FirePro FPX103C Technical Manual

Dual loop auto/manual fire control panel
Hide thumbs

Advertisement

Quick Links

Download this manual
FPX103C
Dual Loop Auto/Manual
Fire Control Panel
Technical Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the FPX103C and is the answer not in the manual?

Questions and answers

Related Manuals for FirePro FPX103C

Summary of Contents for FirePro FPX103C

  • Page 1 FPX103C Dual Loop Auto/Manual Fire Control Panel Technical Manual...
  • Page 2 Our tamper evident tag technology and our strict electronic design rules has proven highly effective. To eliminate the inherent hazards of microprocessor control the FPX103C uses a fully parallel path programmable logic device, which is coded using a language called VHDL, commissioned by US DOD and used for high reliability and safety critical applications.
  • Page 3 FPX103C as a result of an alarm (from either detectors or manual operate switch). With the ignition off the unit enters low power mode and the ON LED will flash to conserve power. Single flash shows the spindown timer is still counting (fans still turning), then adopts a double flash “heartbeat”...
  • Page 4 ELECTRICAL SPECIFICATION (at 24VDC supply unless otherwise stated): Power Supply Operating Voltage 11 to 32V DC Quescent Current Ign Off 8.5mA Typ (excluding external load currents) Ign On 16mA Typ (excluding external load currents) Maximum Alarm Current 100mA (excluding external load currents) Draw Max current draw 3A (including extinguisher operate current)
  • Page 5 Fan/Engine “Spindown” delay time before automatic release. Note: Spindown delay only when ignition is ON OFF.OFF.OFF.OPT 0 Sec = Immediate ON.OFF.OFF.OPT 5 Sec OFF.ON.OFF.OPT 10 Sec ON.ON.OFF.OPT 15 Sec OFF.OFF.ON.OPT 20 Sec ON.OFF.ON.OPT 25 Sec OFF.ON.ON.OPT 30 Sec ON.ON.ON.OPT No Automatic Operation Installation Notes: Ensure that Linear Heat Detectors are suitably mounted for the vehicle vibration levels.
  • Page 6 Outline & Mounting drawing:...
  • Page 8 Typical Application wiring (Linear Heat Detector sensors)

  • Page 9: Limitation Of Liability

    Third Party manufacturer to FirePro Systems. LIMITATION OF LIABILITY In no event, regardless of cause, shall FirePro Systems be liable for any indirect, special, incidental, punitive or consequential damages of any kind, whether arising under breach of contract, tort (including negligence), strict liability or otherwise, even if...
  • Page 10 FirePro Systems 6 Koumandarias Street, PO Box 54080, CY-3720 Limassol, Cyprus - EU Tel.: +357 25 379999 | Fax: +357 25 354432 | Email: mail@firepro.com www.firepro.com...
