  • Page 1 BUILT-IN OVEN OB24 Single models USER GUIDE US CA...

  • Page 3: Table Of Contents

    CONTENTS Safety and warnings Introduction First Use Using the Timer Cooking guide Oven functions Cooking charts Automatic cooking Using the Meat Probe (some models only) User preference settings Sabbath setting Care and cleaning Using the Self Clean function (some models only) Trouble shooting Alert codes Warranty and service...

  • Page 4: Safety And Warnings

    SAFETY AND WARNINGS Your oven has been carefully designed to operate safely during normal cooking procedures. Please keep the following safety instructions in mind when you are using it: WARNING! Electrical Shock Hazard Turn the oven off at the wall before replacing the oven lamp. Failure to follow this advice may result in electrical shock or death.
  • Page 5 SAFETY AND WARNINGS WARNING! Cut Hazard Take care - some edges are sharp. Failure to use caution could result in injury or cuts. IMPORTANT SAFETY INSTRUCTIONS! To reduce the risk of fire, electrical shock, injury to persons or damage when using the oven, follow the important safety instructions listed below: Read all the instructions before using the oven.
  • Page 6 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! User servicing: do not repair or replace any part of the appliance unless specifically ● recommended in the manual. All other servicing should be referred to a qualified technician. Do not use water on grease fires. Smother the fire or flame or use a dry chemical or ●...
  • Page 7 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! Before starting a Self Clean cycle (some models only) remove oven shelves and all ● other cookware/utensils, and wipe up large food spills or grease deposits. Before starting a Self Clean cycle (some models only) make sure you move any pet ●...

  • Page 9: Introduction

    INTRODUCTION Congratulations on your new purchase. Your Fisher & Paykel oven has a number of features to make cooking a great experience for you: a wide choice of oven functions ● intuitive controls and displays ● Before you start Make sure the installer has completed the ‘Final checklist’ in the Installation instructions. ●...

  • Page 10: First Use

    FIRST USE Your oven comes with two shelves positioned and secured inside The following shows you how to remove and reposition the shelves to your preferred ● position We recommend you then condition the oven. ● Remove all cable ties and packaging holding the shelving in place Remove shelves from the oven...
  • Page 11 FIRST USE Replace shelving in your preferred positions Shelf positions To replace a wire shelf: Check the guard rail (as shown) to make sure ● the shelf is the right way up. Slide it horizontally back along the side racks ●...
  • Page 12 FIRST USE - THE CONTROL PANEL Temperature Illustrative purposes only - Function halo indicator oven function indicators may vary. Function dial 1 2 00 REMOTE Temperature halo Function indicators (see ‘Oven functions’) Temperature dial Display Timer indicator Some models only (see’...
  • Page 13 FIRST USE Setting the Clock When your oven is first turned on, or after a power cut, the display will flash . You will need to set the clock in order to use the oven. 2 4 Hr 1 2 Hr ...
  • Page 14 FIRST USE Changing the time You set the clock within the user preference menu. 2 4 Hr 1 2 Hr 1 To enter the user preference menu 3 Touch the right scroll control to   touch and hold the left and right scroll between ...
  • Page 15 FIRST USE 2 Set the temperature to 400 F (200 C) for 30 1 Select the Bake function. minutes. The halo will glow white. ● While the oven is heating up, the Each function has a preset ● ● temperature halo will glow red and the temperature and so the oven temperature indicator will alternately show will start heating at the Bake...

  • Page 16: Using The Timer

    USING THE TIMER You can use the timer at any time, even if you are not using the oven. ● The timer counts down in minutes (hr:min) until the last hour of cooking when it will ● countdown in seconds (min:sec). You can set the timer for up to 23 hours 59 minutes.

