INTRODUCTION
OPERATORS' MANUAL
INVERTER MIG Welding Machine
IMPORTANT: Read this Owner's Manual Completely before attempting to use this
equipment. Save this manual and keep it handy for quick reference. Pay particular
attention to the safety instructions we have provided for your protection. Contact your
distributor if you do not fully understand this manual.
201507
Ⅰ I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTIMIG 350F and is the answer not in the manual?

Questions and answers

Related Manuals for Top Gun MULTIMIG 350F

Summary of Contents for Top Gun MULTIMIG 350F

  • Page 1 INTRODUCTION OPERATORS’ MANUAL INVERTER MIG Welding Machine IMPORTANT: Read this Owner’s Manual Completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your distributor if you do not fully understand this manual.

  • Page 2: Table Of Contents

    CONTENT CONTENT §1 Safety ..................1 §1.1 Signal Explanation ....................... 1 §1.2 Arc Welding Damage ....................1 §1.3 The knowledge of Electric and Magnetic Fields ............5 §2 Overview ..................7 §2.1 Brief Introduction ......................7 §2.2 Working Principle ......................8 §2.3 Volt-Ampere Characteristic ..................

  • Page 3: Safety

    SAFETY 1 Safety § §1.1 Signal Explanation  The above signals mean warning! Notice! Running parts and getting an electric shock or thermal parts will take damage for your body or others. The corresponding notices are as follows. It is quite a safe operation after taking several necessary protection measures.
  • Page 4 SAFETY Ensure to install the equipment correctly and ground the work or metal to be welded to a good electrical (earth) ground according the operation manual. The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts with your bare skin or wet clothing. Wear dry, hole-free gloves to insulate hands.
  • Page 5 SAFETY degreasing, cleaning or spraying operations. The heat and rays of the arc can react with solvent vapors to form phosgene, a highly toxic gas, and other irritating products.  Shielded gases used for arc welding can displace air and cause injury or death. Always use enough ventilation, especially in confined areas, to insure breathing air is safe.
  • Page 6 SAFETY Do not spill fuel when filling tank. If fuel is spilled, wipe it up and do not start engine until fumes have been eliminated. WELDING SPARKS can cause fire or explosion.  Remove fire hazards from the welding area. If this is not possible, cover them to prevent the welding sparks from starting a fire.

  • Page 7: The Knowledge Of Electric And Magnetic Fields

    SAFETY Rotating parts may be dangerous.  Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. All hoses, fittings, etc. should be suitable for the application and maintained in good condition.
  • Page 8 SAFETY  Never coil the power cable around your body.  Make sure welding machine and power cable to be far away from the operator as far as possible according to the actual circumstance.  Connect the work cable to the workpiece as close as possible to the area being welded.

  • Page 9: Overview

    2. High performance multifunction power source (MIG/MAG); 3. Waveform control, stable welding arc; 4. IGBT technology, low power dissipation; 5. Rated duty circle：MULTIMIG 350F and MULTIMIG400F are 60%(40℃),MULTIMIG 500F is 60%(40℃). MIG F SERIES arc welding machine is suitable for all positions welding for various plates...

  • Page 10: Working Principle

    OVERVIEW §2.2 Working Principle The working principle of MIG F SERIES arc welding machine is shown as the following figure. Three-phase 380V work frequency AC is rectified into DC（530V）, then is converted to medium frequency AC (about 20KHz) by inverter device (IGBT), after reducing voltage by medium transformer (the main transformer) and rectifying by medium frequency rectifier (fast recovery diodes), and is outputted by inductance filtering.
  • Page 11 OVERVIEW §2.4Principles of welding...

  • Page 12: Installation And Adjustment

    OPERATION §3 Installation and Adjustment §3.1 Parameters Models MULTIMIG 350F SYN MULTIMIG 400F SYN MULTIMIG 500F SYN Parameters Input Voltage（V） 3~380/400/440±10% 3~380/400/440±10% 3~380/400/440±10% Frequency (HZ) 50/60 50/60 50/60 MIG 19 TIG 15 MMA 21 MIG 24 TIG 19 MMA 25.5 MIG 33 TIG 27.5 MMA 35...

