Dynojet POWER COMMANDER V Installation Instructions page 3

FIG. A
FIG. B
Unplug
FIG. C
17-002 www.powercommander.com
1 Remove the seat, fuel tank and front number plate.
2 Secure the PCV to the stock ECU using the supplied zip tie (Fig. A)
3 Route the PCV harness to the left side of the frame following the throttle
cable.
4 Unplug the stock wiring harness from the injector (Fig. B).
5 Connect the PCV in-line of the stock wiring harness and the injector (Fig. C).
2009 Kawasaki KX450F PCV - 3
