MANUAL
FIRE DETECTION & ALARM SYSTEM
Waitsia Gas – Stage 2
3 – Gas Engine Generators
1 – Diesel Enclosure Generator
2 – Battery Energy Storage Systems
Rev.1.0
Contents
MANUALS
Sigma XT Fire Indicator Panel
Sigma XT Ancillary Relay Board
Sigma XT Signs & Local Control Station
VizuLinx - Modbus
Spectrex Flame Detector - Modbus
Spectrex Flame Detector
SensePoint Gas Detector
Dual Tone - Sounder Strobe

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sigma XT and is the answer not in the manual?

Questions and answers

Related Manuals for FirePro Sigma XT

Summary of Contents for FirePro Sigma XT

  • Page 1 2 – Battery Energy Storage Systems Rev.1.0 Contents MANUALS Sigma XT Fire Indicator Panel Sigma XT Ancillary Relay Board Sigma XT Signs & Local Control Station VizuLinx - Modbus Spectrex Flame Detector - Modbus Spectrex Flame Detector SensePoint Gas Detector Dual Tone - Sounder Strobe...
  • Page 2 Conventional Fire Control Panel with Extinguishant Control Unit for Aerosol Release Operation and Maintenance Manual Available in 2 Zone, 8 Zone, Single risk or dual risk. SIGMA-XT-FP Issue 4.03 Jan 2024...

  • Page 3: Table Of Contents

    Thermal Fuse Mounting ......................12 Thermal Fuse Connection ......................12 Thermal Fuse connection when 2 Thermal Fuses installed ............... 12 Multiway Sequential Activator (FirePro Units) ..................13 Overview ..........................13 Installation ..........................13 Connection of Aerosol Units to Activation circuit ................14 Connection to FirePro Units ......................
  • Page 4 Low Pressure Switch – Normal/Invert ................22 Release Pressure Switch – Normal/Invert ..............22 Panel operation – Access levels 1 and 2....................22 Normal condition ........................22 Alarm Module – Access level 2....................23 Test mode ........................23 Disable zones......................23 Disable sounder outputs ....................

  • Page 5: Introduction

    Operation outside these parameters will lead to premature failure. The FirePro SIGMA XT-A, conventional fire alarm control panel with Extinguishant Control Unit and Aerosol Agent Controller, is designed to comply with AS7240-2, AS7240-4 Fire Detection and Fire Alarm Systems - Control and Indicating Equipment, and AS ISO 14520.1 2009 Gaseous Fire Extinguishant Systems.

  • Page 6: Access Levels & General Fault Codes

    2. Access Levels & General Fault Codes For more information on Access Levels, please see Section 7 - Panel operation – Access levels 1 and 2. Access Levels 1 and 2 The cabinet door has 3 locks: The centre lock opens the display window, allowing for operation of the controls.

  • Page 7: Connecting To The Control Panel

    3. Connecting to the Control Panel The Panel has 2 major components • Alarm Module • Extinguishant Module Software revision number New features may be added to Sigma CP fire control panels from time to time and when this is done the operating software of the unit is updated.
  • Page 8 EOL Resistors EOL Detection Circuits EOL Sounder Circuits Sigma_XT_M4.03 Page 7 of 33...
  • Page 9 24vDC Input from PSU Releasing Solenoid 1N4004 Diode PF Input from PSU Releasing Solenoid 1N4004 Diode Aux 24vDC Output Remote Manual Release Switch EOL 6K8 Fault relay Contact Remote Hold Switch EOL 6K8 Stop Air Conditioning Remote Abort Switch EOL 6K8 Shutdown Power Remote Auto/Manual Select Switch EOL 6K8...

  • Page 10: Warning Sign And Status Unit Connection

    Warning Sign and Status Unit Connection Each Sign requires BOTH 24v POWER and RS485 connections as shown. MAXIMUM devices 7. Individual addresses required for each Sign. The address switch is located on the bottom left hand corner of the status unit. The address is only read when the boards are first powered, so address switches should not be altered on a system that has power applied, as changes will not be recognised.

  • Page 11: Adding - Removing Status Units -Electronic Signs - Local Control Stations

    Adding - Removing Status units -Electronic Signs – Local Control Stations PANEL SHOULD BE POWERED DOWN before any changes are made to status units. Status units include Electronic Signs (DNE-EVAC-Sys InOp) and Local Control Stations When the system is X FAULTS first powered on, it will search for connected status units connected to Enter TO VIEW extinguishant module.

  • Page 12: Detection Zone Wiring

    Detection zone wiring The detection zones provide a nominal 24V DC to power compatible conventional detectors and call points. The wiring is monitored for open and short circuit fault conditions. Detection zone circuits must be wired as a single, radial circuit with no spurs or T junctions to enable the monitoring circuit to work correctly. Sounder circuit wiring All sounders must be of the polarised type.

  • Page 13: Thermal Fuse Mounting

    FIP that the system has operated. It has no ability to activate the system. SINGLE USE ONLY – CANNOT BE RESET Thermal Fuse Connection A Thermal Fuse to be connected to the ONE of the FirePro Aerosol Generators has activated. It should be installed in accordance with the instructions included in the relevant FirePro document.

  • Page 14: Multiway Sequential Activator (Firepro Units)

    4. Multiway Sequential Activator (FirePro Units) Overview Sequential Activator enables connection of actuator devices. Multiple boards can be connected together to provide control and supervision of up to 40 igniting actuator devices from a single extinguishing control panel circuit. Where multiple boards are connected, the system comprises one Master board connected to up to 4 Slave boards.

  • Page 15: Connection Of Aerosol Units To Activation Circuit

    This would require 3 splitter leads. Connection to FirePro Units When constructing leads to the FirePro units the supplied Deutsch Plugs must be used to ensure water-proof connections are made throughout the installation. 1. Cut cable to required length and strip outer insulation to approximately 50mm.

  • Page 16: Indications

    Standard screw terminals are provided for the connection of a remote Isolate switch and indicator. Closing a volt free contact across the ISOL I/P terminals will isolate all outputs. The Isolated condition can be indicated at a remote location via the ISOL O/P volt free terminals. Indications Actuator outputs are supervised for circuit faults and a yellow Fault indicator is provided for each of the 4 dual actuator outputs.

  • Page 17: Display Boards

    Display boards MSA Master and MSA Slave boards have the option for front panel mounted display boards which indicate the Activated and Fault status of the board to which they are connected. The master display board also has an Isolate key switch and Isolated indicator which can be used to isolate all outputs.

  • Page 18: Aux 24V Dc Supply

    The stage 2 relay output can be disabled at access level 2 via the menus on the Sigma XT module. Released relay (Extinguishant Module) Released Relay on the extinguishant module will operate when the module is in the released condition.

  • Page 19: Aborted Relay (Extinguishant Module)

    E8 and those with a flashing dot indicate which options have been set. Extinguishant Module General Settings LINKS - The Sigma XT module contains 3 Links. CIE Serial Terminator – This terminates the RS485 comms from the control section Sigma_XT_M4.03...

  • Page 20: Language Selection

    (English) Extinguishant Output mode The Sigma XT module has two extinguishant outputs. These can be configured to operate together at the same time (common) or be configured as main and reserve outputs. The factory default setting is common.

  • Page 21: Reset Inhibit Time

    This setting allows for a time delay to be set from activation of the extinguishant module to operation of the extinguishant release output. This time may be between 0 and 30 seconds with a maximum of 5 second steps. The factory default time delay on the Sigma XT extinguishant modules is 30 seconds.

  • Page 22: Released Indication

    Enter Write Enable To change to steady second stage alarms, press . To save, slide the switch to the right. MUST be set to STEADY when using Shutdown Isolation Switch Released Indication It is possible to select whether the released indication on a module is operated at the same time as the extinguishant release outputs operate or by operation of a thermal fuse connected to the released thermal fuse input.

  • Page 23: Fault Ouput - Enable/Disable

    Under normal conditions and with all modules in Manual & Auto mode, control panels will have only the green, Power On LED lit on the Sigma XT detection part and on each of the display window extinguishing modules. With the closed, the display on the AUTO &...

  • Page 24: Alarm Module - Access Level 2

    Enter (Test zone 1). To put zone 1 into test mode, press the button on the Sigma XT detection part. The display will now show a flashing dot next to the and the yellow Test LED will be lit.

  • Page 25: Extinguishant Modules - Menu Access

    Turning the Extinguishant System Service Isolate key switch clockwise will isolate the extinguishant circuit, and a Service Isolated fault is generated and the LED is lit. Extinguishant modules – Menu Access Display Window With the open, all extinguishant modules will display: ACCESS LEVEL 2 ENTER FOR MENU Extinguishant release outputs.

  • Page 26: Select Reserve Solenoid Output (Configuration Option)

    Select Reserve Solenoid Output (Configuration Option) If the extinguishing module is configured for Main/Reserve solenoid operation (See section 15.2.1) then an additional menu option is given to select which output is used. SELECT RESERVE To turn on the Reserve Solenoid output, press the “+” button on the module EXTING.

  • Page 27: Sounder Fault

    Low pressure switch This is not used in a FirePro Aerosol Suppression System. The low-pressure switch input will be connected to a pressure switch on the extinguishant cylinder which will operate if the pressure in the cylinder falls below a set point.

  • Page 28: Manual Release

    This Panel is to be used in unmanned spaces only and can report events back to a FIP. The panel will support up to 4 FirePro generators. All circuits are monitored. The ®...

  • Page 29: Watchdog Reset

    BATT LOW - Illuminates when the system is running on batteries and the battery voltage is lower than 21V +/- 2% (the minimum battery voltage). COMMS FAULT - Indicates that communication has been lost with an extinguishant module. Check for comms fault at all extinguishant modules identify the source of the problem.

  • Page 30: Watchdog Reset Switch

    Address switch Extinguishant modules are connected to the serial bus of the Sigma XT detection part of the control panel and each module must be allocated an address between 1 and 7 using the binary coded DIP switch.

  • Page 31: Batteries

    11. Maintenance Sigma XT control panels do not require any specific maintenance, should the control panel become dirty it can be wiped over with a damp cloth and should then be dried with a dry, lint free cloth. Detergents or solvents should...
  • Page 32 250 mA max load. Max 3 modules Normal Resistance for FP Unit 2.8R Min allowable FP resistance across Sequential Activator – FirePro Units Nominal Short Circuit: 1R ± 25% 20 deg C temp to 40 deg C: 3R. When only Nominal Open Circuit: 13R +15% -5% 20 deg C one FP, a 2.2R 3W resistor in line.

