INSTALLATION AND OPERATING INSTRUCTIONS
Electric Griddles, Drop-In Style
Models: EGD-1824, 1836, 1848, 2436, 2448, 2472
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number
WARNING: For your safety do not store or use gasoline or other flammable vapors or
!
liquids in the vicinity of this or any other appliance. Keep the area free and clear of
combustibles. (See ANZI Z83.14B, 1991)
WARNING: Improper installation, operation, service or maintenance can cause property
!
damage, injury or death.
positioning, installing, maintaining or servicing this equipment.
+1 (307) 634-5801 Phone
+1(307) 637-8071 Fax
Serial Number
CONTENTS
Read and understand these instructions thoroughly before
APW WYOTT Foodservice Equipment Company
P.O. Box 1829
Cheyenne, WY 82003
R
1
Date Purchased
P/N 88057-10 9/05
+1 (800) 752-0863 Toll Free
www.apwwyott.com
2
7
13
13
13
13
15
15
15
15
15
15
16
20
!
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGD-1836 and is the answer not in the manual?

Questions and answers

Related Manuals for APW Wyott EGD-1836

Summary of Contents for APW Wyott EGD-1836

  • Page 1: Table Of Contents

    Read and understand these instructions thoroughly before positioning, installing, maintaining or servicing this equipment. P/N 88057-10 9/05 APW WYOTT Foodservice Equipment Company P.O. Box 1829 Cheyenne, WY 82003 +1 (307) 634-5801 Phone +1 (800) 752-0863 Toll Free +1(307) 637-8071 Fax www.apwwyott.com...

  • Page 2: Installation Cutouts

    U.L. CONDITIONS OF ACCEPTABILITY This equipment must be installed in an all metal fixture of steel or stainless steel construction, .078 inch thick minimum for the top and supporting frame. Side enclosure to be at least 22 MSG minimum thickness. A removable bottom enclosure must be provided under each drop-in unit and be made of metal construction of at least 22 MSG min.
  • Page 3 EGD-1824 REFERENCE NOTES ON PAGE 2...
  • Page 4 EGD-1836, EGD-2436 REFERENCE NOTES ON PAGE 2...
  • Page 5 EGD-1848, EGD-2448 REFERENCE NOTES ON PAGE 2...
  • Page 6 EGD-2472 REFERENCE NOTES ON PAGE 2...

  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: Electrical and grounding connections must comply with the applicable portions of the national electrical code and/or other local electrical codes. WARNING: Disconnect electrical power supply and place a tag at the disconnect switch indicating that you are working on the circuit. Terminal Box Location.
  • Page 8 EGD-1836, 208/240/480VAC, 1 & 3 Phase (Wiring Diagram)
  • Page 9 EGD-2436, 208/240/480VAC, 1 & 3 Phase (Wiring Diagram)
  • Page 10 EGD-1848, 208/240/480VAC, 1 & 3 Phase (Wiring Diagram)
  • Page 11 EGD-2448, 208/240/480VAC, 1 & 3 Phase (Wiring Diagram)
  • Page 12 EGD-2472, 208/240/480VAC, 3 Phase (Wiring Diagram)

  • Page 13: General

    GENERAL Drop-In Griddles are designed to be installed into metal fixtures or fabricated tops. Fixture or top must be sufficiently rigid to support device weight without warping. Emphasis is on simplifying the layout and fabrication. These instructions covers all models. The floor plans for the griddles shows overall and other key dimensions of the device and their relationships to the fixture or top into which they will be installed.
  • Page 14 Hobart furnishes a gasket or seal that must be placed around the perimeter of the hole in the top as shown in Fig. 3. This gasket may be temporarily held in place with tape. Do not place the staple securing the gasket ends on or near a corner.

  • Page 15: Owner’S Information

    OWNER'S INFORMATION CLEANING THE GRIDDLE AFTER INSTALLATION Before using the griddle for the first time, be sure to remove the factory-applied rust preventive compound. Add a mild detergent to hot water and wash the griddle well. Rinse with a clean, damp cloth and wipe dry. CONTROLS The heat of the griddle surface is controlled by turning the dial knobs (recessed in the front control pane!).

  • Page 16: Parts Lists & Exploded Views

    EGD-1824, EGD-1836 & EGD-1848 (Exploded View)
  • Page 17 PARTS LIST DROP-IN ELECTRIC GRIDDLES, EGD-1824, -1836, -1848 ITEM PART NUMBER DESCRIPTION 1439722 HEATING ELEMENT , 208 VOLT 1439723 HEATING ELEMENT , 240 VOLT 64256301 PRESSURE PLATE 64257301 BULB CLAMP ASSEMBLY 64634001 BAFFLE 64257801 TERMINAL BLOCK BOX 64257901 COVER 1126035 TERMINAL BLOCK 64258101 BOTTOM PANEL...
  • Page 18 EGD-2436, EGD-2448 & EGD-2472 (Exploded View) 29 27...
  • Page 19 PARTS LIST DROP-IN ELECTRIC GRIDDLES, EGD-2436, -2448, -2472 ITEM PART NUMBER DESCRIPTION 1439725 HEATING ELEMENT , 208 VOLT 1439726 HEATING ELEMENT , 240 VOLT 64256701 PRESSURE PLATE 64257301 BULB CLAMP ASSEMBLY 64625100 BAFFLE 64257801 TERMINAL BLOCK BOX 64257901 COVER 1126035 TERMINAL BLOCK 64258202 BOTTOM PANEL...

  • Page 20: Warranty

    APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
