HARDWARE INSTALLATION GUIDE
Brocade X6-8 Director
Hardware Installation Guide
53-1004105-07
12 May 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X6-8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems X6-8

Summary of Contents for Brocade Communications Systems X6-8

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade X6-8 Director Hardware Installation Guide 53-1004105-07 12 May 2017...
  • Page 2 United States government. The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Parts list – NEBS kit............................................. 33 Assembling the rack hardware......................................... 34 Installing the device in the rack........................................ 37 Installing the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121)..................39 Time and Items required..........................................40 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 4 Interpreting core routing blade LEDs......................................91 Interpreting WWN card LEDs..........................................93 Interpreting power supply LEDs........................................94 Interpreting fan assembly LEDs........................................96 Interpreting POST and boot results.........................................98 POST.................................................. 98 Boot..................................................99 Using monitoring commands..........................................99 chassisShow..............................................99 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 5 Blade fault indicators............................................145 Blade replacement task guide........................................146 Replacing CP blade (hot-swap)......................................146 Replacing a CP blade (cold-swap).......................................146 Time and items required for replacement....................................147 Preparing for replacement..........................................147 Replacing a CP blade............................................148 Hot-swap procedure..........................................148 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 6 Fan assembly task guide..........................................189 Replacing fan assembly (hot-swap)....................................190 Replacing fan assembly (cold-swap)....................................190 Time and items required........................................... 190 Removing a fan assembly ..........................................190 Installing a fan assembly...........................................192 Verifying fan operation............................................192 Blade Filler Panels......................................... 193 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 7 Power consumption for HVAC/HVDC power supplies (typical configuration)......................224 Power consumption for HVAC/HVDC power supplies (idle configuration)........................ 225 Power consumption for HVAC/HVDC power supplies (maximum configuration)....................225 Power consumption (modules)........................................226 Fibre Channel data transmission ranges....................................227 Data port specifications (Fibre Channel).....................................227 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 8 Cautions and Danger Notices..................................... 233 Cautions................................................... 233 General cautions............................................233 Electrical cautions............................................235 Cautions related to equipment weight....................................237 Danger Notices..............................................238 General dangers............................................238 Dangers related to equipment weight....................................238 Electrical dangers............................................239 Laser dangers.............................................. 241 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 9: Preface

    Identifies command names. Identifies keywords and operands. Identifies the names of GUI elements. Identifies text to enter in the GUI. italic text Identifies emphasis. Identifies variables. Identifies document titles. Identifies CLI output. Courier font Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 10: Command Syntax Conventions

    By sending your feedback to documentation@brocade.com Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 11: Contacting Brocade Technical Support

    Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise. For more information, contact Brocade or your OEM. • For questions regarding service levels and response times, contact your OEM/solution provider. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 12 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 13: About This Document

    Fabric OS 8.0.1 CR32-8 blade XBR-X68-0106 Core routing (CR) blade with 16 4x32 -Gbps Fabric OS 8.0.1 QSFP+ ports for Brocade X6-8 Director. SX6 blade XBR-SX6-0000 Extension (X) blade with 16 32-Gbps Fibre Fabric OS 8.0.1 Channel SFP+ ports, 16 10-GbE SFP+ ports,...

  • Page 14: What Is New In This Document

    217, modified the “Fibre Channel data transmission ranges” table. For 32 Gbps transmission, under 50nm, the OM2 range was doubled to 20m, and the extra OM4 entry was removed. Under 9nm, the 10m value was replaced with “N/A”. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 15: Device Overview

    Two half-size slots for control processor (CP) blades: – A single active CP blade can control all the ports in the device. – The standby CP blade assumes control of the device if the active CP blade fails. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 16: Port-Side View Of Device

    Port-side view of device The following illustration shows the port-side view of the Brocade X6-8 Director with installed blades identified. Note that SX6 extension blades are not shown in the following illustration, but would install in the same slots as the FC32-48 port blade. A maximum of four SX6 blades are supported.
  • Page 17 Port-side view of device FIGURE 1 Port side of the Brocade X6-8 Director (sample configuration) Air vent Cable management comb Core routing blades (CR32-8) Control processor blades (CPX6) – slot 1 (upper), slot 2 (lower) Port blades (FC32-48) NOTE Depending on the fans and power supplies installed, airflow can be from the port side to the nonport side of chassis or from the nonport side to the port side of the chassis.