  • Page 33: Commissioning Instructions And Record Of Configuration

    13. Commissioning Instructions and Record of Configuration When power is applied, if all connections are correct, only the green Power On and either the Automatic and Manual or Manual Only indicators should be lit. Use the Table below to record the configuration codes that have been set on the control panel for future reference.
  • Page 34 CONFIGURE Z6 FOR I.S BARRIER CONFIGURE Z7 FOR I.S BARRIER CONFIGURE Z8 FOR I.S BARRIER ZONE 1 SHORT CIRCUIT INDICATES ALARM Changes the trigger threshold of the zone so that the ZONE 2 SHORT CIRCUIT INDICATES ALARM control panel can be used on older systems that had no ZONE 3 SHORT CIRCUIT INDICATES ALARM short circuit monitoring.
  • Page 35 Sigma XT Ancillary Board (K588) Operation and Maintenance Manual Man-1095 Issue 06 November 2016...
  • Page 36 2. Safety and mounting....................3 3. Technical specification ....................4 4. Connecting to the circuit board ................... 5 5. Connection to relay contacts ..................6 7. Connection to Sigma XT panel ..................7 8. Operation ........................ 9 9. Power requirements ....................10 Man-1095_Sigmaxt_Ancillary_Board_06...
  • Page 37 Operation outside of these limits may render the equipment unreliable and/or unsafe. Mounting If not fitted inside a Sigma XT panel, the board should be mounted in a suitable enclosure such that it is protected from ingress of water, dust or foreign bodies.
  • Page 38 Cables should be connected using suitable, metal, shielded cable glands. All swarf and debris caused by drilling of additional cable entries must be cleared before power is applied. 3. Technical specification Table 1 - Electrical specifications Power supply 21 to 30 V DC Nominal 24V DC Maximum ripple voltage 200 millivolts...
  • Page 39 4. Connecting to the circuit board All connections for field wiring are to a row of terminals along the top of the circuit board. Shielded fire alarm cable such as FP200 and metal cable glands should be used for all connections to the board.
  • Page 40 Another 24V DC source may be used if this is more convenient. When using the Sigma XT status unit 24V or Auxiliary 24V outputs, the maximum current of the ancillary boards and status units connected must be taken into consideration. Ancillary board maximum current is 0.175A and status unit maximum current is 0.07A.
  • Page 41 7. Connection to Sigma XT panel If power is supplied locally to the ancillary board only two wires are required from the Sigma XT panel. Wiring can be standard fire alarm cable such as FP200 or shielded data cable. In either case, the shield of the cable must be securely bonded to the enclosure case.
  • Page 42 Switch on the write enable switch on the Sigma XT panel and press the processor reset switch on the Sigma XT panel PCB. The panel will display the address of the first ancillary board it finds on the seven segment LED display as show below.
  • Page 43 8. Operation 8.1 Fuse fail The ancillary board is fitted with a 1 Amp rated, self resetting electronic fuse. This fuse protects the electronics of the ancillary board and prevents any excessive loading of the power supply that is powering it.
  • Page 44 0V with respect to the 24V supply to signal a power fault from the additional power supply. When supplied from the Sigma XT panel, extra battery capacity of 0.6Ah per ancillary board connected should be allowed to give 24 Hour standby.
  • Page 45 Fire Alarm and System Warning Signs & Local Control Stations Installation and Operations Manual Serial Communications Type SIGMA-XT-FP Issue 3.6 October 2022...
  • Page 46 Contents Introduction............................3 Sign Locations ........................3 Local Control Stations (LCS) ....................3 External Devices ........................3 Cable Penetrations and Terminations ..................3 Mounting ..............................4 Internal Signs ......................... 4 External Signs ........................4 Power and Data Connections ........................5 Connecting Signs with RS485 Serial ..................

  • Page 47: Introduction

    Local Control Stations (LCS) LCS should be mounted firmly in an accessible location. The LCS is considered by the Sigma XT FIP to be a STATUS UNIT(S). Status units have monitored inputs to which remote Hold or Mode select switches can be connected.

  • Page 48: Mounting

    2. Mounting Internal Signs Remove Cover Internal circuit board. Mount using suitable fixings. Select cable entry point and prepare. Leave enough tail on cable to ensure the cable will not interfere with operation of sign. Weatherproof - External Signs Mount Sunshade. Remove cover Internal...

  • Page 49: Power And Data Connections

    3. Power and Data Connections Each status unit requires two cores for power and two cores for data transmission to and from the control panel. A four core cable may be used for these connections. All of these connections are polarity conscious and care should be taken to match the polarity with the corresponding terminals at the control panel.

  • Page 50: Connecting More Than 3 Signs

    3.1.2. Connecting more than 3 Signs For systems requiring more than 3 signs (or devices), wiring is as follows: Notes: • FIP MUST BE POWERED DOWN BEFORE ANY CHANGES TO SIGNS. • Connections for the first 3 signs or devices remains the same as the previous wiring diagram. •...

  • Page 51: Connection Of Local Control Station (Lcs)

    4. Connection of Local Control Station (LCS) Power and Data Connection The LCS can be installed in any order on the STATUS SERIAL (RS485) circuit, depending on its location. The LCS must be installed on the STATUS SERIAL (RS485) circuit. It cannot be used as a mimic device. More information is available on the Local Control Station Manual.

  • Page 52: Connection To Hold And Mode Inputs

    Connection to Hold and Mode inputs Status units have monitored inputs to which remote Hold or Mode select switches can be connected. These inputs are monitored for open and short circuit faults and therefore need to have a 470R 1W trigger resistor connected in series with the activating, normally open switches and 6K8 0.5W end of line monitoring resistors connected across the end of the cables.

  • Page 53: Processor And Watchdog Reset Switches

    Processor and Watchdog Reset Switches The status unit is controlled by a microprocessor, which will re-start itself and continue to run if it stops for any reason such as severe electrical interference such as an electrical storm. To ensure that the unit is not being subjected to continual, undue interference which may affect its proper operation, a CPU fault indicator is latched on and a fault condition signalled to the control panel.

  • Page 54: Setting Up The Devices

    5. Setting up the Devices Sign Circuit Board LCS Circuit Board Addressing Devices Before adding a device to the FIP’s programming, each device connected to the STATUS SERIAL (RS485) circuit must be given an individual address. The FIP MUST BE POWERED DOWN BEFORE ANY CHANGES TO DEVICES. IMPORTANT - Devices with the same address will cause an intermittent fault to be displayed.

  • Page 55: Adding Devices To Fip Programming

    6. Adding Devices to FIP Programming In order to add or remove devices from the FIP programming, the FIP must be in “ACCESS LEVEL 3”. The steps to enter “ACCESS LEVEL 3” are as follows: 1. Unlock and open the centre display window. This operates a read switch on the door that enables “ACCESS LEVEL 2”.

  • Page 56: Alternative Sign Arrangements

    7. Alternative Sign Arrangements Mimic Signs / Connecting more than 7 Signs In systems that require more than 7 signs, additional signs may be installed by connecting to the 24VDC TRIGGER terminals located in each sign. This allows connected signs to mimic the operation of a sign that is connected to the STATUS SERIAL (RS485) circuit.

  • Page 57: Alternative Arrangement Of Status Serial (Rs485) Circuit

    Alternative Arrangement of STATUS SERIAL (RS485) Circuit. The standard arrangement for installing signs is to have a single STATUS SERIAL (RS485) cable connecting the FIP to the signs, as per wiring diagram. However, it can be configured to have 2 separate cables for the RS485 circuit with the FIP effectively in the middle of the circuit rather than at one end.

  • Page 58: Troubleshooting

    8. Troubleshooting Output Unit refers to a SIGN, this fault will be OUTPUT UNIT X → • Address is the same as another device in the 485 circuit FAULT • Power has failed to the sign. • RS485 signal has failed to the sign. Status Unit refers to an LCS, this fault will be •...
  • Page 59 Fire Alarm Interface Vizulinx Product Manual *Man-1428* Man-1428 Rev.05...
  • Page 60 Safety Suppliers of articles for use at work are required under section 6 of the Health and Safety at Work act 1974 to ensure as reasonably as is practical that the article will be safe and without risk to health when properly used. An article is not regarded as properly used if it is used ‘without regard to any relevant information or advice’...
  • Page 61 Step 1 - Site/Location name ..........................22 Step 2 – Panel selection ..........................22 Common Fire and Fault ..........................22 Sigma CP/A-CP, Sigma XT/A-XT and Sigma XT+ ..................23 Syncro AS, Syncro, Elite, Elite RS and Hydrosense ..................23 Modbus Panel/Loop Mapping ........................23 Taktis (IP) and Taktis UL (IP) ........................
  • Page 62 Contents ii Section 5 Modules ..........................37 Application ...............................38 Distribution List ............................. 39 Driver ................................43 USB GSM SMS Stick Mode ......................... 43 Events ................................44 Custom Events ............................. 44 Fire Alarm Modules ............................45 Kentec Syncro/Elite Fire Alarm API ......................45 Kentec Taktis/Taktis UL Fire Alarm via IP ....................45 Hardware Module ............................46 GPIO Ports ..............................
  • Page 63 Contents iii Section 8 BACnet ..........................65 BACnet Connectivity ............................65 BACnet Configuration .............................65 BACnet Object ID Construction ........................66 BACnet Object ID List .............................66 Adding a BACnet License ..........................67 Section 9 Specifications ........................68 Additional Information .............................68 Contacting Kentec ............................68 Appendix A Behaviour Source/Events ....................

  • Page 64: Introduction

    Introduction 1 Section 1 Introduction Vizulinx is a standalone, low power module which adds expanded connectivity to Kentec fire alarm control and ex- tinguishant panels. The module reports fire alarm behaviour on site, over email, SMS and communicates with build- ing management systems (using BACNet/Modbus protocols).

  • Page 65: Overview

    Serial via PC Port Elite RS Serial via PC Port Sigma CP GPIO (General Purpose Inputs & Outputs) Sigma XT GPIO (General Purpose Inputs & Outputs) Sigma A-CP GPIO (General Purpose Inputs & Outputs) Sigma A-XT GPIO (General Purpose Inputs & Outputs) Man-1428 Rev.05...
  • Page 66 Overview 2 Product Connection Type Sigma XT+ GPIO (General Purpose Inputs & Outputs) Note: Vizulinx is compatible with all OEM branded variants of the above listed products. Man-1428 Rev.05 Vizulinx Product Manual...
  • Page 67 Overview 2 Figure 2-1 Overview of Vizulinx Module features MISC EXP B PSU FAULT INPUTS 9 -16 FIRE PANEL RS232 INPUTS 1 - 8 INTERFACE PORT Example header numbering format (For information). 1 2 3 4 5 External Dimensions: 106mm (W) X 90mm (H) X 32mm (D) Not to Scale.
  • Page 68 Overview 2 Figure 2-2 Overview of Vizulinx module housed - M2 88.1 385.8 Not to Scale. INTERNAL LAYOUT Description Power On/Power Fault status indicators. Knock-outs for cable entry. Upper enclosure fix- ing hole (x1). Power supply. Vizulinx module. Enclosure chassis. Space for batteries.
  • Page 69 Overview 2 Figure 2-3 Overview of Vizulinx module housed - AM3 106.6 369.4 Not to Scale. INTERNAL LAYOUT Description Power On/Power Fault status indicators. Enclosure earth block. Knock-outs for cable entry. Upper enclosure fixing holes (x2). Vizulinx module. Power supply. Enclosure chassis.

  • Page 70: Installation

    Installation 3 Section 3 Installation This section provides installation instructions for mounting the enclosure and connecting cables. This product should be installed, commissioned and maintained by trained service personnel in accordance with the terms outlined at the beginning of this document. General Installation Process 1.

  • Page 71: Enclosure Fixing Centres

    Installation 3 Enclosure Fixing Centres The following diagrams show enclosure fixing centres. Diagrams show the chassis and associated components removed. Verify enclosure type prior to commencing works. Figure 3-1 Vizulinx ‘M2’ housed module fixing centres 382.8 332.8 28.5 Man-1428 Rev.05 Vizulinx Product Manual...
  • Page 72 Installation 3 Figure 3-2 Vizulinx ‘AM3’ housed modules fixing centres 365.8 318.2 Man-1428 Rev.05 Vizulinx Product Manual...

  • Page 73: Taktis Fire Alarm Control Panel Connection

    Installation 3 Taktis Fire Alarm Control Panel Connection • Taktis EN • Taktis UL Communication between a Vizulinx module and a Taktis fire alarm control panel is by Ethernet IP. This can be a direct connection or via an IP network, to provide IP connectivity in the Taktis panel a Media Gateway card must be installed in slot ‘F’...

  • Page 74: Direct Ethernet Connection

    Installation 3 Direct Ethernet connection This requires an Ethernet patch cable between the Ethernet socket on the panels media gateway card and the Ether- net 1 socket “BMS interface” on the Vizulinx unit. The IP address of the media gateway card and the Vizulinx must be in the same range to be able to communicate, see the network configuration section of this manual on how to set the Vizulinx IP address.

  • Page 75: Ip Network Connection

    Installation 3 IP Network Connection Connection between Taktis and Vizulinx can be done across a Local Area Network (LAN) if required. Ethernet ca- bles will be required to connect the panel and the Vizulinx unit to the LAN. IP addresses of the panel and the Vizulinx must be set so the first 4 numbers match the network and the fourth number is the unique address for that device on the network.

  • Page 76: Syncro/Elite Fire Alarm Control Panel Connection

    Installation 3 Syncro/Elite Fire Alarm Control Panel Connection • Syncro/Syncro AS • Elite/Elite RS Vizulinx connection to these panels is by way of an RS232 serial communication link to the panels PC port. A 10 way ribbon cable is provided with an IDC connector at one end and 3 ferruled connections at the other end. The IDC connector plugs into the control panels PC port and the ferruled connections are terminated in the "FIRE PANEL RS232"...

