PARTS LIST
1-
Main Center Pole
2 -
Leg & Handle Bar Pole
3-
Handle Bar with Foam
x2
6A-
Leg with Upper Openings
x2
7-
Large Plastic Tube
x1
9-
Seat
x2
MODEL# 9307SS
x1
x2
4-
5 -
Upper Support Tube
Lower Support Tube
x1
6B-
Leg with Lower Openings
x2
8 -
Small Plastic Tube
x2
15 -
Bolt M8×70mm
16 -
Bolt M8×65mm
17 -
Bolt M8×115mm
x1
18 -
Bolt M8×95mm
19 -
Bolt M6×20mm
x8
28 -
Allen Wrench
29 -
Wrench
30 -
Wrench 2
20-
M8 Large Arc Washer
x1
x8
21-
M8 Small Arc Washer
x4
x12
22-
M8 Flat Washer
x4
x2
23-
M6 Flat Washer
x2
x8
24-
M8 Nut Cap
x11
25-
M6 Nut Cap
x1
x8
26-
M8 Spring Washer
x1
x11
x1
27-
M6 Spring Washer
x8
5
