APW Wyott GGM-18H Installation And Operating Instructions Manual

Apw wyott foodservice equipment company gas griddles installation and operating instructions ggt-18h, ggt-24h, ggt-36h, ggt-48h, ggm-18h, ggm-24h, ggm-36h, ggm-48h

Hide thumbs Also See for GGM-18H:

Specifications (2 pages)

Installation and operating instructions manual (16 pages)

Table Of Contents

INSTALLATION

OPERATING

INSTRUCTIONS

(US & Canadian units are convertible and are assembled for Natural Gas)

(European units are not convertible and assembled for the appropriate gas)

Please complete this information and retain this manual for the life of the equipment. For

Warranty Service and/or Parts, this information is required.

Model Number

FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and

liquids in the vicinity of this or any other appliance.

WARNING: Improper installation, operation, service or maintenance can cause property

damage, injury or death. Read and understand these instructions thoroughly before

positioning, installing, maintaining or servicing this equipment.

+1 (307) 634-5801 Phone

+1 (307) 637-8071 Fax

AND

Gas Griddles

MODELS: GGT-18H, -24H, -36H, -48H

MODELS: GGM-18H, -24H, -36H, 48H

IMPORTANT FOR FUTURE REFERENCE

Serial Number

APW WYOTT Foodservice Equipment Company

P.O. Box 1829

Cheyenne, WY 82003

Date Purchased

P/N 8838800 6-06

+1 (800) 752-0863 Toll Free

www.apwwyott.com

Table of Contents

Need help?

Do you have a question about the GGM-18H and is the answer not in the manual?

Questions and answers

Summary of Contents for APW Wyott GGM-18H

Page 1 INSTRUCTIONS Gas Griddles MODELS: GGT-18H, -24H, -36H, -48H MODELS: GGM-18H, -24H, -36H, 48H (US & Canadian units are convertible and are assembled for Natural Gas) (European units are not convertible and assembled for the appropriate gas) IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment.
Page 2: Table Of Contents
APW Wyott. Congratulations on your purchase of APW Wyott commercial cooking or refrigeration equipment. APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment.
Page 3: Safety Precautions
If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne, WY 82003. Before installing and operating this equipment be sure everyone involved in its operation is fully trained and is aware of all precautions.
Page 4: Specifications & Dimensions
WARNING: Keep the appliance free & clear of all combustible substances. If gas odor is detected at any time, immediately shut unit down at the main shutoff valve. Do not permit any open flames in the area of the appliance. Immediately contact an authorized Service Agency or your local Gas Supplier for service.
Page 5: Lighting Instructions
Caution: DO NOT use an open flame to check for leaks. Check all gas piping for leaks with a soap and water solution before operating unit. THESE UNITS ARE SUITABLE FOR INSTALLATION ON NON-COMBUSTIBLE SURFACES ONLY. Noncombustible clearances: 0" sides (0 mm) 0"...
Page 6: Operating Instructions
Turn the burner knobs to "HI". If the burner does not ignite, promptly open the pilot valve more. If the pilot flame appears larger than necessary, turn it down and reset burner ignition. The pilot flame should be as small as possible but large enough to guarantee reliable ignition of the burners when the knobs are turned to "HI".
Page 7: Cleaning/Maintenance
CAUTION: Use only non-abrasive cleaners. Abrasive cleaners could scratch the finish of your unit, marring it’s appearance and making it susceptible to dirt accumulation. Do Not use steel wool, other abrasive cleaners or cleaners/sanitizers containing chlorine, iodine, ammonia or bromine chemicals as these will deteriorate the stainless steel and glass material and shorten the life of the unit.
Page 8: Ggt Calibration Procedure/Probe Location
CONVERSION GGT Instructions are for conversion from Natural Gas to Propane (L.P.) on all GGT models . The conversion should be done before connecting the unit to the gas supply. Remove the knobs and front panel. Remove the supply tubes that go between the thermostats and the orifice bracket. Change the orifices to the size recommended for propane (L.P.).
Page 9 CALIBRATION PROCEDURE FOR GGT GRIDDLES Locate the reading positions Make sure the griddle surface is clean. Grease or food particles on the griddle will result in inaccurate thermostat calibration. Mark the locations where the temperature probe will be placed for testing. See the sketch provided. Starting from the left side of the griddle measure 8”...
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM Heat does not come on when thermostat is turned on. Pilot burner will not light. Pilot burner will not stay lit. Fat appears to smoke excessively. Food sticks to griddle. Food burned around edges or contains dark specks. Food is undercooked inside.
Page 11 NOTES...
Page 12: Replacement Parts Lists & Exploded Views
PARTS LISTS & EXPLODED VIEWS GGM GRIDDLES (EXPLODED VIEW)
Page 13 ITEM DESCRIPTION 218215-20 Weldment, Griddle GGM-18 218216-20 Weldment, Griddle GGM-24 218217-20 Weldment, Griddle GGM-36 218218-20 Weldment, Griddle GGM-48 218215-11 Body, 18" Firebox 218216-11 Body, 24" Firebox 218217-11 Body, 36" Firebox 218218-11 Body, 48" Firebox 21820728 Tube, Pilot Supply GGM-18 21820727 Tube, Pilot Supply GGM-24/36/48 2066154...
Page 14 GGT GRIDDLES (EXPLODED VIEW)
Page 15 Item Description 218219-60 Weldment, Griddle, GGT -18 218220-60 Weldment, Griddle, GGT -24 218221-60 Weldment, Griddle, GGT -36 218222-60 Weldment, Griddle, GGT -48 2092614 Elbow, 3/8CC X 3/8NPT, No Hood 81108-00 M/S Tr Hd Ph 6-32 x 1" 2065614 Valve, Pilot GGT-18 2068001 Pilot Valve GGT-24/36/48 218207-23...
Page 16: Warranty
APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