  • Page 77: Conventional & Extinguishant Control Panel Connection

    Conventional & Extinguishant Control Panel Connection • Sigma CP (2,4 & 8 zone) conventional panels • Sigma XT 3 zone, single area extinguishant control panel • Sigma CP-A (2,4 & 8 zone) conventional panels (UL) • Sigma A-XT 3 zone, single area extinguishant control panel (UL) •...
  • Page 78 Installation 3 Sigma CP/ A-CP Sigma XT/ Wire GPIO Default Sigma XT+ (Up to 8 Zones A-XT Colour Input Settings (Up to 8 zones, 4 area) plus ancillary (Plus ancillary card) card) Inputs 9 -16 Not Used Zone 7 Fire...

  • Page 79: Connection Diagrams

    Installation 3 Connection Diagrams Figure 3-10 Typical default Sigma CP/CP-A connections Inputs Inputs Inputs 9 - 16 1 - 8 1 - 8 Common RS485 COINC FAULT FIRE RS485 RS485 RELAY RELAY RELAY FIRE FIRE FIRE FIRE FIRE FIRE FIRE FIRE Anciliary Board RS485...
  • Page 80 Installation 3 Figure 3-11 Typical default Sigma XT connections Inputs Inputs Inputs 1 - 8 1 - 8 9 - 16 RS485 24V DC DISAB HOLD EXTR RS485 RS485 FIRE FIRE FIRE MODE Anciliary Board Product Code: K588 24V DC...
  • Page 81 Installation 3 Figure 3-12 Sigma XT+ connections Refer to Figure 3-5 and the following: Area 1 - Yellow wire Area 2 - Green Inputs 9-16 Area 3 - Blue wire Area 4 - Violet wire C NO C NO 24V Power...

  • Page 82: Gsm & Wi-Fi Connectivity

    See Configuration section of this manual for instructions on how to set-up GSM and Wi-Fi requirements. Figure 3-13 Typical Vizulinx System Diagram Third-party GSM antenna (where required) Sigma CP/Sigma XT INPUTS 9 - 16 Vizulinx Syncro/Syncro AS RS232 Sigma CP/Sigma XT...

  • Page 83: Configuration

    Configuration 4 Section 4 Configuration This section covers setup connection and configuration of the Vizulinx module. Getting Started 1. Connect the Vizulinx module to the fire alarm system. 2. Power up Vizulinx (allow 15 seconds to boot). 3. Set your configuration PC static IP address to: 192.168.100.90 4.

  • Page 84: Ez Configuration

    Configuration 4 Note: Refer to the Settings section of this document for details on how to change login and password details. EZ Configuration The Vizulinx on first ever power up has no default configuration, once logged in the Vizulinx event screen is dis- played with the option “EZ Configuration”...

  • Page 85: Step 1 - Site/Location Name

    Configuration 4 Step 1 - Site/Location name Enter a site or location name to be able to identify the Vizulinx, this will appear in the header text of e-mails and can be shown in SMS text messages. This is important when receiving messages from multiple Vizulinx sites. Step 2 –...

  • Page 86: Sigma Cp/A-Cp, Sigma Xt/A-Xt And Sigma Xt

    Configuration 4 Sigma CP/A-CP, Sigma XT/A-XT and Sigma XT+ There is no configuration required for the conventional fire alarm panels when selected, the default allocation of GPIO to support connection of conventional panels will be done automatically. The screen will just display the panel selected with a short description as shown in the example below.

  • Page 87: Taktis (Ip) And Taktis Ul (Ip)

    Configuration 4 Taktis (IP) and Taktis UL (IP) Taktis panels communicate with Vizulinx using IP connectivity therefore when selecting a Taktis IP connection data will be required as shown below: Host IP or URL This is the IP address of the Media Gateway Card installed within the Taktis panel connected to the Vizulinx module. IP address of the Taktis panel can be obtained through its Access level 3 –...
  • Page 88 Configuration 4 Loop Offset Mapping If loop offsets are being used across a Taktis network then it is important to map these in Vizulinx so that Loop data in the messaging matches the network. Click on Edit mapping and the following screen will appear: Click on add and enter the panel number and the ID number of the first loop in the panel based on the offset.

  • Page 89: Step 3 - Messaging/Integrations

    Configuration 4 Step 3 – Messaging/Integrations Vizulinx can provide SMS and E-mail messaging using different methods as well as system integration through Mod- bus or BACnet. This step enables you to select the communication method or integration required for your system. Note: Multiple messaging and integrations can be set-up simultaneously on the same system however messaging and integration methods which use the same ports cannot be run simultaneously the following options cannot be run simultaneously: Modbus and BACnet, USB GSM SMS stick mode and USB GSM SMS/Data Hi-Link, E-mail...
  • Page 90 Configuration 4 Send alarms/faults to e-mail If an alarm or fault is activated on the Fire Panel, Vizulinx can send an e-mail message via the SMT server con- taining the alarm/fault information to a programmed e-mail address. To add an e-mail address,click “edit” and then “Add”, enter the e-mail address in the box: Enter additional e-mail addresses by clicking on “Add”.

  • Page 91: Textmagic (Sms)

    Configuration 4 TextMagic (SMS) This option enables the transmission of text messages via SMS (Simple Message Service) using the Text- Magic web service. To use this feature, you will require connection to a LAN network with internet access and a TextMagic account.

  • Page 92: Usb Gsm Sms/Data Hilink

    Configuration 4 Only a single piece of information can be entered for this feature: Signal level triggers These are the levels associated with the GSM network signal strength and it is recommended that these should be left at default settings of: Excellent -75, Good -85, OK -95, Marginal -120 Once the EZ config is complete the Vizulinx events screen will display an event for successful connection to the GSM network along with the current signal level.

  • Page 93: Zero Config Email Service

    Configuration 4 The network mode can be configured to determine the functionality of the Wi-Fi connectivity: Disable internet access This setting will prevent the USB Wi-Fi dongle from connecting to the internet and will operate thedongle in GSM SMS mode only allowing the sending of text messages but no e-mail. Enable internet access This setting connects the USB Wi-Fi dongle when there is no other alternative internet connection.

  • Page 94: Modbus Slave

    Configuration 4 Send alarms/faults to e-mail If an alarm or fault is activated on the Fire Panel, Vizulinx can send an e-mail message via the SMTP server containing the alarm/fault information to a programmed e-mail address. To add an e-mail address, click “edit” and then “Add”, enter the e-mail address in the box: Enter additional e-mail addresses by clicking on “Add”.

  • Page 95: Bacnet

    Configuration 4 BACnet Note: BACnet feature is only available when using a Taktis/Taktis UL control panel This feature enables the transmission of status information from the fire alarm system to Modbus compatible equipment. Detailed information regarding BACnet is provided in the BACnet section of this manual To setup the BACnet feature the following information needs to be entered: Upload NLE or XML configuration file BACnet requires the panel/network configuration to be able to allocate object ID’s this is obtained from LE2...

  • Page 96: Completion Of Ez Configuration

    Configuration 4 Broadcast unsolicited COV Support is provided for solicited and unsolicited COV (Change of Value) controlled by the tick box as shown in the screenshot above. Solicited (subscribed) COV – Vizulinx must send a subscribe request and wait for a response from the BACnet server before it can send its changes of value.

  • Page 97: Vizulinx (Events Screen)

    Configuration 4 Vizulinx (Events screen) The Vizulinx events screen is the main screen and it displays information on system status and active events. It will also indicate errors in functionality that can assist with diagnostics. The Vizulinx screen layout is shown below with descriptions for the important highlighted sections: Time and date On first connection to Vizulinx the time and date will be taken from the browser and will appear in red.

  • Page 98: Connection Status

    Configuration 4 Connection Status The status of various connections is shown by a coloured icon in the top right of the screen as shown above. Con- nections to the panel and GSM network will be displayed.If the Vizulinx has been configured to monitor connection to the internet (see Network Connectivity Checker in Modules section) the status of this connection will also be dis- played.

  • Page 99: Debug

    Configuration 4 Events The central panel of the Vizulinx main screen displays events that occur on the system. Any event that occurs on the Vizulinx system is shown here typical events are: - Events received from fire alarm panel/network i.e. fire and fault indications - Confirmation of messages sent i.e.

  • Page 100: Modules

    Modules 5 Section 5 Modules Recommendations are to configure the Vizulinx using the EZ configuration which will automatically install and setup the relevant modules as well as create default configurations. It is possible to add extra modules, remove modules and configure selected modules at any time through the “Modules” screen. This section details the functions of each available module and their configuration settings.

  • Page 101: Application

    Modules 5 Modules can be added by clicking on the “Add module” button which opens another showing the available modules: Available modules are sorted into groups to make them easy to identify this section details the modules associated with each group and the configuration settings. Application Modules in this group mainly relate to the control of rules/behaviours to provide our cause and effect actions asso- ciated with various options GPIO, Panel events, e-mail and SMS messaging.

  • Page 102: Distribution List

    Modules 5 The Applications listed previously are embedded App’s that control the linking of features with rules/behaviours, lim- ited config is available with these options. The configuration options with all the above Application modules are the same, click on any of the modules and the “Module configuration” will Appear in the top right corner of the screen the same three config settings will be listed for the Applications above –...
  • Page 103 Modules 5 Multiple distribution lists can be created, each list would require its own unique “Name” and unique “Join” and “Leave” keywords, see below for further details: Click on the distribution list module in the list and the module configuration data will Appear in the top right corner of the modules screen, as shown below: The module shows the current configuration for this module, to modify the configuration settings shown click on the “Configuration”...
  • Page 104 Modules 5 The available configuration settings are as follows: Name - This is user changeable text to describe the distribution list, default value is Alarm distribution list which is based on the default behaviours set based on the EZ configuration. Multiple distribution list modules can be added to the Vizulinx to suit different criteria, each list will require a different and can be configured with differ- entmobile numbers.
  • Page 105 Modules 5 Leave keyword - As well as being able to log their mobile number onto the distribution list users can also auto- matically remove their mobile number form the list by texting the leave keyword to the same mobile number used to join the list.

  • Page 106: Driver

    Modules 5 Driver This group of modules contains driver modules for hardware that is connected to the Vizulinx currently this contains two drivers for USB modem support. Important! Vizulinx is only provided with one USB port therefore will only support one USB modem, the relevant USB modem type should be selected as required.

  • Page 107: Events

    Modules 5 Events These modules control how events are handled when they are received by Vizulinx. Only one module is available in this section which is “Custom Events”. Custom Events Custom events can be used to funnel events from multiple modules into a common custom event that can be used as a trigger into other modules.

  • Page 108: Fire Alarm Modules

    Modules 5 Fire Alarm Modules These modules control the interface between the selected addressable fire alarm control panel and Vizulinx. Mod- ules are provided for support Syncro and Elite type panels as well as Taktis and Taktis UL panel variants. Note: Modules will work with branded variants of all Syncro and Taktis control panels Kentec Syncro/Elite Fire Alarm API This module supports the serial connection between a Syncro/Elite variant panel and Vizulinx.

  • Page 109: Hardware Module

    If a conventional fire panel was selected in the quick start wizard i.e. Sigma CP, Sigma XT etc. these pins will be pre-configured to specific panel functions with pre-configured ID names.

  • Page 110: Psu Monitor

    Modules 5 PSU Monitor This module is created as default following the EZ configuration and pre-configures pin 1 on expansion port A (PSU Fault) as a power supply fault input which can be used to monitor the fault output of an external PSU. Configuration option for this option are as follows: Name - Name is the description of the module i.e.

  • Page 111: Registry

    Modules 5 Registry The registry stores commonly used values that can be referred to when creating events, messages etc. Configura- tion options available for this feature are as follows: Name - Name is the description of the module i.e. what it does. The name can be changed to something more descriptive as required by clicking on the “Configuration”...

