- Page 1 FPC-2 Fire Control Panel with Extinguishant Control Unit for Aerosol Release Operation and Maintenance Manual Issue 5.3 January 2017...
-
Page 2: Table Of Contents
The FPC-2 Panel Protection Controller enables monitoring of detection and extinguishing circuits. The panel will support up to 4 FirePro aerosol generators. The FPC-2 requires a battery backed 24V DC power supply capable of delivering 3A for a short period in order to operate the Aerosol Generators. -
Page 3: Installation And Mounting
This equipment is designed to be operated from 24V DC supply. This power supply must be battery backed. The FPC-2 should be effectively bonded to earth. Failure to ensure that all conductive accessible parts of this equipment are adequately bonded to earth will render the equipment unsafe. -
Page 4: Detection Zone Wiring
Max Number of FPC-2 Units chained together is 3 using the power IN / OUT link. For additional units need to wire separately. Power supply will need to consider what current is required to ensure all devices operate correctly. Detection zone wiring These terminals are for the connection of a conventional type 24V smoke detector or other another detection device such as linear heat detection cable. -
Page 5: Connection Of Aerosol Units To Activation Circuit
Connection to FirePro Units When constructing leads to the FirePro units the supplied Deutsch Plugs must be used to ensure water-proof connections are made throughout the installation. 1. Cut cable to required length and strip outer insulation to approximately 50mm. -
Page 6: Connecting To Master Fire Panel
“Enable Control” port. FPC-2 as a activation Module only This configuration uses the FPC-2 as an activation module only. This can be established with any style of AS Panel. Individual configurations will be dependent on the specifics of the master panel. -
Page 7: Panel Operation
7. Maintenance FPC-2 control panels do not require any specific maintenance but should the control panel become dirty it can be wiped over with a damp cloth and should then be dried with a dry, lint free cloth. Detergents or solvents should...