  • Page 18: Port-Side Slot Numbering

    Port-side slot numbering The Brocade X6-8 Director contains 10 full-height slots and two half-height slots, for a total of 12 slots. Facing the port side of the device, the half-height slots are on the left, numbered 1 (top slot) and 2 (bottom slot). The remaining full-height slots are numbered 3 through 12, counting from left to right of chassis.
  • Page 19 Nonport-side view of the device FIGURE 2 Nonport side of the Brocade X6-8 Director (sample configuration) WWN bezel (logo plate - WWN cards behind) Fan assembly Power supply assembly 2AWG Panduit LCD2-14AF lug for building ground connection Depending on fans and power supplies installed, airflow can be from the port side to the nonport side of the chassis or the nonport side to the port side of chassis.
  • Page 20 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 21: Preparing For The Installation

    To protect the serial port from damage, keep the cover on the port when not in use. CAUTION Never leave tools inside the chassis. CAUTION Use the screws specified in the procedure. Using longer screws can damage the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 22: Esd Precautions

    A fully populated chassis weighs approximately 145.83 kg (321.5 lbs) and requires a hydraulic or assisted lift to install it. CAUTION Do not attempt to lift or support the chassis by the logo bezel attached over the port-side air vents. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 23: Laser Precautions

    Laser Radiation. Do Not View Directly with Optical Instruments. Class 1M Laser Products. DANGER Use only optical transceivers that are qualified by Brocade Communications Systems, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 24: Time And Items Required For Installation

    20-30 minutes or longer if SFP+ and QSFP28 optical transceivers as needed. you are using high-density port blades. Attaching fiber-optic cables, cable ties, and cable guides. 2-3 hours Fiber-optic cables, cable ties, and cable management comb. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 25: Quick Installation Checklists

    Mount the device Choose one of the following mounting options: • Mount the device in a four-post rack. Refer to the instructions in this guide for mounting your device in a four-post rack. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 26: Items Shipped

    When unpacking the device, follow procedures under "Unpacking and transporting the device". Verify that you have the following items. Save shipping cartons and packaging in the event you need to return the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 27 • 4 GB USB drive • China-RoHS Hazardous/Toxic Substance statement • Network Advisor web pointer card • Brocade documentation web pointer card • Rack mount kit for your device • Ground lug kit Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 28 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 29: Mounting The Device

    Do not use the port cover tabs to lift the module. They are not designed to support the weight of the module, which can fall and be damaged. CAUTION Make sure the airflow around the front, and back of the device is not restricted. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 30: Unpacking And Transporting The Device

    Use a pallet jack or other assisted lift to transport the device to the installation area. Doorways must be wider than 36 in. (91 cm) to accommodate the device. Remove the chassis door if installed. Remove the cable management comb if attached to the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 31: Installing The 14U Rack Mount Kit For Four-Post Racks (Xbr-Dcx-0120 And Xbr-Dcx-0152)

    Hardware devices illustrated in these procedures are only for reference and may not depict the device you are installing into the rack. Time and items required Allow approximately one hour to unpack and install a device in a rack. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 32: Parts List

    For rack rails with square holes cm-kg]) 3/8 in. (0.953 cm) alignment washer For rack rails with square holes NOTE Depending on the device and installation, not all the parts may be used on the device type. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 33: Parts List - Nebs Kit

    NOTE Depending on the device and installation, not all of the parts may be used. Verify that the items listed in the following figure are included in the NEBS kit. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 34: Assembling The Rack Hardware

    Attach the left and right rack mount shelf brackets to the rack rails. NOTE If cables are to be routed down through the cable management comb, allow space below the brackets for cable management Locate the shelf brackets in the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 35 3/8 in. (0.953 cm) alignment washer for rails with square Exhaust air direction holes (4 on each end of each bracket, 16 total) CAUTION Use the screws specified in the procedure. Using longer screws can damage the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 36 Standard EIA rails have holes in sets of three; spaces between the holes are 5/8 in., 5/8 in., and 1/2 in. (1.58 cm, 1.58 cm, and 1.27 cm). Tighten the adjusting screws on the sliding portion of the rack mount shelf brackets to a torque of 32 in-lb (37 cm-kg). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 37: Installing The Device In The Rack

    Move the lift as close as possible to the rack, with the air-intake side of the device facing the front of the rack (see the following figure). If applicable, lock the wheels of the lift. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 38 Installing the 14U Rack Mount Kit for Four-Post Racks (XBR-DCX-0120 and XBR-DCX-0152) Gently slide the device onto the shelf brackets, ensuring that it remains supported during the transfer. FIGURE 7 Positioning the device for installation in a rack Rack Nonport side of device Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 39: Installing The 14U Chassis Mid-Mount Rack Kit For Two-Post Racks (Xbr-Dcx-0121)