  • Page 17: Cooking Guide

    COOKING GUIDE General guidelines This oven has been designed to utilise its four elements and rear fan in differing combinations to provide you with enhanced performance and a wide range of functions, allowing you to cook all types of food to perfection. Outer Shelf positions - Full size ovens Element...
  • Page 18 COOKING GUIDE ROASTING The Roast function is designed to brown the outside of the meat but still keep the inside ● moist and juicy. Boneless, rolled or stuffed roasts take longer than roasts containing bones. ● Poultry should be well cooked with the juices running clear and an internal temperature ●...
  • Page 19 COOKING GUIDE REHEATING Use Bake, Fan Bake or Vent Bake to reheat food. ● Bake and Vent Bake are particularly good for reheating pastry based items, as the base ● heat will help re-crisp the pastry case. Always reheat food to piping hot. This reduces the risk of contamination by harmful ●...

  • Page 20: Oven Functions

    OVEN FUNCTIONS IMPORTANT! Depending on your model, you may only have some of these functions. ● Use all the functions with the oven door closed. ● Bake upper outer and lower elements Heat comes from both the upper and lower elements. The fan is not used in this ●...
  • Page 21 OVEN FUNCTIONS Aero Bake fan plus upper outer and lower elements The oven fan circulates hot air from the top outer and the lower elements and ● distributes it around the oven cavity. Food cooked tends to brown more quickly than foods cooked on the traditional Bake ●...
  • Page 22 OVEN FUNCTIONS Aero Broil fan plus upper inner and outer elements This function uses the intense heat from the elements for top browning and the fan to ● ensure even cooking of foods. Meat, poultry and vegetables cook beautifully; food is crisp and brown on the outside ●...
  • Page 23 OVEN FUNCTIONS Aero Pastry fan plus lower element The fan circulates heat from the lower element throughout the oven. ● Excellent for cooking pizza as it crisps the base beautifully without overcooking the ● topping. Ideal for foods such as sweet and savoury pastry foods and delicate foods that require some top browning eg frittata, quiche.
  • Page 24 OVEN FUNCTIONS Classic Bake (some models only) lower element only Heat comes from the lower element only, the fan is not used. ● This is the traditional baking function, suitable for recipes that were developed in older ● ovens. Bake on only one shelf at a time. ●...
  • Page 25 OVEN FUNCTIONS this is not a cooking function Provides a constant low heat of less than 195°F (90°C). ● Use to keep cooked food hot, or to warm plates and serving dishes. ● To reheat food from cold, use another oven function to heat the Warm food piping hot and only then change to Warm, as this function alone will not bring cold food up to a high enough temperature to...

  • Page 26: Cooking Charts

    COOKING CHARTS Shelf positions are counted from the base up ● (1 is the lowest, 6 (full size ovens) or 4 (compact ovens) is the highest). Position shelves before you turn the oven on. For best results preheat the oven to the required temperature. ●...
  • Page 27 COOKING CHARTS The information in these charts are guidelines only. Refer to your recipe or the packaging and be prepared to adjust the cooking times and settings accordingly. RECOMMENDED SHELF TEMP (°F) TEMP (°C) TIME (MINS) FUNCTION POSITIONS Aero Bake 400 - 425 210 - 220 8 - 10...
  • Page 28 COOKING CHARTS SAVOURY FOOD SHELVES Single Cornbread Vegetables Single Lasagne Single Casserole Single Pizza Single Quiche (blind bake, then Single add filling) Potatoes (whole, baked) Single Frittata (shallow) Single Oven Meals Single ROASTING RECOMMENDED FOOD SHELVES * FUNCTION Rare Single Roast Beef (Boneless) Medium...
  • Page 29 COOKING CHARTS RECOMMENDED SHELF TEMP (°F) TEMP (°C) TIME (MINS) FUNCTION POSITIONS Aero Bake 400 - 425 210 - 215 20 - 25 Vent Bake 350 - 375 175 - 190 30 - 50 Aero Bake 2 or 3 350 - 375 175 - 190 35 - 40 Bake...
  • Page 30 COOKING CHARTS BROILING FOOD SHELVES Beef Steak Rare Single Medium Single Hamburger Single (ground - patties) Meatballs Single (ground) Medium Single Lamb Chops Well done Single Chops (well done) Single Pork Ham steak Single Bacon Single Boneless pieces Single Chicken Bone In Pieces Single Sausages...
  • Page 31 COOKING CHARTS RECOMMENDED SHELF TEMP (°F) TEMP (°C) TIME (MINS) FUNCTION POSITIONS Maxi Broil 5 or 6 8-10 Maxi Broil 5 or 6 10-15 Maxi Broil 12-15 Maxi Broil 12-15 Maxi Broil 5 or 6 15-20 Maxi Broil 5 or 6 20-25 Maxi Broil 5 or 6...