  • Page 112: Smtp Outbound Mail

    Modules 5 SMTP Outbound Mail This is the service module which controls the SMTP outbound mail feature of Vizulinx. If this messaging option is selected during EZ configuration this module settings will be automatically configured. This screen enables us to amend the settings associated with the module.

  • Page 113: Bacnet

    Modules 5 BACnet This is the service which controls the functionality of Vizulinx when configured as BACnet device. If Modbus is se- lected as an integration option during EZ configuration the settings for this function will automatically be configured. Available configuration settings are as follows: Name - Name is the description of the module i.e.

  • Page 114: Network Connectivity Checker

    Modules 5 Network Connectivity Checker The Vizulinx requires a connection to the internet to enable e-mail messaging either via LAN or USB GSM HiLink dongle. This module enables Vizulinx to monitor the internet connection to ensure it is active, it monitors the con- nection by polling a configured selection of websites.

  • Page 115: Behaviours

    Behaviours 6 Section 6 Behaviours The behaviours screen is accessed by clicking on the "Behaviours" tab in the header bar. Behaviours allow the user to define cause and effect fire alarm mapping from and to the connected devices/services. Each connected device/service creates and/or listens for events, these events can be linked to create a range of system operations - from sending a text message (SMS) to the building owners mobile phone when there is a fire alarm, to sending an email to the maintenance engineer whenever there's a fault.
  • Page 116 Behaviours 6 There are no identified limits to the number of behaviours that can be created, to create a behaviour the process is as follows: Click the “Add new behaviour” button to add the new behaviour: Complete the Source/Event/Destination/Action as appropriate by selecting options from the drop-down menus. Click on “Save changes”...

  • Page 117: Customising Behaviours

    Behaviours 6 Customising Behaviours Behaviours can be further enhanced by adding filters to the source and event data and customising the destination and action settings. Adding a Behaviour Filter A filter adds more control over a behaviour to subsequently provide more control over the functionality of the Vizulinx system.

  • Page 118: Customising Behaviour Settings

    Behaviours 6 And a filter: Our behaviour with the added filter now works as follows – Any alarm that appears in the custom events will be fil- tered and only alarms that contain the value “Zone 1” in the payload will be sent to the configured e-mail address. Customising Behaviour Settings Each behaviour has its own individual settings which can be customised to enhance the performance of the system, this allows customisation of the information sent/displayed when the behaviour is activated i.e.
  • Page 119 Behaviours 6 There are three sections which make up the rule configuration – Output field, Action and Value. Output field The output field relates to the information type i.e. in this example “To email address”, “Subject” and “Body text” that make up the messaging To email address - This is the e-mail address(es) we want to send the information associated with thisrule to.
  • Page 120 Behaviours 6 Map from - Where “Pass thru” sends all data provided from the fire panelassociated with the event. Map from uses the data from the panel but allows us to select what information we wish to include. Depending on the source selected the options available to “Map from”...

  • Page 121: Customising Behaviour Names

    Behaviours 6 To select one of the bits of data to include in your message click on the button and itwill appear in {{}} in the selected box. The data will be sent in the message in order itis shown in the box. The message format for the selection in the screenshot examplewill be as follows: BACNET TEST PANEL ZONE 10...

  • Page 122: Modbus

    Modbus 7 Section 7 Modbus Vizulinx can be configured as a Modbus slave device allowing it to communicate various status conditions to other Modbus devices using Modbus TCP/IP. Modbus enables the fire alarm control panels connected to Vizulinx to inte- grate with other equipment such BMS (Building Management Systems), Plant control equipment etc Modbus Connectivity Vizulinx connects to Modbus using its Ethernet 1 (Eth 1) port, the port IP settings will need to be configured to match...

  • Page 123: Modbus Mapping For Addressable Systems

    Modbus 7 Syncro/Syncro AS Modbus system connectivity SYNCRO/AS VIZULINX LAPTOP SERIAL PORT PORT IP CONNECTION MODBUS SYSTEM Vizulinx as a Modbus device does not have a specific Modbus address ID, Vizulinx is designed to listen to the MOD- BUS port and responds to any request from the Modbus system using the same ID used in the request in the reply packet.

  • Page 124: Modbus Addresses 1-500

    Modbus 7 Modbus Addresses 1-500 These Modbus addresses are allocated to the reporting of zone status with the addresses linked in zone sequence i.e. Address 1 = Zone 1, Address 2 = Zone 2 etc. Each zone address has an associated flag shown in the table above which indicates the specific status of the zone. There are nine states that the zone can be in as shown in the table e.g.

  • Page 125: Mapping The Panels/Loops

    Modbus 7 Select the panel number and loop number you wish to associate with that block of addresses, the panel loop selec- tion does not need to be entered in sequence, any panel number and loop number can be allocated to any block of addresses this make is it easier to add additional panels and loops without affecting the existing Modbus address allocation.

  • Page 126: Adding A Modbus License

    Modbus 7 Adding a Modbus License As already mentioned the 1000 x 16 bit addresses provided as standard in the Vizulinx unit can be increased by purchasing an upgrade license. Each license will enable an additional 1000 x 16 bit addresses up to a maximum of 10000 addresses.

  • Page 127: Modbus Mapping For Discrete Inputs

    GPIO input 1 and the last item on the list relates to GPIO input 16 e.g. activation of a Zone 2 Fire on the Sigma XT/A-XT will activate GPIO input 6. The names and sequence of names can be re-configured as required by clicking on the configuration button which opens the configuration window.

  • Page 128: Bacnet

    BACnet 8 Section 8 BACnet Vizulinx can provide BACnet IP communications to third party systems such as BMS for Taktis Systems and net- works. Kentec have unique BACnet vendor ID which identifies the Vizulinx on BACnet as a Kentec product. BACnet Connectivity BACnet communicates to Vizulinx using its Ethernet 1 (Eth 1) port, the port IP settings will need to be configured to match the BACnet system.

  • Page 129: Bacnet Object Id Construction

    BACnet 8 BACnet Object ID Construction The following table shows how BACnet object IDs are constructed: Nibble 1/2 5 Panel Not used Panel 0 - 127 0x3ff Zone Zone (0-2000) 0x3fe Sub-address Device Panel (0-127) (Loop 0-16) Device (0-255) (0-6) Flag EN Panels Fire...

  • Page 130: Adding A Bacnet License

    BACnet 8 Adding a BACnet License As already mentioned the 500 BACnet object IDs provided as standard in the Vizulinx unit can be increased by purchasing an upgrade license. Each license will enable an additional 500 BACnet object IDs. To add a BACnet license a license code will be required which is purchased from Kentec Electronics. To obtain the license code you must provide the Vizulinx hardware code to Kentec, you will then be provided with a license code which can only be used on the Vizulinx with the hardware code you supplied.

  • Page 131: Specifications

    Specifications 9 Section 9 Specifications Equipment Product Code Description Colour Size WxHxD (mm) K85000 Vizulinx - Module only 106 x 90 x 32 K85000 M2 Vizulinx - Housed version (M2) Powder coat - Grey (BS-00-A-05) 385 x 310 x 90 K85110 AM3 Vizulinx - Housed version (AM3) 110V AC Powder coat Red (RAL 3002)
  • Page 132 Specifications 9 ©2018 Kentec Electronics Ltd. All rights reserved. Man-1428 Rev.05 Vizulinx Product Manual...

  • Page 133: Behaviour Source/Events

    Behaviour Source/Events A Appendix A Behaviour Source/Events This table shows the possible behaviour triggers based on source and event options. The source and event triggers available at any time will be dependant upon the Vizulinx configuration. Source Event Comments Custom Events Alarm Will trigger a behaviour when a custom event behaviour relating to an alarm is...
  • Page 134 Behaviour Source/Events A Continued. Source Event Comments PSU Monitor Pin changed state Will trigger a behaviour when the GPIO pin used to monitor the PSU fault out- Pin low put changes state Pin high Regular expression parser Parser messaged Will trigger a behaviour when Parser is messaged Registry Registry item updated...

  • Page 135: Behaviour Destination/Actions

    Behaviour Source/Events A Behaviour destination/actions The sources and event behaviour listed in the previous table can be paired with the following possible Destination/ Actions to create a complete behaviour. The available destination/actions available at any time will depend on the configuration of the Vizulinx features and services.

  • Page 136: Bacnet Protocol Implementation Conformance Statement

    BACnet Protocol Implementation Conformance Statement B Appendix B BACnet Protocol Implementation Conformance Statement Date: 06/05/2020 Vendor Name: South Midlands Communications Ltd Product Name: Vizulinx Product Model Number: n/a Application Software Version: 1.0.16 onwards Firmware Revision: 1.0.16 onwards BACnet Protocol Revision: 1.2 Product Description This products maps generic fire alarm statuses to BACnet objects.

  • Page 137: Device Address Binding

    BACnet Protocol Implementation Conformance Statement B Device Address Binding Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other devices.) Networking Options √ Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc. Annex H, BACnet Tunneling Router over IP √...
  • Page 138 Reference Manual 00909-0200-4975, Rev AB July 2022 ™ ™ Spectrex SharpEye 40/40C and D Series Flame Detectors ® Modbus Manager Manual...
  • Page 139 Legal notice The device described in this document is the property of Emerson. No part of the hardware, software, or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without prior written permission from Emerson.
  • Page 140 Abbreviation or acronym Definition American wire gauge Built-in test Electromagnetic compatibility End of line Field of view ® HART Highway addressable remote transducer - communication protocol Immune at any distance IECEx International Electrotechnical Commission Explosion Isopropyl alcohol Infrared Type of jet fuel Latching Refers to relays remaining in the ON state even after the ON condition has been removed.
  • Page 142 Reference Manual Contents 00909-0200-4975 July 2022 Contents Chapter 1 Introduction......................7 1.1 Product overview.........................7 1.2 Minimum requirements....................... 7 Chapter 2 Initial setup........................9 2.1 Download software........................9 2.2 Running the software........................9 2.3 Connect computer to the device....................9 2.4 Connect device to harness cable....................10 2.5 Set up USB adapter........................
  • Page 143 Contents Reference Manual July 2022 00909-0200-4975 Spectrex.net...

  • Page 144: Chapter 1 Introduction

    Reference Manual Introduction 00909-0200-4975 July 2022 Introduction Product overview ® Modbus Manager is a customized software based on Modbus protocol over RS485, used to configure the device to suit the customer needs, perform firmware upgrades and provide troubleshooting information and functionality. This guide describes the Modbus Manager and provides instructions on how to install, operate, and maintain the software.
  • Page 145 Introduction Reference Manual July 2022 00909-0200-4975 Spectrex.net...

  • Page 146: Chapter 2 Initial Setup

    Reference Manual Initial setup 00909-0200-4975 July 2022 Initial setup Download software ® To download the Modbus Manager, follow these steps: Procedure 1. Go to Spectrex.net. 2. Using the site navigation, go to the relevant product page 3. Scroll down to Documents and Drawings. 4.

  • Page 147: Connect Device To Harness Cable

    Initial setup Reference Manual July 2022 00909-0200-4975 Connect device to harness cable Procedure 1. Connect one side of the cable to detector Terminal 13 for RS-485 (+). 2. Connect the other side of the cable to detector Terminal 14 for RS-485 (-). Set up USB adapter CAUTION Check that the D-connector adapter wiring is similar to the wiring shown (if not, adjust the...
  • Page 148 Reference Manual Initial setup 00909-0200-4975 July 2022 2. Select Device Manager. 3. Select Ports. 4. Note to which COM the USB Serial Port is connected (this will vary among computers). 5. From the Comport dropdown, select the relevant COM port. 6.

  • Page 149: Connecting The Device

    Initial setup Reference Manual July 2022 00909-0200-4975 Connecting the device The device must be connected to power and the RS485 should be connected to the terminals according to the following table: Function Wire color Terminal RS485 (+) RS485 (-) Black Spectrex.net...

  • Page 150: Chapter 3 Operation

    Reference Manual Operation 00909-0200-4975 July 2022 Operation Screen overview Main screen The left menu and top bar display on every screen. The left menu displays the brand name and navigation controls; the top bar displays device information. A. Device brand B.
  • Page 151 Operation Reference Manual July 2022 00909-0200-4975 Top bar The top bar contains information about the connected detector and appears on every screen. A. Current detector address B. Detector serial number C. Full detector model code D. Communication status E. Detector status F.