    Installing the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121) Use the following instructions to install a Brocade modular device in a telecommunications (Telco) rack, using the 14U Chassis Mid- Mount Rack Kit for Two-Post Racks (XBR-DCX-0121). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 40: Time And Items Required

    Hydraulic or assisted lift with a minimum raise of 140 cm (55 in.) and a minimum capacity of 113 kg (250 lbs). Parts list The following parts are provided with the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 41: Assembling The Rack Hardware

    Attach the rear tray (with or without adapter, as required) to both rack rails. Orient the tray (refer the following figure) and use nine screws (Item E) for each rail. Attach the front tray to both rack rails. Orient the tray (Figure 11) and use nine screws (Item E) for each rail. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 42 Verify that the rear edge of the front tray is seated into the front edge of the rear tray. FIGURE 10 Attaching the rear tray to the rack rails 2. Tray, rear, mid-mount, chassis 3. Adapter, rear, mid-mount, right 4. Adapter, rear, mid-mount, left 5. Screws Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 43: Installing The Device In The Rack

    5. Screws Installing the device in the rack DANGER Use safe lifting practices when moving the product. NOTE A fully populated device requires a hydraulic or assisted lift to install into a rack. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 44 Use three screws (Item 5) to attach each side of the rear tray to the device (refer the following figure). NOTE The screw holes in the device walls have pem nuts on the inside surface. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 45: Removing Logo Bezel Protective Cover

    Reinstall the device door. For instructions, refer to the door removal and installation instructions in your device installation guide. Removing logo bezel protective cover The chassis ships with a protective cover installed over the logo bezel and air vents at the top of the port side of the chassis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 46 If not removed, the chassis can overheat and will eventually shut down. Remove this cover by removing the Phillips screws securing it to the mounting bracket on each side of the chassis. FIGURE 14 Removing bezel protective cover from Brocade X6-8 CAUTION Do not attempt to lift or support the chassis by the logo bezel attached over the port-side air vents.

  • Page 47: Initial Setup And Verification

    Customize a switch and chassis name for the device. Use the switchName command, followed by new name in quote marks (switchname "bigswitch".) Use the chassisName command followed by the new name in quote marks (chassisname "chassis_002"). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 48: Items Required

    15.2 cm (6 in.) and are routed to avoid stress. • Remember that power is supplied to the device as soon as the first power supply is connected to a power source. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 49: Connecting Power Cord To Ac Power Supplies

    Ground the chassis by attaching a ground wire from building ground to an appropriate crimp connector and attaching the connector to the 2AWG Panduit LCD2-14AF lug located under the fan assemblies near the bottom of the chassis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 50: Connecting Power Cord To Hvac/Hvdc Power Supplies

    Installing a power supply on page 181 for procedures. When installing the device in a rack, route power cables from power distribution units (PDUs) so they do not cover air vents in chassis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 51 Save the retainer cover and screws for reinstallation after plugging in the power cord. CAUTION When removing the metal cable restraint cover under the high voltage power supply inlet, remove the 2 Torx head screws only. Torx head screws Metal cable restraint cover Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 52 Attach the cable restraint cover under the power cord connector using its two torx head screws (refer to step 4). NOTE This retainer cover protects the power cord from being accidentally unlatched and disconnected from the power supply. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 53 11. Route the cords so they will be out of the way when connected to the power source. Ensure that the power cords have a minimum service loop of 15.2 cm (6 in.) available and are routed to avoid stress. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 54 Note that the connector's latch should be positioned under the connector and will latch when the power cord connector is fully inserted into the power supply. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 55: Establishing A Serial Connection To The Device

    Access the device using a terminal emulator application (such as HyperTerminal in a Windows environment or tip in a UNIX environment). Disable any serial communication programs running on the workstation (such as synchronization programs). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 56: Configuring The Ip Addresses

    The device requires three IP addresses, which are configured using the ipaddrset command. IP addresses are required for both CP blades (CP0 and CP1) and for chassis management (shown as SWITCH under the ipaddrshow command) in the device. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 57 The addresses 10.0.0.0 through 10.0.0.255 are reserved and used internally by the device. External IPs must not use these addresses. Following is example configuration for setting the chassis IP address. swDir:admin> ipaddrset -chassis DHCP [Off]: Ethernet IP Address [10.0.0.0]:192.168.1.1 Ethernet Subnetmask [255.0.0.0]:255.255.240.0 IP address is being changed... Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 58: Establishing An Ethernet Connection To The Device

