Importing A Job And Making Job Settings - EFI Fiery proServer SE Quick Start Manual

5 Select "Connect using different credentials".
6 Click Finish.
The Windows Security window is displayed.
7 Type the VUTEk credentials.
Both the user name and the password are vutek01.
8 Select "Remember my credentials", and click OK.
Windows sets up a connection to the Import folder, and the mapped drive appears in File
Explorer. To create a shortcut on the Fiery proServer desktop, click the Windows icon, click
File Explorer and drag the mapped drive to the desktop.

Importing a job and making job settings

By default, jobs are printed using the settings that have been made for the workflow. You can
override the workflow settings by applying job-specific settings to a loaded job. The following
steps give examples of how to load a job and make basic job settings. To make job settings,
you must click the job in the job list.
T
O IMPORT A JOB AND MAKE JOB SETTINGS
1 In the toolbar, click Job Explorer.
2 In the toolbar, click Import Job.
3 Browse to your job, and click Open.
4 In the Import to dialog box, click Hold Job.
Held jobs are not immediately processed in Fiery XF. After you have made job settings, you
can start job processing manually.
5 To rotate a job: In the preview window, right-click the preview, point to Rotate and click an
item.
6 To scale a job: In the preview window, right-click the preview, point to Scale, point to Fit to,
and then click Sheet Width.
7 To align a job on the sheet: On the Layout tab, open the Layout Options pane. Select an
alignment by clicking the appropriate cell in the diagram. Define job margins, if required.
8 To select a different calibration set: On the Output tab, open the Media Configuration pane.
Under "Calibration set", select a calibration set.
A calibration set is a combination of base linearization file and ICC profile. Fiery XF provides
a variety of calibration sets for different media types.
You can create copies of output devices and select different default calibration sets for each.
This can be useful if a hotfolder has been explicitly set up for a certain media type.
9 To change or remove the job ticket: On the Layout tab, open the Job Ticket pane.
8
