  • Page 1 TRIAX TR 305 Digital Terrestrial Receiver User's Manual K7_ENGLISH 104313...

  • Page 2: General Safety

    General Safety Warning Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment. Unplug the receiver from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the receiver. Do not use accessories or attachments not recommended by the receiver manufacturer as they may cause problems to the equipment and will void the warranty.
  • Page 3 General Safety Digital Terrestrial Receiver Owner's Manual OPERATION HANDBOOK Before operation, Please read the entire manual thoroughly and retain it for future reference. Channel List Edit Channel List Program Guide System Setting Automatic Search Manual Search CA System Utility DIGITAL TERRESTRIAL RECEIVER...

  • Page 4: Table Of Contents

    Contents Remote Control Unit Front Panel ..............8 Rear Panel .
  • Page 5 Contents RF Channel ...............29 Local Time .

  • Page 6: Remote Control Unit

    Remote Control Unit STAND BY NUMERIC BUTTON TV/STB TV/RADIO CH UP/DOWN VOL UP/DOWN MUTE PAUSE UP/DOWN LEFT/RIGHT MENU EXIT GREEN BUTTON YELLOW BUTTON / TIMER INFO(BLUE BUTTON) SUBTITLE(RED BUTTON) TEXT P.STD SLEEP RECALL A.L/R P.SIZE A.LANG Note 1 When inserting batteries, make sure that the polarity (+/-) is correct. The design of the Remote Control Unit may be changed without any notice in advance.
  • Page 7 Remote Control Unit STAND BY NUMERIC BUTTONS TV/STB TV/RADIO CHANNEL UP/DOWN VOLUME UP/DOWN MUTE PAUSE LEFT/RIGHT UP/DOWN EXIT MENU GREEN SUBTITLE(RED) YELLOW INFO(BLUE) P .STD P .SIZE A.L/R TEXT RECALL SLEEP A/LANG To switch between operation and stand by mode. To select the channel and enter the channel edit and PIN code.

  • Page 8: Front Panel

    Front Panel 1. POWER(STAND BY) 2. SEG. DISP . 3. CH 4. Smartcard Slot(Option) DIGITAL TERRESTRIAL RECEIVER Switch the receiver power "ON" or "OFF". 4-digit 7-segment display channel information. Channel Up/Down or select item of sub-menu. 1 shot for smartcard.

  • Page 9: Rear Panel

    Rear Panel 1. POWER SUPPLY 90-250V~ 50/60Hz. 2. RS-232 To connect to a personal computer for software upgrade. 3. VIDEO Video connection port to the TV or other equipment. 4. S/PDIF To connect a digital amplifier output. 5. AUDIO Audio connection port to the TV or other equipment. 6.

  • Page 10: Connecting Your Equipment

    Connecting Your Equipment How to connect your STB to various systems There are several ways of connecting the STB to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.
  • Page 11 Connecting Your Equipment TV with Terrestrial Antenna 1. Connect one end of RCA/Cinch cable to the RCA/ Cinch jack on the back of the STB and the other end to a RCA/Cinch jack on your TV. If your TV doesn’t have a RCA/Cinch jack, connect one end of RF cable to the TV OUT on the back of the STB and the other end to a RF input jack on your TV.

  • Page 12: Basic Operation

    Basic Operation Basic Function DIGITAL TERRESTRIAL RECEIVER 1. Program Information After the television channels have been programmed, you will see the information box each time you change the channels. 1. Every time you change channels you will receive program information for a few seconds.
  • Page 13 Basic Operation Basic Function 4. Channel-Information Banner 1. During "Channel Banner" is appearing, when you press INFO(BLUE) button, you can get "Channel-Information Banner". 2. Using "Channel-Information Banner", you can get a detailed channel listing information. 5. Volume Control/Mute 1. To control audio volume, press VOL 2.
  • Page 14 Basic Operation Basic Function DIGITAL TERRESTRIAL RECEIVER 7. Timer The user can reserve a desired program at a desired time by using the Timer function. 1. Once, Daily, Weekly Reservation. Use the , , , or buttons in the Timer Setting screen to select the date and time.
  • Page 15 Basic Operation Basic Function 9. Soundtrack 1. When you want to change the Audio Language of current channel, press the A.LANG button on the remote control. The on-screen menu is displayed on the left side of the screen. 2. Use buttons to choose the audio you want.