  • Page 152: Perform Manual Bit

    Reference Manual Operation 00909-0200-4975 July 2022 Left menu The left menu contains navigation information and the main sections are viewed on each page. Subitems of the selected item are visible. A. Device information B. Device status C. Device setup D. Device and software version Perform manual BIT Procedure In the Test Detector pane, click the Built-In Test (BIT) button.

  • Page 153: Assign Address To Device

    Operation Reference Manual July 2022 00909-0200-4975 Assign address to device Procedure 1. In the Address pane, select the New Address for the Detector radio button. 2. Use the Address dropdown to select the required address or enter the address in the dropdown text box.

  • Page 154: Locating The Detector Address

    Reference Manual Operation 00909-0200-4975 July 2022 Note Alternatively, the up and down arrows can be used to switch the address without clicking the Switch button. Locating the detector address If the detector address is not shown in the top menu or is not communicating, its address can be located by clicking the Locate button within the Locate Detector Address pane.

  • Page 155: Trend Screen

    Operation Reference Manual July 2022 00909-0200-4975 A. Shows current input voltage (in volts) B. Shows current internal temperature (in degrees C or F according to setup) C. Shows current 4-20 analog output (in mA) D. Activates manual BIT Trend screen This screen shows the input voltage, internal temperature, and analog output live trends according to the selected timeframe.

  • Page 156: Recording Screen

    Reference Manual Operation 00909-0200-4975 July 2022 A. Displays all recorded data according to timeframe settings B. Exports all data as ".txt" file C. Opens timeframe settings The timeframe settings can be adjusted by selecting the required values and clicking the Reset button.
  • Page 157 Operation Reference Manual July 2022 00909-0200-4975 Note The Fast mode provides recording at the best possible polling rate – around three records per second. 2. Enter a comment and click the Insert button. 3. To end the recording, click the Stop button. 4.

  • Page 158: Detector Setup Tab

    Reference Manual Operation 00909-0200-4975 July 2022 Procedure To adjust number of records shown, change the number in the Get field and then press the Get button. A. Displays records according to selection in the records up to current position field B.
  • Page 159 Operation Reference Manual July 2022 00909-0200-4975 A. Detector configurable settings B. BIT settings C. Accessory relay options D. Detection options E. Lock option F. 4-20 settings G. Click to save any changes made, becomes clickable once any setting has been changed Note Any unavailable options will be grayed out depending on specific detector model connected.
  • Page 160 Reference Manual Operation 00909-0200-4975 July 2022 Heater on Temperature at which the demister is activated, if the heat mode temperature is set to Auto. Default: 5 °C Enable alarm latch When selected, the alarm remains on even when the signal abates. Default: Not enabled 3.9.2 BIT settings...
  • Page 161 Operation Reference Manual July 2022 00909-0200-4975 3.9.3 Accessory relay options These options may be changed as described. Activate When the detector’s status is warning, the accessory relay is accessory relay activated. on warning Default: Not enabled Accessory relay When selected, the accessory relay is activated. as EOL Default: Not enabled Accessory relay...
  • Page 162 Reference Manual Operation 00909-0200-4975 July 2022 3.9.5 Lock option ® Modbus Manager offers password protection for various maintenance and administrative actions. Not locked No password required to change detector settings or perform BIT Locked Password required to change detector settings; opens dialog box for setting passwords Change To change the password, the previous password must be entered.
  • Page 163 Operation Reference Manual July 2022 00909-0200-4975 Default: 4mA Normal 4 or 5mA (must be ≥ the FOV value) Default: 4mA Pre-alarm warning 13 – 16mA (must be lower than alarm value) Default: 16mA Alarm 15 – 20mA (must be higher than warning) Default: 20mA Once values are entered, click the OK button to update the setup.

  • Page 164: Chapter 4 Maintenance

    Reference Manual Maintenance 00909-0200-4975 July 2022 Maintenance Miscellaneous functions This screen provides access to various maintenance functions. A. Perform firmware update with provided file B. Upload parameters file C. Detector reset D. Fix 4-20 values E. Download parameters file Update firmware Prerequisites Firmware update file will be provided.

  • Page 165: Set Fixed Current 4-20 Values

    Maintenance Reference Manual July 2022 00909-0200-4975 Where required, this file will be provided by the manufacturer. Set fixed current 4-20 values 4-20mA is factory calibrated with controlled and certified equipment; there is no need for additional calibration. This process allows fixing of multimeter values to 4mA and 20mA fixed values.

  • Page 166: Parameter Download

    Reference Manual Maintenance 00909-0200-4975 July 2022 11. Click the Burn button to save the changes. Parameter download There is an optional feature to download device parameter files incorporated into one ® folder located in the Modbus Manager directory. This folder is saved to the subfolder with the detector serial number included in the title.
  • Page 167 Maintenance Reference Manual July 2022 00909-0200-4975 A. Enter time-limited password received from the manufacturer to enter tech-mode. B. Enter time-limited password received from the manufacturer to reset password. Note If the application is closed after entering the password, a new password is required to re- enter tech mode or reset password.

  • Page 168: Appendix A Reference Data

    Reference Manual Reference data 00909-0200-4975 July 2022 Reference data Ordering information, specifications, and dimensional drawings To view current SharpEye 40/40 Series ordering information, specifications, and dimensional drawings, follow these steps: Procedure 1. Go to Spectrex.net/en-us/flame-gas-detectors-flame-detectors-40-40-series. 2. Select the appropriate product. 3.
  • Page 169 Reference data Reference Manual July 2022 00909-0200-4975 Status Description 4-20mA Analog Fault Test rate output output relay indicator Restore from wrong Open After wrong voltage blinking voltage orange Wrong 5 VOLT Open Every 30msec blinking orange Wrong 9 VOLT Open Every 30msec blinking orange...
  • Page 170 Reference Manual Reference data 00909-0200-4975 July 2022 Status Description 4-20mA Analog Fault Test rate output output relay indicator IR signal Amp stuck at Open Every BIT one failure blinking orange Failure SPI COM with Open Every 30msec blinking orange AFE stuck at 1 Open Every 30msec blinking...
  • Page 171 Reference data Reference Manual July 2022 00909-0200-4975 Status Description 4-20mA Analog Fault Test rate output output relay indicator Wrong ambient Close Every 30msec temperature blinking orange 4-20mA circuit failure 0 mA Close Every 30msec blinking orange Fault relay failure Open Every 30msec blinking orange...
  • Page 172 Reference Manual Reference data 00909-0200-4975 July 2022 Status Description 4-20mA Analog Fault Test rate output output relay indicator Pre-alarm Close Every 30msec blinking green Alarm delay 16mA Close Every 30msec blinking red Warning 16mA Close Every 30msec blinking red Alarm 20mA Close Constant...
  • Page 173 Reference data Reference Manual July 2022 00909-0200-4975 Status Description 4-20mA Analog Fault Test rate output output relay indicator Wrong vin Open Every 30msec blinking orange Program memory CRC Open At start-up failure blinking orange Faulty parameters Open At start-up or blinking upon setup/ orange...
  • Page 174 Reference Manual Reference data 00909-0200-4975 July 2022 Status Description 4-20mA Analog Fault Test rate output output relay indicator UV pulse stuck at 1 Open Every 30msec blinking orange Digi pot failure Open Every 30msec blinking orange UV tube broken/ Open Every 30msec constant UV pulse blinking...
  • Page 175 Reference data Reference Manual July 2022 00909-0200-4975 Status Description 4-20mA Analog Fault Test rate output output relay indicator UV LED failure Open Every BIT blinking orange FOV failure Close Every 30msec blinking green Missed ADC reading Close Every 30msec blinking green Analog output failure Close...
  • Page 176 Reference Manual Reference data 00909-0200-4975 July 2022 Status Description 4-20mA Analog Fault Test rate output output relay indicator Anti-flare Close Every 30msec blinking green Explosion 20mA Close Constant Every 0.23msec SharpEye 40/40...
  • Page 177 Reference data Reference Manual July 2022 00909-0200-4975 Spectrex.net...

  • Page 178: Appendix B Configurable Options

    Reference Manual Configurable options 00909-0200-4975 July 2022 Configurable options SharpEye 40/40C options This section contains values for configurable options. Asterisks (*) indicate default values unless otherwise noted. Option SharpEye model 40/40C-I 40/40C-M 40/40C-LB 40/40C-L4B Detection sensitivity • • • • •...
  • Page 179 Configurable options Reference Manual July 2022 00909-0200-4975 Option SharpEye model 40/40C-I 40/40C-M 40/40C-LB 40/40C-L4B Alarm relay on successful • manual BIT • Accessory relay on successful • manual BIT • Post manual BIT indication 3–60 duration (in seconds) Default value: 3 Enable automatic BIT •...

  • Page 180: Sharpeye 40/40D Options

    Reference Manual Configurable options 00909-0200-4975 July 2022 SharpEye 40/40D options This section contains values for configurable options. Asterisks (*) indicate default values unless otherwise noted. Option SharpEye model 40/40D-I 40/40D-M 40/40D-LB 40/40D-L4B Detection sensitivity • • • • • 30m* •...
  • Page 181 Configurable options Reference Manual July 2022 00909-0200-4975 Option SharpEye model 40/40D-I 40/40D-M 40/40D-LB 40/40D-L4B Accessory relay on successful • manual BIT • Post manual BIT indication 3–60 duration (in seconds) Default value: 3 Enable automatic BIT • Yes* • Fault count 0–10 Default value: 3 Bit interval (in minutes)
  • Page 182 Reference Manual Configurable options 00909-0200-4975 July 2022 Option SharpEye model 40/40D-I 40/40D-M 40/40D-LB 40/40D-L4B • • • SharpEye 40/40...
  • Page 183 00909-0200-4975 Rev. AB 2022 For more information: Emerson.com © 2022 Emerson. All rights reserved. Spectrex is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners.
  • Page 184 Reference Manual 00909-0100-4975, Rev AB December 2021 ™ Spectrex SharpEye 40/40C and 40/40D Series Flame Detectors...
  • Page 185 Legal notice The device described in this document is the property of Emerson. No part of the hardware, software, or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without prior written permission from Emerson.
  • Page 186 Abbreviation or acronym Definition American wire gauge Built-in test Electromagnetic compatibility End of line Field of view ® HART Highway addressable remote transducer - communication protocol Immune at any distance IECEx International Electrotechnical Commission Explosion Isopropyl alcohol Infrared Type of jet fuel Latching Refers to relays remaining in the ON state even after the ON condition has been removed.
  • Page 188 Reference Manual Contents 00909-0100-4975 December 2021 Contents Chapter 1 Introduction......................7 1.1 Product overview.........................7 1.2 Models............................7 Chapter 2 Installation.......................11 2.1 Installation guidelines........................11 2.2 Preparation for use........................11 2.3 Attach detector to tilt mount.....................15 2.4 Open the back cover........................16 2.5 Wire terminals and ground cable....................16 2.6 Install the protective cover......................21 2.7 Aim the detector........................22 2.8 Changing default detector settings ...................
  • Page 189 Contents Reference Manual December 2021 00909-0100-4975 A.2 Product certifications and installation drawings.................41 Appendix B FM fuel test responses ..................... 43 Appendix C Immunity to false alarm sources................47 Spectrex.net...

  • Page 190: Chapter 1 Introduction

    Reference Manual Introduction 00909-0100-4975 December 2021 Introduction Product overview The SharpEye 40/40 series is based on proven Spectrex technologies, including triple infrared (IR3) and ultraviolet infrared (UV/IR). The SharpEye 40/40 series features ™ QuadSense technology, providing the fastest response to fire, longest distance detection, and revolutionary UV/IR technology, coupled with superior immunity to false alarms, functioning in harsh conditions with unparalleled reliability and durability.
  • Page 191 Introduction Reference Manual December 2021 00909-0100-4975 SharpEye 40/40C-L4B The SharpEye 40/40C-L4B is a dual spectrum UV/IR flame detector designed to provide fast detection in under five seconds of hydrocarbon-based fuel and gas fires. SharpEye 40/40D-I The SharpEye 40/40D-I, an ultra-fast multispectrum Quad-sense IR3 flame detector, provides superior, longest distance detection of hydrocarbon fires at up to 295.3 ft (90 m), exceptional ultra-fast detection in under 50 msec, and unparalleled reliability.
  • Page 192 Reference Manual Introduction 00909-0100-4975 December 2021 CAUTION If the product is used outside of specified limits, this voids the product certification, and our company is not responsible for any incurred warranty expense. Do not open this product, except for the terminal compartment as listed in this document, under any circumstances.
  • Page 193 Introduction Reference Manual December 2021 00909-0100-4975 Spectrex.net...