  • Page 32: Automatic Cooking

    AUTOMATIC COOKING You can set the oven to automatically turn on later, cook for a preset time (cooking ● time), then automatically turn off at a preset stop time. See the example and instructions below (steps 1 to 7). If you start cooking manually and only want the oven to turn off automatically after a ●...
  • Page 33 AUTOMATIC COOKING Select function and temperature !0 Select a function. !1 Adjust the temperature. The function halo will stop flashing. When automatic cooking is set The oven and the lights will stay off, the halos will be unlit, but your oven is now set for ●...

  • Page 34: Using The Meat Probe (Some Models Only)

    USING THE MEAT PROBE (SOME MODELS ONLY) Using the meat probe Use your meat probe to accurately judge when your meat is perfectly cooked. You can use the probe with any function. 1 Select the oven function and temperature. Preheat the oven if appropriate. Remember Roast and Aero Broil do not require preheating.
  • Page 35 USING THE MEAT PROBE (SOME MODELS ONLY) 5APress the right scroll 6 Use the scroll button 4 times buttons to set the and the meat probe indicator will required meat temperature. come on and the display will show 150. 5BPress the select button to confirm.

  • Page 36: User Preference Settings

    USER PREFERENCE SETTINGS You can set your oven to: display the temperature in degrees Celsius or Fahrenheit ● give audio feedback (tones and beeps) or operate quietly ● display time as 12-hr or 24-hr ● operate with the display off ●...
  • Page 37 USER PREFERENCE SETTINGS How to change preference settings 1 1 05 2 4 Hr 1 Check the oven function dial is set to 2 Touch and hold the scroll controls OFF and that the display shows the together for 3 seconds to enter the time of day.
  • Page 38 USER PREFERENCE SETTINGS 5 Touch the right scroll 6 Touch the select control to scroll control to save the through the options for that particular new option . 7 For all options except ‘Display off’ : setting. Refer to the table below. touch the cancel control to quit the user preference menu.
  • Page 39 USER PREFERENCE SETTINGS SETTING DEFAULT OPTION ALTERNATIVE OPTION(S) TIME SCALE & ‘DISPLAY 12 HR DISPLAY OFF ** 24 HR OFF’ OPTION Select between 24-hr or 12-hr clock display    (and set the clock) or set ‘Display off’ option if you only need the basic functionalities of your oven.

  • Page 40: Sabbath Setting

    SABBATH SETTING This setting is designed for religious faiths that observe a ‘no work’ requirement on the Sabbath. While your oven is in Sabbath setting The display, dial halos and indicators will be unlit, the controls will be unresponsive. ● No tones or beeps will sound.
  • Page 41 SABBATH SETTING 2 0 00 2 0 00 5 Touch the scroll controls to set the 6 Touch the select control to confirm time (hrs). You may set the time up to the time. 48 hours. The function halo will flash. ●...