  • Page 16: Menu Guide

    Menu Guide Easy Installation DIGITAL TERRESTRIAL RECEIVER Before you can view the television or radio program, you must perform the installation procedure first. Therefore you will see only "Easy Installation Menu" at first when you plug in your system. The Easy Installation gives you the convenience of selecting various languages, adjusting the time and channel search.
  • Page 17 Menu Guide Easy Installation Language The first option is "Language Select" to select the desired language of the Menu, Audio, or Subtitle. Place the cursor on the sub menu by pressing the keys and press the OK button to change language. The Language of Menu, Audio, or Subtitle will be changed to the selected language.

  • Page 18: Main Menu

    Menu Guide Main Menu DIGITAL TERRESTRIAL RECEIVER Press the MENU button on the remote control unit. You will see the "Main Menu" on the screen. 1. You can move into the desired submenu using 2. You should enter the PIN code in order to move into the corresponding submenu in case of "Edit Channel List"...

  • Page 19: Channel Search

    Menu Guide Channel Search Select Automatic/Manual channel search in main menu. Automatic Search 1. Press Automatic Search in Main Menu. 2. Input a proper Start Frequency of the cable signal using NUMERIC buttons. 3. Input a proper End Frequency of the cable signal using NUMERIC buttons. 4.
  • Page 20 Menu Guide Channel Search DIGITAL TERRESTRIAL RECEIVER Select Automatic/Manual channel search in main menu. Manual Search 1. Press Manual Search in Main Menu. 2. Input a proper Frequency of the cable signal using NUMERIC buttons. 3. Input a proper Symbol Rate of the cable signal using NUMERIC buttons. 4.

  • Page 21: Channel List

    Menu Guide Channel List This menu helps you to easily select the channel that you want to watch. You can see the channel list when you had searched before. To use this menu, you should set channel group you want in the Edit Channel List menu. 1.

  • Page 22: Edit Channel List

    Menu Guide Edit Channel List DIGITAL TERRESTRIAL RECEIVER From these menus, You can edit favorite lists, lock, skip, delete, or move channel. 1. Select "Edit Channel List" in the main menu with and press OK button. 2. At the request window, Input PIN code. If you have not entered your own PIN code, then the PIN code 0000 applies, which was set at the factory.
  • Page 23 Menu Guide Edit Channel List 1. Favorite 1 ~ 4 1. You can edit favorite TV and Radio list. This enables you to create the 4 favorite TV and Radio lists. 2. Select the channel you want to edit favorite list and press OK button. Note To rename the Favorite channel, press INFO(BLUE) button.

  • Page 24: Program Guide

    Menu Guide Edit Channel List Program Guide DIGITAL TERRESTRIAL RECEIVER 5. Move 1. You can change the position of the channel you want on the TV/Radio/ All channel lists. 2. Select the channel you want to move to desired channel and press the OK button.
  • Page 25 Menu Guide Program Guide 1. Now/Next Program Guide Shows the information of Present/Following program on different channels. To watch the programs you go through the display window : 1. Select a program with buttons, you can get the list at right-side view. 2.

  • Page 26: System Setting

    Menu Guide System Setting DIGITAL TERRESTRIAL RECEIVER You will be asked to enter your PIN code before you can enter this menu. The PIN code preset to 0000 from the factory. The code can be changed from the "Change PIN Code" menu. Refer to page 30. If you want to customize the system to suit you better, you can specify some settings from the submenus in the "System Setting"...

  • Page 27: Subtitle Language

    Menu Guide System Setting 3. Subtitle Language In this menu You can change default language for subtitle when changing services. 1. Use the buttons to move to language you want and then press OK button. You can choose the language from a selection of English, Finnish, Swedish, Norwegian, Danish.