  • Page 194: Chapter 2 Installation

    Reference Manual Installation 00909-0100-4975 December 2021 Installation Installation guidelines Installation should comply with the National Fire Protection Association (NFPA) 72E or any other local and international regulations and standards, as applicable to flame detectors and installation of Ex approved products. To ensure optimal performance and efficient installation, consider the following guidelines.
  • Page 195 Installation Reference Manual December 2021 00909-0100-4975 Table 2-1: Required tools Tool Function Hex key 1.5 mm Fasten back cover security screw. Hex key 6 mm Adjust the tilt mount. Hex key 10 mm Affix the detector to the tilt mount. Hex key ⅛-in Attach protective cover to detector.
  • Page 196 Reference Manual Installation 00909-0100-4975 December 2021 Figure 2-2: Vertical Field of View for SharpEye 40/40C-I, C-LB, C-L4B, D-I, D-LB, and D- • +50 ° (down) • -45 ° (up) Gasoline For SharpEye 40/40C-M and D-M • Horizontal: 80 ° • Vertical: 80 °...
  • Page 197 Installation Reference Manual December 2021 00909-0100-4975 Figure 2-3: Vertical and horizontal field of view for gasoline Hydrogen For SharpEye 40/40C-M and D-M • Horizontal: 90° • Vertical: 90° Figure 2-4: Horizontal field of view for hydrogen Spectrex.net...

  • Page 198: Attach Detector To Tilt Mount

    Reference Manual Installation 00909-0100-4975 December 2021 Figure 2-5: Vertical field of view for hydrogen Attach detector to tilt mount Procedure 1. Unpack the detector. 2. Insert location pins on the tilt mount into the openings on detector housing. 3. Thread the holding screw and tighten it. SharpEye 40/40...

  • Page 199: Open The

    Installation Reference Manual December 2021 00909-0100-4975 Note To change the detector field of view, release the horizontal and vertical locking screws. 4. Point the detector toward the protected area and ensure the view of the area is unobstructed. 5. Secure the detector in that position by tightening the locking screws on the tilt mount.
  • Page 200 Reference Manual Installation 00909-0100-4975 December 2021 Procedure 1. Connect the terminals according to Table 2-2. The terminal details are also on the inside back cover. Figure 2-6: Terminal box SharpEye 40/40...
  • Page 201 Installation Reference Manual December 2021 00909-0100-4975 Table 2-2: Terminal box Terminal Function 24 Vdc (+) 24 Vdc (-) External built-in test (BIT) switch Fault relay - normally open Fault relay Fault relay - normally closed Alarm relay - normally open Alarm relay Alarm relay - normally closed 0-20 mA (+)
  • Page 202 Reference Manual Installation 00909-0100-4975 December 2021 Figure 2-7: Typical wiring for four-wire controllers A. Controller B. First detector C. Second detector D. Last detector E. Power supply F. Alarm loop G. End of line Figure 2-8: Non-isolated sink (three wires) A.
  • Page 203 Installation Reference Manual December 2021 00909-0100-4975 Figure 2-9: Sink four-wire A. Detector B. Controller C. Input power: 18 to 32 Vdc D. Return E. 0-20 mA meter Figure 2-10: Source three-wire A. Detector B. Controller C. Input power: 18-32 Vdc D.

  • Page 204: Install The Protective Cover

    Reference Manual Installation 00909-0100-4975 December 2021 4. Close the terminal compartment by screwing the back cover on to the housing. 5. Tighten the back cover security screw. Figure 2-11: Closing security screw A. Back cover security screw B. Ground cable connection point 6.

  • Page 205: Aim The Detector

    Installation Reference Manual December 2021 00909-0100-4975 Procedure 1. Place the protective cover on top of the detector. 2. Secure the protective cover by tightening the screw. Note When installing the stainless steel protective cover, the same installation instructions apply. Aim the detector Aim the detector toward the center of the detection zone and make sure you have a completely unobstructed view of the protected area.
  • Page 206 Reference Manual Installation 00909-0100-4975 December 2021 • Alarm latch • Field of view integrity indication Refer to the Spectrex SharpEye 40/40C and D Series Flame Detectors Modbus Manager Manual or the Spectrex SharpEye 40/40C and D Series Flame Detectors HART Manual for instructions on changing these settings.
  • Page 207 Installation Reference Manual December 2021 00909-0100-4975 Spectrex.net...

  • Page 208: Chapter 3 Operation

    Reference Manual Operation 00909-0100-4975 December 2021 Operation Power up the detector Procedure After connecting the detector to power, wait up to 60 seconds for the detector to completed the initial start-up procedure. Note Turning on the detector initiates the following sequence of events: a.
  • Page 209 Operation Reference Manual December 2021 00909-0100-4975 Table 3-2: Flame Simulator Reference Manuals Flame simulator Reference manual Spectrex FS-1100 TM380002 Spectrex FS-1200 TM380102 Spectrex FS-1400 TM380302 Spectrex.net...

  • Page 210: Chapter 4 Initial Setup

    Reference Manual Initial setup 00909-0100-4975 December 2021 Initial setup Continuous feature test The detector is supplied with default settings, including a continuous feature test. To change these settings, refer to the Spectrex SharpEye 40/40C and D Series Flame ® Detectors Modbus Manager Manual.
  • Page 211 Initial setup Reference Manual December 2021 00909-0100-4975 • Electronic circuitry The detector can be set to perform the BIT in the following modes: • Automatically and manually • Manually only BIT operation The BIT is intended to check optical integrity and electronic circuitry. The detector's status remains unchanged if the result of a BIT is the same as the current status (Normal or BIT Fault).

  • Page 212: Chapter 5 Maintenance

    Reference Manual Maintenance 00909-0100-4975 December 2021 Maintenance Keeping maintenance records Record all maintenance operations performed on a detector in accordance with site guidance and requirements. Clean the detector Procedure 1. Disconnect power from the flame detector. 2. Wipe the detector housing with clean water and a damp cloth. CAUTION Do not use a brush or sharp tools.
  • Page 213 Maintenance Reference Manual December 2021 00909-0100-4975 Spectrex.net...

  • Page 214: Chapter 6 Troubleshooting

    Reference Manual Troubleshooting 00909-0100-4975 December 2021 Troubleshooting Light-emitting diode (LED) is off, fault relay is open, 0-20 mA shows 0 mA, analog voltage output is 0 V Note Analog voltage output applies to SharpEye 40/40D models only. Potential cause No power to the unit. Recommended actions 1.

  • Page 215: Light-Emitting Diode (Led) Constantly Red, Alarm Relay Energized, 0-20 Ma Indicates Alarm

    Troubleshooting Reference Manual December 2021 00909-0100-4975 Recommended action Ensure the detector window and reflector mirror are clean. Potential cause Faulty detector. Recommended action Re-power the detector. Light-emitting diode (LED) constantly red, alarm relay energized, 0-20 mA indicates alarm Potential cause Existing alarm condition.

  • Page 216: Chapter 7 Specifications

    Reference Manual Specifications 00909-0100-4975 December 2021 Specifications Technical specifications Spectral response SharpEye 40/40C-I Four infrared (IR) bands between 4 μm and 5 μm SharpEye 40/40C-M Four IR bands between 2 μm and 5 μm SharpEye 40/40C-LB Ultraviolet (UV): 0.185 - 0.260 μm IR: 2.5-3.0 μm SharpEye 40/40C-L4B UV: 0.185 - 0.260 μm...
  • Page 217 Specifications Reference Manual December 2021 00909-0100-4975 Table 7-1: SharpEye 40/40C Models (continued) Fuel 40/40C-I 40/40C-M 40/40C-LB 40/40C-L4B Magnesium 16.4 ft (5 m) 33 ft (10 m) alloy Gun powder 141.1 ft (43 m) 32.8 ft (10 m) 91.9 ft (28 m) Fireworks 23.0 ft (7 m) 5.25 ft (1.6 m)
  • Page 218 Reference Manual Specifications 00909-0100-4975 December 2021 Table 7-2: SharpEye 40/40D Models (continued) Fuel SharpEye SharpEye SharpEye SharpEye 40/40D-I 40/40D-M 40/40D-LB 40/40D-L4B Paper 112 ft (34 m) 10 ft (3 m) Hydrogen 164 ft (50 m) 70 ft (21 m) Magnesium 33 ft (10 m) alloy Gun powder...
  • Page 219 Specifications Reference Manual December 2021 00909-0100-4975 Ultra fast response time Table 7-5: SharpEye 40/40C Models Spectrex 40/40C-I Spectrex 40/40C-M Spectrex 40/40C-LB Spectrex 40/40C-L4B Table 7-6: SharpEye 40/40D Models SharpEye 40/40D-I SharpEye 40/40D-M SharpEye 40/40D-LB SharpEye 40/40D-L4B Typically <1 sec at 100 ft (30 m) 20 msec for flash fire at 10 ft (3 m) High speed response time Table 7-7: SharpEye 40/40C Models...
  • Page 220 Reference Manual Specifications 00909-0100-4975 December 2021 Table 7-10: SharpEye 40/40D Models SharpEye 40/40D-I SharpEye 40/40D-M SharpEye 40/40D-LB SharpEye 40/40D-L4B Six ranges: Three ranges: • 10 ft (3 m) • 10 ft (3 m) • 50 ft (15 m) • 50 ft (15 m) •...

  • Page 221: Electrical Specifications

    Specifications Reference Manual December 2021 00909-0100-4975 Electrical specifications The electrical specifications apply to all models unless stated otherwise. Operating voltage 24 Vdc nominal (18-32 Vdc) Power consumption Standby: Max. 3 W (8 W with heated window) Alarm: Max. 4.2 W (9.6 W with heated window) Cable entries 2 x ¾-in - 14 NPT conduits or 2 x M25 x 1.5 mm International Organization for Standardization (ISO)

  • Page 222: Mechanical Specifications

    Reference Manual Specifications 00909-0100-4975 December 2021 Optics are continuously heated Auto (default) Operated only when the change of temperature requires the heating Note In Auto mode, the starting heat temperature can be defined between 32 °F (0 °C) and 95 °F (35 °C).
  • Page 223 Specifications Reference Manual December 2021 00909-0100-4975 Spectrex.net...