  • Page 42: Care And Cleaning

    CARE AND CLEANING Manual cleaning ALWAYS NEVER Before any manual cleaning or Never use a steam cleaner. ● ● maintenance, first wait for the oven to Never store flammable substances in the ● cool down to a safe temperature to oven.
  • Page 43 CARE AND CLEANING Manual cleaning WHAT? HOW? IMPORTANT! Take particular care when cleaning Control Panel Do not use any oven cleaners, the control panel glass. Only use a harsh or abrasive cleaners, damp cloth with detergent. scouring pads, steel wool or sharp metal scrapers on the glass.
  • Page 44 CARE AND CLEANING Manual cleaning WHAT? HOW? IMPORTANT! Remove everything from the Oven cavity To prevent soiling from ● ● oven: all shelves and trays, the becoming ‘baked on’ and side racks (including fixing nuts). (models without stubborn, we recommend ‘Selfclean’...
  • Page 45 CARE AND CLEANING Manual cleaning WHAT? HOW? IMPORTANT! Wipe with a damp cloth and mild Full extension Never leave in the oven during detergent. Do not wipe off or wash sliding shelf a Self Clean cycle. away the white lubricating grease Do not wash the shelf in the (visible when the shelf is dishwasher, immerse in soapy...
  • Page 46 CARE AND CLEANING Removing the side racks Remove the side racks to make cleaning the oven easier. For models with Self Clean only: The side racks can be left in the oven during the self clean cycle. IMPORTANT! Always turn off the oven at the wall first. Ensure the oven has cooled down completely before starting.
  • Page 47 CARE AND CLEANING Refitting the side racks 1 Slide the rear prongs of the side rack into the holes at the rear of the oven 2 Fit the side rack front tab over the fixing screw. 3 Replace the fixing nut. You may use a coin to tighten the nut. Insert rear prongs into holes...
  • Page 48 CARE AND CLEANING Drop-down upper element (models without a Self clean function only) IMPORTANT! Always turn off the oven at the wall before lowering the upper element. Make sure the oven has cooled down completely before starting. To lower the upper element: Pull both the securing clips forward to release the element. ●...
  • Page 49 CARE AND CLEANING Replacing the oven light bulbs Note: Oven bulb replacement is not covered by your warranty. Your oven uses G9 halogen bulbs with the specifications 120V, 50Hz and 25W. Always hold the replacement bulb in a soft cloth. Touching the bulb will reduce its life- span.
  • Page 50 CARE AND CLEANING Removing and refitting the oven door. IMPORTANT! Take care, the oven door is heavy. To remove the door 1 Open the door fully. 2 Push each locking lever 3 Holding the door on Locate the two small down fully to release both sides, lift door metal locking levers...

  • Page 51: Using The Self Clean Function (Some Models Only)

    USING THE SELF CLEAN FUNCTION (SOME MODELS ONLY) During the pyrolytic Self Clean cycle the extremely high temperature burns off and ● breaks down grime and grease deposits. All that is left is a small amount of grey ash that you can easily remove. There is a choice of two Self Clean cycles: ●...
  • Page 52 USING THE SELF CLEAN FUNCTION (SOME MODELS ONLY) 5 Select the Self Clean function.   The display will flash ● 6 Touch the right scroll control once for the Self Clean cycle 0 00   - the display will flash (4 hours), or Touch the right scroll control a second time...
  • Page 53 USING THE SELF CLEAN FUNCTION (SOME MODELS ONLY) When a Self Clean cycle has finished The oven will: emit a long tone ● automatically turn off ● automatically unlock the door (when the oven has cooled to a safe temperature). ●...

  • Page 54: Troubleshooting

    TROUBLESHOOTING Troubleshooting chart If there is a problem, check the chart below to see if you can fix it. If the problem cannot be fixed or persists, call your Authorized Repairer or Customer Care. PROBLEM POSSIBLE CAUSES WHAT TO DO General The oven does not work.
  • Page 55 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO General I can feel hot air This is normal. For safety reasons the cooling fans will continue blowing out of the vents to run even when you have after I have turned the turned the function dial to oven off.
  • Page 56 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO Self Clean function (some models only) During a Self Clean This is normal: the oven’s cooling fans operate at their highest cycle, the oven is louder speed. than usual. The oven door is locked Wait until the Self Clean cycle has The display shows ...

  • Page 57: Alert Codes

    ALERT CODES If there is a problem, the oven will: automatically suspend all oven functions ● beep five times ● display an alert code. ● IMPORTANT! Do not turn off the mains power supply to the oven (wall switch) if you get an alert code, unless the instructions in the chart following specifically instruct you to.
  • Page 58 ALERT CODES ALERT CODE POSSIBLE CAUSES WHAT TO DO  The oven has overheated. 1 Allow the oven to cool down. 2 Once the oven has cooled down and the door has unlocked, the alert code will disappear. You can now use the oven again.

  • Page 59: Warranty And Service

    WARRANTY AND SERVICE Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: 1 Your product is correctly installed. 2 You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &...
  • Page 60 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2017. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