    Complete any additional device configuration procedures for the device using one of the following steps: • Log into the device using a serial console connection and admin login. • Log into the device through a Telnet session using the chassis management IP address and admin login. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 59: Setting The Domain Id

    A serial console connection to the active CP blade. The active CP is indicated by an illuminated blue LED on the blade front panel. • A Telnet session using the chassis management IP address. Log into the device using admin. If you have not changed the default password, usepassword. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 60: Setting The Time Zone

    A serial console connection to the active CP blade. The active CP is indicated by an illuminated blue LED on the blade front panel. • A Telnet session using the chassis management IP address. Log into the device using admin. If you have not changed the default password, usepassword. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 61 Enter the tsTimeZone command followed by the time zone, such as US/Pacific, US/Central, or US/Eastern as in the following example. switch_99:Admin> tstimezone US/Pacific System Time Zone change will take effect at next reboot Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 62: Synchronizing Local Time With An External Source

    A message displays that the name change is applied and the new name will display at next login. You can enter switchName to verify the new name after login. Record the new names for future references. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 63: Verifying Installed Licenses And License Key

    Displays information about the device operation in the fabric and general information about the fabric slotShow Displays the current status of each slot in the device tempShow Displays temperature status and information historyShow Displays the device history errDump Displays any errors Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 64: Backing Up The Configuration

    For more information on using the configUpload and configUpload -vf command, refer to the Brocade Fabric OS Command Reference. Enter the following commands for additional configuration information that you can save to files: • configShow • ipaddrShow • licenseShow • switchShow Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 65: Powering Down The Chassis

    Power off the chassis by disconnecting all power cords or switching off rack power source. Note that power supply LEDs will continue to flash green briefly after disconnecting power until power supply is completely off. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 66 Disconnect the power cable from the power supply. Note that the latch for the power cable connector is positioned under the connector. Press on the latch using a small screwdriver or other tool to unlatch from the power supply. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 67 Powering down the chassis Power cable Connector latch Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 68 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 69: Installing Transceivers And Cables

    The 4x32 Gbps QSFP transceiver has four links that operate at 32 Gbps to achieve a 128 Gbps link speed. The 4x16 Gbps QSFP+ transceiver has four links that operate at 16 Gbps to achieve a 64 Gbps link speed. The cables come in specific predetermined fixed lengths that are qualified by Brocade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 70: Port And Extension Blade Transceivers

    Supported transceivers and cables DANGER Use only optical transceivers that are qualified by Brocade Communications Systems, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 71: Core Routing Blades

    Following are types of QSFPs installed in core routing blades: • Separate MTP cable and transceiver. The transceiver is inserted into the blade port and the cable plugs into a QSFP on the other end of the ICL. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 72 An off-the-shelf MTP cable up to 100 meters can be used as an ICL cable when using the standard SWL optics. The Brocade 2 km 16 Gbps QSFP with LWL optics has an integrated 3 meter single-mode pigtail with a male MTP connector for Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 73 • Use female-to-female patch cable with the following specifications: – Single-mode (not OM3 MMF or OMM MMF) – MTP/MPO 1x12 fiber – MTP female angled polished connector (APC) – Key-up/key-up connectors for polarity Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 74: Time And Items Required

    All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Brocade Communications Systems, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 75: Cleaning The Fiber-Optic Connectors

    Before plugging a cable into any port, be sure to discharge the voltage stored on the cable by touching the electrical contacts to ground surface. NOTE Do not use tie wraps with optical cables because they are easily overtightened and can damage the optic fibers. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 76: Installing An Sfp+ Transceiver

    The device supports only Brocade-qualified transceivers. If you use an unqualified transceiver, the switchshow command output shows the port in a Mod_Inv state. Fabric OS also logs the issue in the system error log. To insert an SFP+ transceiver, complete the following steps: Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 77 FIGURE 24 Installing an SFP+ transceiver with bail latch into blade port Bail Transceivers are keyed so that they can only be inserted with the correct orientation. If a transceiver does not slide in easily, ensure that it is correctly oriented. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 78: Replacing An Sfp+ Transceiver

    The 16- and 32-Gbps SFP+ transceivers do not have bails but pull tabs. Always use the pull tab to insert or remove the SFP+ transceivers, as the transceiver might be hot. Remove any cables that are inserted into the transceiver. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 79 FIGURE 26 Installing an SFP+ transceiver with bail latch into blade port Bail Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 80: Installing A Qsfp Transceiver

