Summary of Contents for Triax ORB 923 Series
- Page 1 User Guide Fibre Optical Receiver Model Item no. ORB 823/923 Series triax.com Version...
- Page 2 ORB 823, Fibre Optical Receiver (att. settings via potentiometer) ORB 923, Fibre Optical Receiver (settings via JxP Pads) © Copyright © Triax A/S Copying and distribution only with prior written permission from Triax A/S Triax A/S, Bjørnkærvej 13, 8783 Hornsyld. www.triax.com English ORB 823/923 Series...
- Page 3 Table of Contents Table of Contents Page Table of contents Installation, Environmental protection standards General principles of use Adjustments, Forward channel Forward path amplifier Optical receiver adjustment Test points Power supply Operating tips Interchangable jumpers for att. and equ. Block Diagrams Adjustment elements on the unit Maintenance / Service Recycling...
- Page 4 Environmental vation and use of an ORB x23 optical receiver. Should you have any queries protection regarding our products, please contact Triax A/S, or one of our nearest distri- standards bution representatives. Products or packaging that are marked with such a logo may not be disposed of together with unsorted household waste but should be delivered to a specialized WEEE collection point for re- cycling and waste reuse.
- Page 5 Adjustments 2. 0 The RF path of the optical receiver amplifies input signals received by Forward the optical circuit. The attenuator enables adjustment of the input RF level, Channel whilst the interstage equalizer enables pre-adjustment. Following this, the signal travels to the outputs. The ORB x23 optical receiver has been designed for use within FTTx networks.
- Page 6 Settings ORB-x23 optical receivers are designed to be supplied from a 180…253 VAC, Power Supply 50..60 Hz mains socket. To ensure appropriate ventilation, keep any items at least 5 cm away Operating Tips from the unit, The unit should not be covered with any items, ...
-
Page 7: Technical Specifications
Technical Specifications Block Diagrams Adjustment elements on AGC ON/OFF switch the units Attenuator (0...20dB) (ORB 823 shown) Equalizer (0...20dB ) Power input LED indicator Repair only by an Authorized Technician and Service Center. Please refer to Your Sales Representative for more info. Maintenance/ Service You must adhere to the Legal Requirements and precautions that applies to... - Page 8 ORB 823/923 Series Art. No.: 30799x—B.11.12 Copyright © 2016 TRIAX. All rights reserved. The TRIAX Logo and TRIAX, TRIAX Multimedia are registered trademarks or trademarks of the TRIAX Company or its affiliates. All specifications in this guide are subject to change without further notice.