  • Page 224: Appendix A Reference Data

    Reference Manual Reference data 00909-0100-4975 December 2021 Reference data Ordering information, specifications, and dimensional drawings To view current SharpEye 40/40 Series ordering information, specifications, and dimensional drawings, follow these steps: Procedure 1. Go to Spectrex.net/en-us/flame-gas-detectors-flame-detectors-40-40-series. 2. Select the appropriate product. 3.
  • Page 225 Reference data Reference Manual December 2021 00909-0100-4975 Spectrex.net...
  • Page 226 Reference Manual FM fuel test responses 00909-0100-4975 December 2021 FM fuel test responses Results of the FM fuel tests are as follows: Table B-1: SharpEye 40/40C Models Fuel SharpEye SharpEye SharpEye 40/40 SharpEye 40/40 40/40C-I 40/40C-M C-LB C-L4B Gasoline 213 ft (65 m) 49 ft (15 m) 92 ft (28 m) N-Heptane...
  • Page 227 FM fuel test responses Reference Manual December 2021 00909-0100-4975 Table B-1: SharpEye 40/40C Models (continued) Fuel SharpEye SharpEye SharpEye 40/40 SharpEye 40/40 40/40C-I 40/40C-M C-LB C-L4B Battery 200 ft (61 m) 39 ft (12 m) 76 ft (23 m) (1) 1 ft (0.1 m ) pan fire (2) Plume fire: 2.5 ft (0.75 m) high, 0.8 ft (0.25 m) wide...
  • Page 228 Reference Manual FM fuel test responses 00909-0100-4975 December 2021 Table B-2: SharpEye 40/40D Models (continued) Fuel SharpEye SharpEye SharpEye SharpEye 40/40D-I 40/40D-M 40/40D-LB 40/40D-L4B Vinyl acetate 246 ft (75 m) 69 ft (21 m) Flammable 207 ft (63 m) 69 ft (21 m) adhesive Solvents 246 ft (75 m)
  • Page 229 FM fuel test responses Reference Manual December 2021 00909-0100-4975 Spectrex.net...
  • Page 230 Reference Manual Immunity to false alarm sources 00909-0100-4975 December 2021 Immunity to false alarm sources Table C-1: Immunity to false alarm sources IAD: Immunity at any distance Radiation source Immunity distance SharpEye SharpEye SharpEye SharpEye 40/40C-I and D-I 40/40C-M and D- 40/40C-LB and D- 40/40C-L4B and D-L4B...
  • Page 231 Immunity to false alarm sources Reference Manual December 2021 00909-0100-4975 Table C-1: Immunity to false alarm sources (continued) Radiation source Immunity distance SharpEye SharpEye SharpEye SharpEye 40/40C-I and D-I 40/40C-M and D- 40/40C-LB and D- 40/40C-L4B and D-L4B Vehicle exhaust diesel fume For SharpEye 40/40D-IH only Table C-2: Welding immunity distance Level...
  • Page 232 Reference Manual 00909-0100-4975 December 2021 SharpEye 40/40...
  • Page 233 00909-0100-4975 Rev. AB 2021 For more information: www.emerson.com © 2021 Emerson. All rights reserved. Spectrex is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners.
  • Page 234 Technical Manual Sensepoint XCD Gas Detector...

  • Page 235: Safety

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 1 Safety Ensure that this Operating Manual is read and understood BEFORE installing / operating / maintaining the equipment. Pay particular attention to Warnings and Cautions. All document Warnings are listed here and repeated where appropriate at the start of the relevant chapter(s) of this Operating Manual.
  • Page 236 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Special conditions for safe use – Sensepoint XCD with Flammable Sensor: 1. Compliance with the Technical Manual is required for safe use of Sensepoint XCD. 2. The following environmental conditions of operation apply for the use of the Sensepoint XCD: Temperature: -25 °C to +55 °C...
  • Page 237 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 3. In order to minimise measurement errors, the ambient conditions (temperature, pressure, humidity) during the calibration of the measuring channels should be as close as possible to those to be encountered during normal operation. 4.

  • Page 238: Information

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 2 Information This manual is for use with the Sensepoint XCD range transmitters only. The Start-up/Surge/In rush current is dependant on the type of power supply used. The typical start-up current for Sensepoint XCD is less than 800mA. Measure the start-up current using the specific power supply before installation to ensure suitability for your application.
  • Page 239 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 3 Table of contents 1 Safety 2 Information 3 Table of contents 4 Introduction 4.1 Transmitter 4.2 Flammable, Toxic Oxygen Gas sensors 4.3 Accessories 4.4 Options ® 4.4.1 Modbus 5 Installation 5.1 Mounting and location 5.2 Mounting the transmitter 5.3 Installing the sensor 6 Electrical connections...
  • Page 240 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 13.3 Sensor / Gas Selection 13.3.1 Sensor Selection 13.3.2 Gas Selection 13.4 Review Mode 14 General specification 15 Ordering information 16 Warranty statement 17 Installation Drawing 17.1 Mechanical Installation Drawing 17.2 Electronic Connection Drawing 17.3 Duct Mounting Drawing 17.4 Collecting Cone Drawing 17.5 Mounting Bolt Assy Drawing 17.6 Mounting Bracket Drawing...

  • Page 241: Introduction

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 4 Introduction The Sensepoint XCD (“Exceed”) comprises a gas detector transmitter and a choice of sensors for detecting flammable gas, toxic gas and oxygen. The construction of Sensepoint XCD allows it to be used in hazardous area locations; it may also be used in other areas not classified as hazardous.

  • Page 242: Transmitter

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 4.1 Transmitter The transmitter enclosure has three threaded entries. The two cable/conduit entries either side of the upper part of the transmitter housing are for connecting the power source, signal output and relay contacts to associated signalling equipment. The bottom entry allows direct connection of the sensor socket.

  • Page 243: Accessories

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Diagram 3: Sensepoint XCD Flammable, Toxic and Oxygen Sensor Cartridge 4.3 Accessories A range of accessories are available to allow use of Sensepoint XCD in a wide variety of applications. These including mounting brackets, maintenance tools, weather housings, flow housing, collecting cone, duct mounting kit and sensor junction boxes.
  • Page 244 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Collecting cone Duct mounting kit The Duct Mounting Kit (P/N: SPXCDDMK) The Collecting Cone (P/N: SPXCDCC) is an is an optional accessory that is designed for optional accessory that may be fitted to the applications to allow the monitoring for the Weather Protection.

  • Page 245: Options

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 4.4 Options 4.4.1 Modbus (Modbus option not tested as part of the performance ® approvals) One of the most common field buses in the industry, the optional Modbus ® interface allows the XCD to connect to a bus of devices and transmit data to PLCs or controllers (see Appendix A).
  • Page 246 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual (MODBUS ID SETTING) Set id>>Set ModBus slave ID>>Set Baud rate>>Set Parity 1) Slave ID shall be set 1~247 2) Baud rate setting 9600 or 19200 3) Parity setting (No, Even, Odd) From the Configuration Mode screen, select ‘✓’. To set the ModBus Slave ID, use the updown ‘▲▼’switches to move to the desired position and use ‘✓’...

  • Page 247: Installation

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 5 Installation WARNINGS Sensepoint XCD is designed for installation and use in Zone 1 or 2 hazardous areas in many countries including Europe and for Class 1 Division 1 or 2 area applications in North America.

  • Page 248: Mounting And Location

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 5.1 Mounting and location Caution: The location of gas detectors should be made in accordance with any relevant local and national legislation, standards or codes of practice. Always replace sensors with a sensor of the same type. Gas detectors should be mounted where a potential hazard of gas is most likely to be present.
  • Page 249 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Diagram 5: Mounting arrangements To mount the Sensepoint XCD transmitter to a Vertical or Horizontal pipe/structure, use the optional XCD Mounting Kit and following procedure: 1. Fit the four spring washers, then the plain washers to the M8 x 80mm SS316 bolts. 2.

  • Page 250: Installing The Sensor

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 5.3 Installing the sensor The XCD gas sensor cartridge plugs into the XCD Sensor Socket. Sensor Socket Weather Protection Plug-In Sensor Cartridge Sensor Retainer Locking Grub Screw Diagram 6: Installing the Sensor WARNINGS Care should be taken when removing and refitting the Sensepoint XCD plug-in Sensor to the Sensor Socket so that damage to the connection pins can be avoided.

  • Page 251: Electrical Connections

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Electrical connections WARNINGS Sensepoint XCD is designed for installation and use in Zone 1 or 2 hazardous areas in many countries including Europe and Class 1 Division 1 or 2 area applications in North America. Installation must be in accordance with the recognized standards of the appropriate authority in the country concerned.

  • Page 252: Transmitter Wiring

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 6.1 Transmitter Wiring Caution: All electrical connections should be made in accordance with any relevant local or national legislation, standards or codes of practice. The Sensepoint XCD transmitter may be wired in either Current SOURCE or Current SINK configuration. These two options are offered to allow greater flexibility in the type of control system that it can be used with.

  • Page 253: Terminal Connections

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 6.2 Terminal connections Note: Ensure that none of the wires in the terminal area cause an obstruction when refitting the Display Module. Ensure that the socket on the Display Module is fully engaged in the Display Module Connector on the Terminal Module.

  • Page 254: Power

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 6.3 Power 6.3.1. For ATEX/IECEx/AP Versions The Sensepoint XCD transmitter (ATEX/IECEx/AP Versions) requires a power supply from the controller of between 16Vdc and 32Vdc. Ensure that a minimum supply of 16Vdc is measured at the sensor, taking into account the voltage drop due to cable resistance. The maximum loop resistance in the field cable is calculated as follows: = (V –...

  • Page 255: For Ul/Csa Versions

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 6.3.2. For UL/CSA Versions The Sensepoint XCD transmitter (UL/CSA Versions) requires a power supply from the controller of between 12Vdc and 32Vdc. Ensure that a minimum supply of 12Vdc is measured at the sensor, taking into account the voltage drop due to cable resistance. The maximum loop resistance in the field cable is calculated as follows: = (V –...

  • Page 256: Cabling

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 6.4 Cabling Caution: All unused and used cable/conduit entries must be sealed with a suitable certified sealing plug and cable gland. The use of industrial grade, suitably armoured field cable is recommended. For example, screened 3 cores (plus screen 90% coverage), suitably mechanically protected copper cable with a suitable M20 explosion-proof gland, or ¾”...

  • Page 257: Ground Terminal Wiring

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual The Earth Screen of the field cable should be “tied to Earth” or connected to Ground at one point only. It is common practise to adopt a STAR EARTH connection regime where all instrumentation Screens are connected at one common point. The Screen at the other end of the cable should be “parked” or terminated into a blank terminal.

  • Page 258: Default Configuration

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 7 Default configuration The Sensepoint XCD transmitter is supplied with the following default configuration. Function Value/Setting Meaning Automatic according to Sensor XCD recognizes the XCD sensor cartridge according to the Sensor Type type connected gas type within its own sensor family i.e. mV, EC or O ≥0.0<1.0 mA Fault (refer to table 5 section 12.3 for details) Inhibit (during configuration/user settings)

  • Page 259: Normal Operation

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 8 Normal Operation Sensepoint XCD is supplied configured and ready for use according to the “Default Settings” table shown above. However these setting may be tailored to a specific application requirement using the Sensepoint XCD configuration menu system. Access to the Sensepoint XCD transmitter’s configuration menus system is via the Magnetic Activation Tool.

  • Page 260: System Status

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 8.2 System Status Display indications, current output and relay states for various operational conditions are shown in the following table. For further details of error messages and trouble shooting see section 12.3. System Status Relay Back Status...

  • Page 261: Magnetic Wand Activation

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 8.3 Magnetic Wand Activation The magnetic wand is used as a tool to allow the user to communicate with the Sensepoint XCD transmitter. Communication with the XCD is achieved by positioning the Magnetic Wand at one of three different positions on the front glass window of the Sensepoint XCD transmitter.

  • Page 262: First Time Switch On (Commissioning)

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 9 First time switch on (Commissioning) WARNING The following procedure requires the Transmitter Cover to be removed while carrying out supply voltage checks. Therefore the appropriate permits to work should be sought in preparation.
  • Page 263 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Note: For a full description of each screen shown in Diagram 15., please refer to Section 13.3 “Review Mode” of this Manual. Diagram 15: Normal Start up procedure (For the CO sensor version) 11.The warm up countdown of 60 seconds (depending on the gas type) is then displayed.

  • Page 264: Response Check And Calibration

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 10 Response Check and Calibration It is recommended to periodically carry out a gas response check on the Sensepoint XCD to ensure correct operation. This may be done in two ways; 1. A simple Response Check often referred to as a “BUMP TEST” is a test using calibration gas applied to the sensor via the nozzle of the Weather Protection or using the Sensepoint XCD Gassing Cap.
  • Page 265 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual To calibrate the detector follow the procedure below. Note: the Oxygen sensor does not require a zeroing procedure. Background air (20.9%Vol oxygen) can be used to span the oxygen sensor in place of a compressed air cylinder (20.9%Vol oxygen).
  • Page 266 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual  10. If span calibration is required use ‘ ’ proceed to the next step. If span calibration  ’ to return to configuration mode.  is not required, use ‘ ’ to select ‘No’ and ‘ WARNING When calibrating the Flammable IR or CO IR sensors, it is essential that the span calibration is done after a zero calibration.
  • Page 267 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18. The display alternates between “Purg gAS” and the gas reading to indicate that the unit is expecting the span gas to be removed from the sensor. 19. Promptly switch off the calibration span gas and remove the Sensepoint XCD Gassing Cap from the sensor to allow the gas to disperse.