  • Page 28: Banner Time

    Menu Guide System Setting DIGITAL TERRESTRIAL RECEIVER 6. Banner Time When you switch channels, an information banner will be shown for a few seconds. You can select for how long the banner will be shown. 1. Select the banner time you want and then press OK button. 2.

  • Page 29: Menu Transparency

    Menu Guide System Setting 10. Menu Transparency From 20 to 63 will give the variable transparency on Video and OSD screen. Select an menu blending ratio and press OK button. The transparency will be applied on the screen. 11. Change PIN Code From here you can change the PIN code from the standard 0000.

  • Page 30: Parental Lock

    Menu Guide System Setting DIGITAL TERRESTRIAL RECEIVER Parent Rating If you select "on", you can change the Parental Lock. This function is - if you want the limited age, rating lock function select. 14. Menu Lock If you select "On", you will have to enter the PIN code every time when you enter the Channel Search Menu and Channel List Menu.

  • Page 31: Network Search

    Menu Guide System Setting 16. Auto Power 1. If the Auto Power is set to On and power is off, the Set turns on automatically and turns into the channel mode which you were watching before power breakdown. 2. If the Auto Power is set to Off and power is off, the Set turns into the standby mode.

  • Page 32: System Information

    Menu Guide System Setting DIGITAL TERRESTRIAL RECEIVER 19. OTA Upgrade To set up OTA Upgrade. It is possible to set up OTA upgrade manually. Please check if there is new software as pressing OK button after entering Frequency, Symbol Rate, Const.. Updated software will be downloaded.

  • Page 33: Ca System

    Menu Guide CA System The menus are provided by Smartcard. Your receiver is equipped with one Smartcard slot, Plug in the appropriate a valid Smartcard. You will then have access to the respective scrambled and Pay-Per-View services. Insert the Smartcard into the Smartcard Slot on the front panel. The Smartcard determine the programs that can be de-scrambled.

  • Page 34: Utility

    Menu Guide Utility DIGITAL TERRESTRIAL RECEIVER 1. Game 1. Select "Game" in the Utility menu with press buttons. 2. Select the game you want to play and press OK button, and then you can play the game. Tetris Hexa 2. Demonstration Select "Demonstration"...
  • Page 35 Menu Guide Utility 4. Zoom Select "Zoom" in the Utility menu with press OK on, the white frame will appear. 5. Mail Box You can check the messages sent by broadcasting stations. buttons and DIGITAL TERRESTRIAL RECEIVER...

  • Page 36: Troubleshooting

    Troubleshooting Problem No display LED on the front panel. No power supply No Picture Poor picture quality No Sound Remote Control does not operate Service is not running or scrambled. You have forgotten your secret PIN code. DIGITAL TERRESTRIAL RECEIVER Solution Power cord plug in correctly.

  • Page 37: Technical Specifications

    Technical Specifications Tuner Guard Interval Modes Channel Bandwidth FEC Modes Rate Input Connector Frequency Channel Bandwidth RF Modulator PLL type TV Standard RF Connector Frequency Range MPEG TS A/V Decoder Video Resolution Input Bit Rate Transport Stream Audio Decoding Audio Mode COFDM 2K/8K-Carrier 1/32, 1/16, 1/8, 1/4 1/2, 2/3, 3/4, 5/6, 7/8...

  • Page 38: Power Supply

    Technical Specifications A/V & Data Input/Output Video Audio RS-232C System Resources Flash Memory SDRAM Main CPU MPEG Chip Power Supply Input Voltage Power Consumption Protection Type Physical Specification Size(W × H × D) Net Weight Operating Temperature Storage Temperature Option Function Embedded CAS SW Upload DIGITAL TERRESTRIAL RECEIVER...

  • Page 39: Menu Map

    Menu Map Main Menu Channel List Edit Channel List Program Guide System Setting Automatic Search Manual Search CA System Utility Menu Language Audio Language Subtitle Language SCART Output Screen Type Banner Time RF Mode RF Channel Local Time Menu Transparency Change PIN Code Parental Lock Parent Rating...