    • Some QSFPs, such as the 4x16 Gbps 2 km QSFP, have an integrated cable attached. You do not need to install a separate cable. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 81: Replacing A Qsfp Transceiver

    Each QSFP contains four individual 16 Gbps or 32 Gbps ports. Be aware that any problems with one port could affect all four ports in the quad if the QSFP must be replaced. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 82 Gently push the correctly oriented QSFP transceiver until the latching mechanism clicks. FIGURE 28 Installing a QSFP optical transceiver into blade port Pull tab QSFP transceiver QSFP cable The port's status LED initially blinks amber after installation, then displays steady amber. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 83: Verifying The Operation Of New Transceivers

    For output examples and additional information on Fabric OS commands, refer to Using monitoring commands on page 99 and the Brocade Fabric OS Command Reference. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 84 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 85: Monitoring The Device

    Refer to the Brocade Web Tools Administration Guide and the Brocade Fabric OS Administration Guide for additional information. Interpreting port blade LEDs Refer to the following illustration and table to interpret the LED patterns for the FC32-48 blade. The LED patterns will temporarily change during POST and other diagnostic tests. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 86 No light (LED is off) Blade is not powered on. Ensure that the blade is firmly seated, with ejectors pushed in fully to center of blade and captive screw for each ejector fully tightened. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 87: Interpreting Extension Blade Leds

    Interpreting extension blade LEDs Refer to the following illustration and table to interpret the LED patterns on the SX6 extension blade. The LED patterns may temporarily change during POST and other diagnostic tests. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 88 Recommended action Power Steady green Blade is operational. No action required. No light (LED is off) Blade is not powered on. Ensure that the blade is firmly seated, with ejectors pushed in fully Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 89 Change the transceiver or reset the second, then off 1/2 second) faulty. switch from the workstation. Alternating green and amber Port is bypassed. Reset the port from the workstation using the portEnable or portCfgPersistentEnable command. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 90: Interpreting Control Processor Blade Leds

    Verify that the power LED is on. not have power. Steady amber If on for more than 5 seconds, the Ensure that the blade is firmly CP blade is faulty. seated and the switch has Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 91: Interpreting Core Routing Blade Leds

    Interpreting core routing blade LEDs Refer to the following illustration and table to interpret the LED patterns on the CR32-8 blade. The LED patterns may temporarily change during POST and other diagnostic tests. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 92 Blade is either healthy or does not Verify that the power LED is on. have power. Steady amber Blade is faulty or the switch is still Ensure that the blade is firmly booting. seated and the switch has Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 93: Interpreting Wwn Card Leds

    TABLE 16 WWN card LED descriptions LED purpose Color Status Recommended action Power No light (LED is off) Card is not receiving power. Ensure that device power supplies are firmly seated, power cables are Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 94: Interpreting Power Supply Leds

    Refer to the following information to interpret the LED patterns on the power supply. The LED patterns may temporarily change during POST and other diagnostic tests. The Brocade X6-8 Director can have up to four power supplies. FIGURE 34 AC Power supply LED...
  • Page 95 If status persists, replace power supply. Flashing on seven times, and then Power supply is disabled. Disconnect power cable from off 5 seconds. power supply, remove and reinsert Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 96: Interpreting Fan Assembly Leds

    Refer to the following illustration and table to interpret the LED patterns on fan assemblies. The LED patterns may temporarily change during POST and other diagnostic tests. The Brocade X6-8 Director has three fan assemblies. Brocade X6-8 Director Hardware Installation Guide...
  • Page 97 Slow-flashing amber (on 2 Fan assembly is not seated Pull the unit out and reseat it. If the seconds, then off 2 seconds) correctly or is faulty. LED continues to flash, replace the unit. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 98: Interpreting Post And Boot Results

    Operating system is initialized. Hardware is initialized. Diagnostic tests are run on several functions, including circuitry, port functionality, ability to send and receive frames, all aspects of memory, parity, statistics counters, and serialization. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 99: Boot

