OPERATOR'S MANUAL
AIR PLASMA CUTTER
CUT 65 CNC
IMPORTANT: Read this Owner's Manual Completely before attempting to use this
equipment. Save this manual and keep it handy for quick reference. Pay particular
attention to the safety instructions we have provided for your protection. Contact your
distributor if you do not fully understand this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUT 65 CNC and is the answer not in the manual?

Questions and answers

Related Manuals for Top Gun CUT 65 CNC

Summary of Contents for Top Gun CUT 65 CNC

  • Page 1 OPERATOR’S MANUAL AIR PLASMA CUTTER CUT 65 CNC IMPORTANT: Read this Owner’s Manual Completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your...

  • Page 2: Table Of Contents

    CONTENT §1 SAFETY ....................................2 §2 TECHNOLOGY PARAMETERS ............................. 4 2.1 W ..........................4 ORKING PRINCIPLE OF MAIN CIRCUIT 2.2 P ..................................4 ARAMETERS 2.3 F : ..................................5 EATURES §3 INSTALLATION ................................6 3. 1 U ..................................6 NPACKING 3.2 I ............................

  • Page 3: Safety

    §1 SAFETY Important Safety Precautions OPERATION AND MAINTENANCE OF PLASMA ARC EQUIPMENT CAN BE DANGEROUS TO YOUR HEALTH.  Plasma arc cutting produces intense electric and magnetic emissions that may interfere with the proper function of cardiac pacemakers, hearing aids, or other electronic health equipment. Persons who work near plasma arc cutting applications should consult their medical health qualified technician and the manufacturer of the health equipment to deter- mine whether a hazard exists.
  • Page 4  Never touch any parts that are electrically “live” or “hot.”  Wear dry gloves and clothing. Insulate yourself from the work piece or other parts of the cutting circuit.  Repair or replace all worn or damaged parts.  Extra care must be taken when the workplace is moist or damp.

  • Page 5: Technology Parameters

    Current positive- feedback control Figure 2.1 Working principle diagram 2.2 Parameters Table2.1 Technical parameters Models CUT 65 CNC Parameters Rated input voltage（V） 3-380V±10%，50/60Hz Rated input current（A） Rated input power（KW） Cutting current adjustment range （A） 20～65 No-load voltage (V)

  • Page 6: Features

    2.3 Features: IGBT parallel balanced current technology and digital control technology. Wider input voltage flexibility provides peak performance power under variable conditions (±15%) for steady cuts. EMI filter restrains the EMI transmission of the power. Starts without high-frequency so it will not interfere with controls or computers. Pilot Arc Controller increases cutting capabilities and speeds, and improves tip life.

  • Page 7: Installation

    §3 Installation 3. 1 Unpacking Use the packing lists to identify and account for each item. Inspect each item for possible shipping damage. If damage is evident, contact your distributor and / or shipping company before proceeding with the installation. When using forklift, its arm length must be long enough to reach the outside so as to ensure lifting safely.

  • Page 8: Operation

    §4 Operation 4.1 Layout Of The Front And Rear Panel Fig 4.1 schematic drawing of the front panel and rear panel 1.Cutting current regulator: it is used to regulate the current when cutting. 2. Power pilot lamp 3. Alarm pilot lamp: This pilot lamp indicates when lit that the protection of the machine has been activated. 4.

  • Page 9: Cutting Preparation

    11. Mains cable: Connected to the appreciate power supply 12. Power switch: turn on or off the power source 4.2 Cutting Preparation Tightly connect the power cable to electrical socket outlet (the input voltage, refer to the section 2 technology parameters) Tonnect the air pipe to the air supply equipment, the earth cable to the workpiece Turn on the power switch ,the power source lamp on.

  • Page 10: Maintenance

    §5 Maintenance 5.1 Cutting gun maintenance Warning : 1. Check the consumable parts for damage, if worn, replace it. 2. Turn off the power source before check or remove cutting gun parts Note: When operating the torch in a normal condition, a small amount of gas vents through the gap between the shield cup and the torch handle, Do not attempt to over tighten the shield cup as irreparable damage to internal components may result.

  • Page 11: Troubleshooting Principle

    5.2 Troubleshooting Principle WARNING There are extremely dangerous voltage and power levels present inside this unit. Do not attempt to diagnose or repair unless you have had training in power electronics measurement and troubleshooting techniques. A. Power lamp and temperature lamp on. Air flow blocked, check for blocked air flow around the unit and correct condition.
  • Page 12 F. Arc shuts off during operation; arc will not restart when torch switch is activated. Power Supply is overheated, let unit cool down for at least 5 minutes. Make sure the unit has not been operated beyond Duty Cycle limit. Refer to Section 2 for duty cycle specifications. Gas pressure too low, check source for at least 4bar/60psi;...

  • Page 13: Electrical Principle Drawing

    5.3 Electrical principle drawing...
