HMP60 / HMP110 / HMP110T
Wiring / Verdrahtung / Câblage / 配線 / 接线
2
1
4-pin M8 Male
HMP60 / HMP110 / HMP110T
5 ... 28 VDC (V
1
8 ... 28 VDC (V
Channel 1: RH / Td / T
2
0 ... 1 / 2.5 / 5 V, 1 ... 5 V
GND / AGND
3
Channel 2: RH / Td / T
4
0 ... 1 / 2.5 / 5 V, 1 ... 5 V
HMP110T: No output on channel 2
HMP110T: Keine Ausgabe über Kanal 2
HMP110T: Aucune sortie sur le canal 2
HMP110T: チャンネル2に出力がありません
HMP110T: 通道 2 无输出
Dimensions / Abmessungen / Dimensions / 寸法 / 尺寸
4
3
0 ...1 / 0 ... 2.5 V)
out
0 ... 5 / 1 ... 5 V)
out
Vaisala Humidity and Temperature Probes
Brown / Braun / Marron / 茶 / 褐
White / Weiβ / Blanc / 白 / 白
Blue / Blau / Bleu / 青 / 蓝
Black / Schwarz / Noir / 黒 / 黑
HMP60 and HMP110 Series
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vaisala HMP110
Summary of Contents for Vaisala HMP110
- Page 1 Vaisala Humidity and Temperature Probes HMP60 and HMP110 Series HMP60 / HMP110 / HMP110T Wiring / Verdrahtung / Câblage / 配線 / 接线 4-pin M8 Male HMP60 / HMP110 / HMP110T 5 ... 28 VDC (V 0 ...1 / 0 ... 2.5 V) Brown / Braun / Marron / 茶...
- Page 2 HMP63 / HMP113 Wiring / Verdrahtung / Câblage / 配線 / 接线 4-pin M8 Male 5 ... 28 VDC (V 0 ...1 / 0 ... 2.5 V) Brown / Braun / Marron / 茶 / 褐 8 ... 28 VDC (V 0 ...
- Page 3 HMP110REF (Constant Output Probe) HMP110REF is a validation tool that outputs constant digital humidity and temperature readings. It does not have any sensors, and it does not measure. The output is defined when ordering from Vaisala. Order Code: HMP110REF Relative Humidity...
- Page 4 Bits d’arrêt Contrôle de flux données 通信速度 パリティ データビッ ト ストップビ フロー制御 ッ ト 波特率 奇偶 数据位 停止位 流量控制 Ref. M211059EN-E © Vaisala 2017. All Rights Reserved. *M211059EN* Vaisala Oyj Vanha Nurmijärventie 21 www.vaisala.com/manuals FI-01670 Vantaa, Finland...