  • Page 13: Equipment Connection

    OPERATION If transformer is over-heat, the heat relay inside it will open and will output an instruction to circuit board, cut AC relay and the output welding current, and brighten the over-heat pilot lamp in the front panel. At this time, the machine should be relaxed for 15 minutes to cool the fan. When operating the machine again, the welding output current or the duty cycle should be reduced.

  • Page 14: Maintenance Of Mig Gun Mechanism

    OPERATION 8.Connect the shielded gas pipe on the welding gun with the gas output on the panel of wire feeder. 9.Connect the switch control cable of welding gun with the two-lead aero socket on the panel of wire feeder. 10.When installing wire reel, make sure the wire diameter is accordant with wire wheel and welding gun’s tip, and press the wire properly.
  • Page 15 OPERATION §3.4.3 The operation for the MIG GUN 1. Service the wire feed mechanism at least every time the reel is changed. ·Check the wear of the feed roll groove and change the feed roll when necessary. ·Clean the welding gun wire guide with compressed air. 2.

  • Page 16: Maintenance Of The Wire Feed Mechanism

    OPERATION 3.Wife feeder Parts Welding Voltage and other parameter regulator Welding Current and other parameter regulator Inductance regulator Manual wire key Air check key Water /Air selecting key 2T/4T welding mode selecting key Pre flow/Post flow/Soft start/Burn back selecting key MIG gun connector Spool gun connector water connector...
  • Page 17 OPERATION Changing the feed roll groove The feed roller (No.16 in the picture) is factory set for welding filler wires of 08-1.0mm and 0.6mm diameter on the other side. The feed roller side must be changed if you use 0.6mm thick filler wire.

  • Page 18: Operation

    OPERATION §4 Operation §4.1 Layout for the front and rear panel 1. Output cathode: When MIG mode, this polarity must connect the work piece. 2. Shield gas connector: Is connected to the gas input pipe of torch. 3. Aviation plug : TIG gun control connecter. 4.
  • Page 19 OPERATION 8. Power source input: To connect power source. 9. water box connector: To connect water box. 10.On/off switch: Control the power supply on and off. 11. Parameter select and adjust knob: Control the parameter select and adjust. 12. Alarm Led: When the welder is over voltage, less voltage, over current or over heated, the alarm pilot lamp will be on.

  • Page 20: Welding Operation

    OPERATION 25. 2T welding mode LED: When the 2T welding mode LED is on ,it can 2T welding mode,2T is suitable for the short welding. 26. 4T welding mode LED: When the 4T welding mode LED is on ,it can 4T welding mode, 4T is suitable for the long welding.

  • Page 21: Operation Environment

    OPERATION §4.4 Operation environment Height above sea level ≤1000 M ▲ ▲ Operation temperature range -10～+40℃. ▲ Air relative humidity is below 90 %( 20℃). ▲ Preferable site the machine some angles above the floor level, the maximum angle does not exceed 15℃.

  • Page 22: Maintenance & Troubleshooting

    THANK YOU FOR USING OUR PRODUCTS §5 Maintenance & Troubleshooting §5.1 Maintenance In order to guarantee that arc welding machine works high-efficiently and in safety, it must be maintained regularly. Let customers understand the maintenance methods and means of arc welding machine more , enable customers to carry on simple examination and safeguarding by oneself, try one's best to reduce the fault rate and repair times of arc welding machine, so as to lengthen service life of arc welding machine .Maintenance items in detail are in the following...

  • Page 23: Troubleshooting

    THANK YOU FOR USING OUR PRODUCTS Using the dry compressed air to clear the inside of arc welding machine. Especially for clearing up the dusts on radiator, main voltage transformer, inductance, IGBT module, the fast recover diode and PCB, etc. Monthly Check up the bolt in arc welding machine, if it is loose, please screw down it.
  • Page 24 THANK YOU FOR USING OUR PRODUCTS If there are some simple troubles of MIG F SERIES welding machine, you can consult the following Chart: Troubles Reasons Solution Breaker damaged Change it Close the breaker, but the Fuse damaged Change it power light isn’t on Power damaged Change it...

  • Page 25: Electrical Schematic Drawing

    THANK YOU FOR USING OUR PRODUCTS §5.3 Electrical schematic drawing -23-...
