Yale PR50 Installation Instructions Manual

Parallel Rigid Arm Door Closers
with or without Stop
Additional Closer Options:
- "DL" indicates Delayed Action closing.
- "H" indicates Hold-Open function. These components are handed
- "T" indicates Thumbturn actuated Hold-Open control.
Optional Accessories:
- 213 Dropplate
- 293L, 890, 891 Soffit Plate Accessories.
NOTE: For special applications a separate door and frame preparation template is packed with these instructions. In those
cases, use this instruction sheet for installation sequence and closer adjustments only.
Closer mounts on opposite to hinge (push) side of door. PR51 Parallel Rigid Non Hold Open arm illustrated.
Right Hand Door – RH
Left Hand Reverse – LHR
Closer mounts on opposite to hinge (push) side of door. 5121 Parallel Rigid arm with stop illustrated.
Right Hand Door – RH
Left Hand Reverse – LHR
Closer mounts on opposite to hinge (push) side of door. 5121T Parallel Rigid arm with Thumbturn Hold Open illustrated.
Right Hand Door – RH
Left Hand Reverse – LHR
Installation Instructions
80-9350-2530-010 (06-09)
An incorrectly installed or improperly
adjusted door closer can cause
property damage or personal injury.
These instructions should be followed
to avoid the possibility of
misapplication or misadjustment.
Standard Frame Installation
See Pages 3 and 4
Narrow Frame Installation
890 and 891 accessories required for this application (supplied separately).
See Pages 3 and 4
Flush Partition Installation
293L accessory required for this application (supplied separately).
See Pages 3 and 4
Model Numbers Included:
PR50(BF) / PR150(BF)
5120(BF)(T)
Left Hand Door – LH
Right Hand Reverse – RHR
Left Hand Door – LH
Right Hand Reverse – RHR
Left Hand Door – LH
Right Hand Reverse – RHR
