  • Page 1 TRIAX STR 333 Digital Combo Receiver PREMIUM DUAL PVR Use Manual N1_ENGLISH 104165...

  • Page 2: General Safety

    General Safety Cautions CAUTION : To reduce the risk of electrical shock, do not remove the cover. No user serviceable parts inside. Read this manual carefully before using the product. The cautions described below contain important information about safety, and are categorized into: Danger, The company will not take any responsibility for accidents or damage resulting from careless handling by the user.
  • Page 3 Cautions Warning If the product is mishandled, the user might receive a serious or minor injury. Damage or loss to the user’s property might also result. • The product must not be exposed to water or liquid. If the apparatus is exposed to drips or splashes, it might cause a problem that cannot be repaired.

  • Page 4: Table Of Contents

    Contents General Safety... 2 1. Functions and Installation ... 5 1.1 Remote Control Unit... 5 1.2 Front Panel... 6 1.3 Rear Panel ... 6 1.4 CAM(Conditional Access Module) and Smart Card ... 7 1.5 Connecting and Installation ... 8 2. Easy Installation... 10 3.

  • Page 5: Functions And Installation

    1. Functions and Installation 1.1 Remote Control Unit STAND BY To switch between operation and stand by mode. A.L/R To select the sound mode. (Mono, Left, Right, Stereo) To display the reserved list. (Option) A/LANG To select the audio language. ON/OFF To turn the PIP screen on/off.

  • Page 6: Front Panel

    1.2 Front Panel STAND BY(POWER) Switch the receiver power "ON" or "OFF". MENU To see main menu. VOL -/+ To turn the volume -/+ or select a sub-menu item. To select a program, a highlighted line or parameter value. 1.3 Rear Panel ANTENNA Input connector from terrestrial antenna.

  • Page 7: Cam(Conditional Access Module) And Smart Card

    1.4 CAM(Conditional Access Module) and Smart Card (Option) Caution Please do not plug in the main power supply cord until you have finished all of the connections! Although some TV and radio channels are free to view, you must subscribe to most TV and radio/music channels and a Conditional Access component is required.

  • Page 8: Connecting And Installation

    1.5 Connecting and Installation 1.5.1 How to connect the receiver to various other systems There are several ways of connecting the receiver to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.5.2 To Connect Satellite and Terrestrial Antenna (Only Combo) •...
  • Page 9 1.5 Connecting and Installation 1.5.5 Connect the receiver to a Hi-Fi System • Connect a RCA stereo cable from the AUDIO L/R jacks, S/PDIF on the receiver to the LINE, AUX, SPARE or EXTRA input jacks on your Hi-Fi System. 1.5.6 Connect the receiver to a Digital Audio System •...

  • Page 10: Easy Installation

    2. Easy Installation 2.1 Menu Application Press the MENU button on the remote control unit. You will see the “Main Menu” on the screen. • Default PIN code is "0000" • You can move into the desired submenu using the •...
  • Page 11 2.2 Easy Installation 2.2.3 Channel Search You can search the channels. If you press the button, the Installation screen will appear If you want to search the channel, you select between Satellite and Terrestrial. And then press the search setting screen. 2.2.4 Satellite - Channel Search Select the satellite you want using the satellite list.
  • Page 12 2.2 Easy Installation C/KU Switch: You can select C/KU band by selection of switch type. (None, DiSEqC Switch) Position (DiSeqC 1.2) After selecting a satellite, please select position number. To change value, press the button. The position list will be displayed. LNB Freq.
  • Page 13 2.2 Easy Installation Scan • After selecting all that is necessary, press the satellite list. Pop up widow will bedisplayed. • Select ON or OFF according to your Network. • Select All or FTA Search Type. • Select All, TV, or Radio TV/Radio •...

  • Page 14: Basic Operation

    3. Basic Operation 3.1 Basic Function Usage 3.1.1 Program Information After the television channels have been programmed, you will see the information box each time you change the channels. • Every time you change channels you will receive program information for a few seconds. (In the select how long this information will be shown.) •...
  • Page 15 3.1 Basic Function Usage 3.1.6 Subtitle • Press the SUB-T(Red) button and the popup window will be displayed on the screen. • Select the Off then subtitle function is off. • Select the Subtitle language, and then you can see Subtitles. 3.1.7 Teletext •...
  • Page 16 3.1 Basic Function Usage 3.1.11 To change the audio output • Press the A.L/R button on the remote control unit to change the output. • Then on-screen menu is displayed on the top right side of the screen. • Press the A.L/R button repeatedly to change the sound mode.
  • Page 17 3.1 Basic Function Usage 3.1.15 TV/Radio Change With this function, you can change the Radio listening mode while you are watching TV. If you press the TV/RADIO button while you are watching TV, the radio listening screen will appear. If you press the the TV screen will reappear.

