  • Page 1 Shaper/Router Table Owner’s Manual Model 5000231 HONESTLY NOW … Have you read this OWNER’S MANUAL? Parlez-vous français? Voir page 8 ¿Habla español? Vea página 14 • Safety • Assembly • Operation • Service Parts P.O. Box 1468 Racine, Wisconsin 53401 1-800-437-3635 http://www.dremel.com...

  • Page 2: Power Tool Safety Rules

    Power Tool Safety Rules Read and understand all instructions. Failure to follow all instructions listed WARNING below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work Area Personal Safety Keep your work area clean and well lit. Stay alert, watch what you are doing and Cluttered benches and dark areas invite use common sense when operating a power...
  • Page 3 Maintain tools with care. Keep cutting tools Service sharp and clean. Properly maintained tools, Tool service must be performed only by with sharp cutting edges are less likely to bind qualified repair personnel. Service or and are easier to control. Any alteration or maintenance performed by unqualified modification is a misuse and may result in a personnel could result in a risk of injury.
  • Page 4 ATTENTION: Read entire instruction manual carefully before using your Dremel Shaper/Router Table. Retain instructions for future reference. This attachment will convert Dremel Corded Rotary Tools to a Shaper/Router Table for edge forming, routing, grooving, shaping, sanding edges, MOUNTING jointing, etc.

  • Page 5: Installing Router Bits

    Installing Router Bits Fig. 3 DEPTH 1. When installing router bits, be sure the OF CUT power cord is unplugged, then remove the tool from the Shaper/Router Table. ROUTER BIT Fit the ROUTER BIT SHANK into the collet allowing a maximum of 5/8” to protrude past the collet nut.
  • Page 6 Fig. 5 WEDGE CLAMP NUT SUPPORT WEDGE Routing Using the Fence 1. Unplug the rotary tool before making any fence adjustments or bit changes. Feed the work against the rotation of the bit as shown. Most fence cutting is done CENTER CYLINDER THUMB NUT with the SUPPORT WEDGE adjusted to...
  • Page 7 1 1/2" SLOT TO CLEAR GUARD 16" 12" Fig. 7 3/8" PLYWOOD 1 1/2" RECTANGULAR HOLE TO FIT OVER TABLE 1 1/2”HIGH SUPPORTS ON BOTH ENDS WILL REST ON BENCH Routing Using Pilot Bits Drum Sanding 1. When bits with pilots are to be used The Shaper/Router Table is also ideal for (such as 5000612 or 5000615), move drum sanding irregular shaped parts as...

  • Page 8: Model Modèle Modelo

    MODEL MODÈLE MODELO 5000231 -20-...
  • Page 9 ORDER BY PART NUMBER, NOT CODE NUMBER CODE NO. PART NO. DESCRIPTION 2615296101 *Guard & Sleeve 2615296100 *Fence & Wedge 2615294998 *Shaper Table *Thumb Nut 2615294999 *Guard & Pin 2615294956 *Adjustable Bracket Clamp Screw 4 Req’d 2615294223 *Clamp Screw Nut #6-32 3 Req’d 2615294205 *Clamp Screw #6-32 x 3/4"...
