the Touch Time switch assembly is not working properly and needs to be replaced. Contact your Bradley representative to order a replacement switch assembly.

  • Page 15: Terreon® Cleaning/Maintenance

    ® Solid Surface cleaner and polish to refresh and protect the Terreon Solid Surface material. Bradley recommends additional care and maintenance for the darker colored Terreon, for complete instructions on this additional maintenance see Bradley document #1505. IMPORTANT: DO NOT USE STRONG ACID OR ALKALINE CHEMICALS AND CLEANSERS TO CLEAN TERREON.

  • Page 16: Stainless Steel Cleaning/Maintenance

    It is emphasized that all products should be used in strict accordance with package instructions. 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 17: Soap Dispensing Valve Repair Parts

    Attaching Assembly Parts S09-057 S09-057S Item Part No. Description 124-001D Washer — 110-057 — 125-001AN Stopper — 159-114 Reinforcing Plate — 124-001AT Washer — 160-176 Screw — S09-040 Valve S53-045 Adaptor Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 18 If none is present, it will be necessary to drill out the bearing hole with a 1/2" or 5/8" drill. The plastic container config- uration forms a natural template for locating the bearing hole. 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 19: Soap Recommendations And Maintenance

    Soap thickness is determined by a measurement called viscosity. Soap viscosity should be between 100 cps (centerpoise) and 2500 cps for all Bradley soap dispensers. Thinner soaps are perceived by the users as being "watered down" so users tend to take more than they need, resulting in waste. Thick soaps flow slower and inhibit the "flushing"...

  • Page 20: Sprayhead Troubleshooting/Repair Parts

    NOTE: The sprayhead shown above includes a perforated neopreme spray ring grommet that is self-cleaning. The water pressure flexes the spray holes which slows accumulation of foreign matter and tends to “break loose” any such deposits that may have accumulated. 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...

  • Page 21: Solenoid Valve Troubleshooting

    • reconnect to the adjacent valve and turn on the water supplies to the unit; • pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor. Bradley Corporation • 215-1579 Rev. D EN 10-00-002 1-26-10...
  • Page 22 VALVE BODY, 5/16" CLOSED 269-983 DIAPHRAGM 269-577 ARMATURE 269-578 SPRING 269-1729 ARMATURE HOUSING 269-1730 CLAMP, ARMATURE HOUSING 269-579 COIL, SOLENOID VALVE 160-447 SCREW, #8 X 5/8 125-001CS O-RING, #2-013 Figure 12 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-...

  • Page 23: Thermostatic Mixing Valve Troubleshooting

    Problem: Limited water flow Cause: Dirt and debris have built up in the valve or strainer. 1. Remove and clean strainer. If strainer needs to be replaced, order Bradley part no. 173-028. 2. Check the piston for smooth movement. To check the valve's piston for free and smooth movement, follow the procedures outlined below: 1.
  • Page 24 Vernatherm™ Thermostatic Mixing Valve (S01-524) Repair Kit S65-259 Nut 3/8-24 Hex Jam Item Description Thermostat O-Ring O-Ring O-Ring O-Ring Stem Thermostat Piston Spring Seal Cup Valve Body Strainer (173-028) Figure 13 1-26-10 Bradley Corporation • 215-1579 Rev. D; EN 10-00-002...