  • Page 18: Main Menu Guide

    4. Main Menu Guide 4.1 PVR - Record & Play 4.1.1 Record With this function, you can check file information while recording with the PVR. In addition, you can set the record-end time, and the power to go off after recording. •...
  • Page 19 4.1 PVR - Record & Play 4.1.6 Fast-Forward & Rewind The Fast-Forward and Rewind functions enable the user to view the front, back or any desired part of the file. • To view forward parts press the parts press the button on the remote control.
  • Page 20 4.1 PVR - Record & Play 4.1.11 To File Playback With this function, you can play recorded files. • If you press the MODE/FILE button while watching TV, the File List screen will appear. The currently saved directory in the HDD will be displayed on the File List screen.
  • Page 21 4.1 PVR - Record & Play Note • If you press the GREEN button on the Group Play List pop-up window after selecting the file, the selected file will be deleted. • If you press the RED button on the Group Play List pop-up window, all files will be deleted.
  • Page 22 4.1 PVR - Record & Play 4.1.15 Timer With this function, you can set reserved recording functions including adding, changing and deleting reserved recordings. You can add a reserved recording. • Press the UP/DOWN buttons on the PVR menu to select the Timer and then press the button.
  • Page 23 4.1 PVR - Record & Play 4.1.17 Format HDD • To format the HDD, press the UP/DOWN select Format HDD and then press the • When the format confirmation pop-up window appears, press the button. 4.1.18 HDD Information You can see the HDD Information. (Size, Serial Number, Firmware Version, Model Name) button on the PVR menu to button.

  • Page 24: Edit Channel List

    4.2 Edit Channel List From these menus, you can create favorite lists, lock, skip, delete, or move channel. • Select “Edit Channel List” in the main menu with the buttons and press the button. • At the request window, Input PIN code. If you have not entered your own PIN code, then the PIN code 0000 applies, which was set at the factory.
  • Page 25 4.2 Edit Channel List 4.2.1 Favorite(Auto Favorite, 1~31) • You can edit favorite TV and Radio list. This enables you to create the 31 favorite TV and Radio lists. • Select the channel you want to edit on the favorite list and press the button.

  • Page 26: Program Guide

    4.3 Program Guide The program guide provides information such as the program listings and ending times for all available programs. You can reserve a recording by pressing Select “Program Guide” in the main menu with the buttons and press the button.

  • Page 27: System Setting

    4.4 System Setting You will be asked to enter your PIN code before you can enter this menu. The PIN code preset to 0000 from the factory. If you want to customize the system to suit you better, you can specify some settings from the submenus in the •...
  • Page 28 4.4 System Setting 4.4.2 Time • Press the UP/DOWN button on the Setup list to select Time and then press the button. • Press the UP/DOWN button to select either Day Light Saving and then press the right pop-up menu. Banner Time When you switch channels, an information banner will be shown for a few seconds.
  • Page 29 4.4 System Setting 4.4.3 Lock Control • Press the UP/DOWN button on the Set list to select Lock Control and then press the button. • Press the UP/DOWN buttons to select either Menu Lock, Parental Lock, Receiver Lock or Change PIN Code and then press the button to move to the right pop-up menu.
  • Page 30 4.4 System Setting 4.4.4 A/V Setting • Press the UP/DOWN buttons on the Setup list to select Display and press the button. • Press the UP/DOWN button to select either Screen Type, Menu Transparency, SCART Output, SPDIF Output, RF Channel, RF Mode or TV Type and then press the pop-up menu.
  • Page 31 4.4 System Setting RF Mode You can select the RF Mode. If you get picture but no sound, the RF Mode selecting might be wrong. Select an RF Mode and then press the Note • PAL BG, PAL I, PAL DK, SECAM L, NTSC M 4.4.5 Menu Transparency From 20% to 100% will give the variable transparency on Video and OSD screen.
  • Page 32 4.4 System Setting 4.4.8 OTA Upgrade To set up OTA Upgrade It is possible to set up OTA upgrade manually. Please check if there is new software as pressing after entering Frequency, Symbol Updated software will be downloaded. 4.4.9 Other Setting Simple Channel List Hide If you select “ON”...

  • Page 33: Utility (Option)

    4.5 Utility (option) Select “Utility” in the main menu with the press the button. 4.5.1 Calendar Select “Calendar” in the Utility menu with the press the button, you can see the Calendar. 4.5.2 Game Press the button to move to the GAME folder of the File List. Select the GAME file on the HDD to play the game.

  • Page 34: Common Interface

    4.6 Common Interface modules, automatically provide access to both services. Each smart card contains your subscription details. You can view your entitlement via the COMMON INTERFACE menu by using the MENU button as below. • Press the MENU button and select Common Interface then Slot1 and Slot2 will be showed up on the screen and the menu will be appeared.

  • Page 35: Technical Specifications

    6. Technical Specifications Tuner Demodulation FEC Modes Rate Satellite Input Connector Frequency Range Symbol Rate Demodulation Guard Interval Modes FEC Modes Rate Terrestrial Input Connector Frequency Channel Bandwidth RF Modulator PLL type TV Standard RF Connector Frequency Range MPEG TS A/V Decoder Video Resolution Input Bit Rate Transport Stream...
