Specifications

Mechanical Specifications:
Width:
Height:
Depth:
Weight:
Electrical Specifications:
Backlight OFF, Sound OFF, WIFI ON
Backlight ON, Sound OFF, WIFI ON
Backlight ON, Sound ON, WIFI ON
Operating Environment: Humidity
Temperature: Operating
Temperature: Shipping / Storage
ACE type

SD/SDHC Card Slot and Reset Button

The Galaxy TouchCenter Plus has a media card slot and reset button located behind the panel as shown below.
Note: If you need to insert a media card or access the reset button remember to do so before securing the keypad in
place.
Note: When EN50131 Mode* is enabled the system status line at the top of the keypad is not displayed.
*The EN50131 Display compliance feature is a European Standard designed to prevent unauthorized users from
viewing the status of the Security System.
About the System (cont'd)
218 mm
162 mm
34 mm
629 g
9.6 VDC 12 VDC
170 mA 140 mA
280 mA 225 mA
340 mA 260 mA
93% RH, non-condensing
−10˚C to 55˚C
−40˚C to 70˚C
Type B (fixed equipment)
8
13.8 VDC
130 mA
200 mA
250 mA
