INSTRUCTION MANUAL
®
MultiGard 5000
System Integration
Modbus/TCP Gateway Option
1-800-MSA-INST or FAX (724) 776-8783
MSA International (412) 967-3354 or FAX (412) 967-3451
In Canada 1-800-267-0672 or FAX (416) 663-5908
© Mine Safety Appliances Company 2017 – All Rights Reserved
Manufactured by
MINE SAFETY APPLIANCES COMPANY
PITTSBURGH, PENNSYLVANIA 15230
3013-1048 Rev. 0
Advertisement
Related Manuals for MSA MultiGard 5000
Summary of Contents for MSA MultiGard 5000
- Page 1 MultiGard 5000 System Integration Modbus/TCP Gateway Option 1-800-MSA-INST or FAX (724) 776-8783 MSA International (412) 967-3354 or FAX (412) 967-3451 In Canada 1-800-267-0672 or FAX (416) 663-5908 © Mine Safety Appliances Company 2017 – All Rights Reserved Manufactured by MINE SAFETY APPLIANCES COMPANY PITTSBURGH, PENNSYLVANIA 15230 3013-1048 Rev.
-
Page 2: Msa Permanent Instrument Warranty
MSA Permanent Instrument Warranty 1. Warranty – Seller warrants that this product will be free from mechanical defect or faulty workmanship for a period of eighteen (18) months from date of shipment or one (1) year from installation, whichever occurs first, provided it is maintained and used in accordance with Seller’s instructions and / or recommendations. - Page 3 MultiGard 5000 system along with an Ethernet switch. This document is intended to cover all six models of the MultiGard 5000 System that are factory configured at MSA from two platforms. The models are 8 point, 16 point, dual 8 point, 24 point, 32 point, and dual 16 point.
- Page 4 The addresses will be placed onto labels located inside the MultiGard 5000 System enclosure for easy reference as well as in the system configuration document (part of the 3-ring binder).
- Page 5 4.0 Guidelines For Accessing Data Table Addresses Remember the following key items about the MultiGard 5000 System when using these tables to decide what is applicable: All Modbus data is read-only (holding register, 4X, or read input, 1X) except for the acknowledge items listed in Table 6 (force single coil, 0X).
- Page 6 5.0 Multigard System Data Table Addresses The most useful MultiGard 5000 System data will be defined in Tables 2 through 8 along with corresponding Modbus/TCP addresses. These addresses will allow for the presentation of gas...
- Page 7 Sensor Gas Levels Table 2: Point # Sensor 1 Sensor 2 Sensor 3 Sensor 4 40001 40002 40065 40066 40129 40130 40193 40194 40003 40004 40067 40069 40131 40132 40195 40196 40005 40006 40069 40070 40133 40134 40197 40198 40007 40008 40071 40072...
- Page 8 : Points 1-32 Alarm States Table 3 Sensor 1 Sensor 2 Sensor 3 Sensor 4 Point # Trouble Warning Alarm Trouble Warning Alarm Trouble Warning Alarm Trouble Warning Alarm 14098 14099 14100 14610 14611 14612 15122 15123 15124 15634 15635 15636 14130 14131...
- Page 9 Table 4: Flow Status Point # System A System B Sample Bypass Sample Bypass 18193 18257 18321 18353 18194 18258 18322 18354 18195 18259 18323 18355 18196 18260 18324 18356 18197 18261 18325 18357 18198 18262 18326 18358 18199 18263 18327 18359 18200...
- Page 10 Miscellaneous Table 5: Address Comments System A Position: 40525 Integer value = Point # System B Position: 40526 Integer value = Point # 0 = Sampling System A 40527 1 = Manual Calibration Operation Mode: 2 = Auto-Standardization System B 0 = Sampling 40528 1 = Manual Calibration...
- Page 11 Horn & Condition Acknowledges Table 7: Sequencer (A) Sequencer B Comments Coil - Write Horn Acknowledge: 08906 08941 (Momentary action is (Push Button) necessary.) 08656 08683 Coil - Write Condition Acknowledge: (Momentary action is (Push Button) necessary.) User Configured Output (UCO) Relay Images Table 8: Output # UCO#1...