  • Page 268: Zeroing And Span Calibration Of Hydrogen Sulfide Sensors

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 10.2 Zeroing and span calibration of Hydrogen Sulfide sensors Hydrogen Sulphide sensors can be affected by extreme humidity changes. A sudden increase in ambient humidity can result in a short-term positive drift in the instrument’s reading.

  • Page 269: General Maintenance

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 11 General Maintenance WARNINGS Access to the interior of the transmitter, when carrying out any work, must only be conducted by trained personnel. Care should be taken when removing and refitting the Sensepoint XCD plug-in Sensor Cartridge to the Sensor Socket so that damage to the connection pins can be avoided.

  • Page 270: Servicing

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Refer to section 12 for sensor replacement procedures. Caution: Oxygen deficient atmospheres (less than 6%V/V) may result in inaccuracy of reading and performance. 12 Servicing WARNINGS Take care when handling sensors as they may contain corrosive solutions. Do not tamper or in any way dis-assemble the sensor.
  • Page 271 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Sensor Socket Sensor Cartridge Weather Protection Sensor Retainer Locking Grub Screw Diagram 13: Sensor Replacement To replace the plug-in sensor of a Sensepoint XCD Sensor Socket use the following procedure: 1. Important: Remove the Power from the Sensepoint XCD Transmitter 2.

  • Page 272: Replacing Modules Within The Transmitter

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 12.2 Replacing Modules within the Transmitter Two replaceable module assemblies are located within the transmitter housing. The Display Module and the Terminal Module. The Display Module is simply removed by unplugging it from the Terminal Module (this procedure is done during normal installation).

  • Page 273: Faults And Warnings

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 12.3 Faults and Warnings The table below provides details of possible error. Message Description Action The unit has not been calibrated for the configured calibration interval W-01 Calibration needed Calibration is necessary due to change of sensor/gas type Transmitter Temperature ...

  • Page 274: Menu's And Advanced Configuration

    SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 13 Menu’s and Advanced Configuration 13.1 Abort Function In Review Mode or Configuration Mode the user can escape one step back from the current position using the Abort Function. To do this the user must activate the Enter switch for more than 3 seconds with the Magnetic Wand.
  • Page 275 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Menu Display Description Execute zero/span calibration Set calibration gas level Set Calibration After zero, the option exists to proceed with span calibration, or return to the Menu. Select the type of sensor from the sensor list. This Select Sensor menu is only available for flammable / IR sensor.
  • Page 276 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Set Location Set location (or TAG number) Set Temperature Change temperature display unit. Unit °C (Celcius) or °F (Fahrenheit) Check Alarm Simulate alarm situation to check the alarm system functions without gas present at the sensor Quit Return to Monitoring mode Table 7: Transmitter menu descriptions...
  • Page 277 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual...
  • Page 278 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual...
  • Page 279 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 13.3 Sensor / Gas Selection NOTE: This Configuration option is not available for XCD units with EC sensors 13.3.1 Sensor Selection “Select Sensor” sets the identity of the type of mV sensor attached to the XCD when XCD does not detect the sensor type automatically.
  • Page 280 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Diagram 16: Gas Selection...
  • Page 281 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 13.4 Review Mode The instrument will enter Review mode when the “Enter” switch is activated with the Magnetic Wand and held for around one second. Names, displays and descriptions for each review item in Review Mode are shown in the following table.
  • Page 282 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Location Location in which the transmitter is installed Power Power voltage* Temperature Internal Transmitter temperature* Peak conc. Maximum concentration detected up to now Test Result There is no fault detected. Table 8: Transmitter menu descriptions Note: *Power voltage and internal transmitter temperature may be different from actual value due to measuring accuracy and internal heating components.
  • Page 283 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Menu Switch (1s to 3s) Review Monitoring Mode Mode Abort Auto end to cycle S/W Version Test Result 2 second delay 2 second delay SRS Version Peak Reading 2 second delay 2 second delay EEPROM Version Temperature 2 second delay...
  • Page 284 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 14 General specification Sensepoint XCD Transmitter. 3-wire, 4-20mA, gas detector transmitter for use with directly installed flammable and toxic gas sensors. For the protection of personnel and plant from flammable and toxic gas hazards. Electrical Input Voltage Range: 16 to 32Vdc (24Vdc nominal) for ATEX/IECEx/AP Versions 12 to 32Vdc (24Vdc nominal) for UL/CSA version Max Power Consumption: Max 5 Watts. at 24Vdc (see section 2 regarding maximum in rush current) Current output 4-20mA (Source or Sink) ≥0.0<1.0 mA...
  • Page 285 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Detectable Gases & Performance (See notes below) User Selectable Default Steps User Default Cal Response Recovery Time Accuracy Operating Temperature* Default alarm points Lowest Alarm Performance Full Accuracy Range Selectable Point Time (T90) for Toxic Sensors Level Approved...
  • Page 286 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 15 Ordering information Part number Description Sensepoint XCD transmitter and sensor KIT (ATEX/IECEx/AP*, LM25 and M20 Entry) SPXCDALMFX ATEX/IECEx/AP* Methane CAT 0-100%LEL (20,0 to 100.0%LEL, 10%LEL) with LM25, M20 Entry SPXCDALMRX ATEX/IECEx/AP* Methane IR 0-100%LEL (20,0 to 100.0%LEL, 10%LEL) with LM25, M20 Entry SPXCDALMPX ATEX/IECEx/AP* Propane IR 0-100%LEL (20,0 to 100.0%LEL, 10%LEL) with LM25, M20 Entry SPXCDALMO1...
  • Page 287 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual SPXCDULNCXM UL/cUL approved Carbon Monoxide 0-500ppm (100 to 1000ppm, 100ppm) with LM25, 3/4"NPT Entry, with Modbus SPXCDULNG1M UL/cUL approved Hydrogen 0-1000ppm with LM25, 3/4"NPT Entry, with Modbus SPXCDULNNXM UL/cUL approved Nitrogen Dioxide 0-50ppm with LM25, 3/4"NPT Entry, with Modbus SPXCDULNB1M UL/cUL approved Carbon Dioxide IR 0-2%VOL with LM25, 3/4"NPT Entry, with Modbus SPXCDULNB2M...
  • Page 288 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 16 Warranty statement All products are designed and manufactured to the latest internationally recognized standards by Honeywell Analytics under a Quality Management system that is certified to ISO 9001. As such Honeywell Analytics warrants its products against defective parts and workmanship and will repair or (at its option) replace any instruments which are or may become defective under proper use within 12 months from date of commissioning by an approved Honeywell Analytics representative or 18 months from date of shipment from Honeywell Analytics, whichever is the sooner.
  • Page 289 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17 Installation Drawing 17.1 Mechanical Installation Drawing...
  • Page 290 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17.2 Electronic Connection Drawing...
  • Page 291 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17.3 Duct Mounting Drawing...
  • Page 292 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17.4 Collecting Cone Drawing...
  • Page 293 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17.5 Mounting Bolt Assy Drawing...
  • Page 294 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 17.6 Mounting Bracket Drawing...
  • Page 295 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18 Certification 18.1 China GB Ex and PA China GB Ex (Chinese Version):...
  • Page 296 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual China GB Ex (English Version):...
  • Page 297 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual China PA Certification:...
  • Page 298 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.2 Korea KTL...
  • Page 299 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual...
  • Page 300 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.3 European ATEX ATEX For Transmitter:...
  • Page 301 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual ATEX for Sensor...
  • Page 302 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual ATEX Special Conditions for Safe Use Sensor: The integral supply cable is to be protected from impact and be suitably terminated. The attachment thread has a 3mm wide undercut. This shall be taken into consideration if the sensor is attached to a flameproof enclosure in order to maintain the minimum engaged thread length.
  • Page 303 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.4 International IEC IEC Ex for Transmitter...
  • Page 304 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual IEC Ex for Sensor...
  • Page 305 Sensepoint XCD Technical Manual SPXCDHMANEN Issue 9 18.5 Sensepoint XCD ATEX Name Plate...
  • Page 306 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.6 Sensepoint XCD UL Name Plate...
  • Page 307 Sensepoint XCD Technical Manual SPXCDHMANEN Issue 4 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.7 Sensepoint XCD Warning Tag 18.7 Sensepoint XCD Warning Tag...
  • Page 308 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.8 Sensor Cartridges Label...
  • Page 309 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 18.9 EC Declaration of Conformity A full EC declaration of conformity is available on the CD accompanying the product. This document lists the European Standards with which the Sensepoint XCD complies.
  • Page 310 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 19 Cross Interference and Cross Calibration 19.1 Cross Interference Table for Toxic and Oxygen This below table shows the relative cross sensitivity of the Sensepoint XCD to other gases. “Gas Type” indicated the XCD sensor type fitted to the XCD. “Gas Type Applied” indicates the gas that may be applied to that sensor and the resulting Reading. Gas Type Applied Concentration Unit Reading...
  • Page 311 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 19.2 Cross Calibration Flammable Gas Detector (Not tested as part of the performance approval) For greater accuracy, a catalytic gas detector should be calibrated using a certified gas/air mixture equal to 50% LEL of the actual target gas intended to be monitored. However, it is not always practical to obtain every detectable type of hydrocarbon gas in a calibration-ready, certified and verifiable form. Therefore, it is possible to carry out a “cross calibration”...
  • Page 312 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Propan-2-ol Styrene Tetra hydrafuran Toluene Triethylamine Xylene Table 14 . Star Rating of Gases To cross calibrate the Sensepoint XCD flammable gas detector: (1) Obtain the star rating for both the calibration test gas and the gas to be detected from Table 14 (2) These values may then be used in Table 15 to obtain the required calibration span setting when a 50% LEL test gas is applied to the detector.
  • Page 313 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual Table 16. Correction factors Notes: 1. Since catalytic sensors require oxygen for correct operation, a mixture of gas in air should always be used for calibration purposes. 2. Assuming average performance of the sensor, the sensitivity information in Tables 14 To 16 is normally accurate to + or - 30%.
  • Page 314 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual 19.3 Meter Multiplication Factors for Sensepoint XCD-IR Propane It is possible to apply a linear cross reference factor to the output of a sensor characterized for propane and achieve the results shown in the graph below. Reasonable accuracy is maintained to at least the 50% LEL equivalent values of the cross-referred gasses.
  • Page 315 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual XCD Transmitter Appendix A - Modbus® Protocol A-2 A.1 Modbus and the XCD The XCD gas detector may be fitted with the optional Modbus board. Authoritative information on the MODBUS Upgrade Kit can be found at www.modbus.org. The XCD supports Modbus/RTU over an RS-485 physical layer. The interface is isolated and includes a switchable 120 Ohm termination resistor.
  • Page 316 SPXCDHMANEN Issue 9 Sensepoint XCD Technical Manual A.2 Modbus Registers ModBus Register Information Type Size Note Address 30001 Main SW Version of XCD 30002 EEP Version of XCD 30003 WatchDog s/w Version of XCD 30004 Location string string[12] 30010 ModBus slave ID 30011 Monitor Status Upper byte : Function...
  • Page 317 Find out more www.honeywellanalytics.com Contact Honeywell Analytics: Europe, Middle East, Africa, India Life Safety Distribution AG Javastrasse 2 8604 Hegnau Switzerland Tel: +41 (0)44 943 4300 Fax: +41 (0)44 943 4398 India Tel: +91 124 4752700 gasdetection@honeywell.com Americas Honeywell Analytics Inc. 405 Barclay Blvd.
  • Page 318 This siren cannot be connected to S1 or S2 Current: 12v - Max 120mA 24v - Max 110mA outputs on Sigma XT Panel. Sound Output: 100dB(A) To achieve the 2 separate alarm signals must connect to Stage 1 and Stage 2 Alarm Relays.

This manual is also suitable for:

Sigma xt-a

Table of Contents