    Time Awake: Time that the system as been powered on since the last reboot. • Time Alive: Reflects the total power-on time for the FRU (when available). The following examples show output from this command. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 100 Factory Serial Num: EAL0339L009 Manufacture: Day: 24 Month: 10 Year: 2015 Update: Day: 12 Month: Year: 2016 Time Alive: 66 days Time Awake: 0 days SW BLADE Slot: 6 Header Version: Power Consume Factor: -420W Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 101 Factory Part Num: 60-1003325-01 Factory Serial Num: DYJ0339L00J Manufacture: Day: Month: 10 Year: 2015 Update: Day: 12 Month: Year: 2016 Time Alive: 78 days Time Awake: 0 days SW BLADE Slot: 12 Header Version: Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 102 Power Consume Factor: -300w Factory Part Num: 60-1003203-03 Factory Serial Num: DYL0329L055 Manufacture: Day: 10 Month: 10 Year: 15 Update: Day: 15 Month: Year: 2016 Time Alive: 68 days Time Awake: 2 days Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 103: Errdump And Errshow

    CP where the command is issued. • My_Switch corresponds to what is entered for switchname and is a switch or logical switch event. • My_Chassis corresponds to what is entered for chassisname and is a chassis event. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 104: Fanshow

    Inserted at Mon Jun 13 13:59:09 2016 Factory Part Number: 23-0000161-01 Factory Serial Number: DUC2M35L0CL POWER SUPPLY Unit 3 Inserted at Mon Jun 13 13:59:10 2016 Factory Part Number: 23-0000161-01 Factory Serial Number: DUC2M41L0JJ Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 105 Inserted at Mon Jun 13 13:59:20 2016 Factory Part Number: 60-1003201-09 Factory Serial Number: DYK0338L00E SW BLADE Slot 12 Inserted at Mon Jun 13 14:29:57 2016 Factory Part Number: 60-1003200-07 Factory Serial Number: DYJ0332L018 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 106: Psshow

    41: (Temperature) is Ok, value is 29 C sensor 42: (Temperature) is Ok, value is 30 C sensor 43: (Temperature) is Ok, value is 43 C sensor 44: (Temperature) is Ok, value is 49 C Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 107: Slotshow

    7: -- Slot 3/Port 8: -- Slot 3/Port 9: -- Slot 3/Port 10: -- Slot 3/Port 11: -- Slot 3/Port 12: -- Slot 3/Port 13: -- Slot 3/Port 14: -- Slot 3/Port 15: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 108 9/Port 15: -- Slot 10/Port 0: -- Slot 10/Port 1: -- Slot 10/Port 2: -- Slot 10/Port 3: -- Slot 10/Port 4: -- Slot 10/Port 5: -- Slot 10/Port 6: -- Slot 10/Port 7: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 109 6/Port 23: -- Slot 6/Port 24: -- Slot 6/Port 25: -- Slot 6/Port 26: -- Slot 6/Port 27: -- Slot 6/Port 28: -- Slot 6/Port 29: -- Slot 6/Port 30: -- Slot 6/Port 31: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 110 Serial No: JAF31542000010P Speed: 8,16,32_Gbps Slot 6/Port 35: id (sw) Vendor: BROCADE Serial No: JAF315410000NNZ Speed: 8,16,32_Gbps Slot 6/Port 36: -- Slot 6/Port 37: -- Slot 6/Port 38: -- Slot 6/Port 39: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 111 7: -- Slot 7/Port 8: -- Slot 7/Port 9: -- Slot 7/Port 10: -- Slot 7/Port 11: -- Slot 7/Port 12: -- Slot 7/Port 13: -- Slot 7/Port 14: -- Slot 7/Port 15: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 112 7/Port 47: -- Slot 7/Port 48: -- Slot 7/Port 49: -- Slot 7/Port 50: -- Slot 7/Port 51: -- Slot 7/Port 52: -- Slot 7/Port 53: -- Slot 7/Port 54: -- Slot 7/Port 55: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 113 4/Port 11: -- GE: Slot 4/Port 12: -- GE: Slot 4/Port 13: -- GE: Slot 4/Port 14: -- GE: Slot 4/Port 15: -- GE: Slot 4/Port 16: -- GE: Slot 4/Port 17: -- Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 114: Switchshow

    010c00 No_Module 010d00 No_Module 010e00 No_Module 010f00 No_Module 018000 No_Module 018100 No_Module 018200 Online E-Port 10:00:50:eb:1a:f6:6c:68 "ras006" (Trunk master) 018300 Online E-Port 10:00:51:ee:1a:f6:6c:68 "ras006" (Trunk master) 018400 Online E-Port 10:00:52:ee:1a:f6:6c:68 "ras006" (Trunk master) Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 115: Supportsave

    Saving support information for switch:ras015, module:SSHOW_SERVICE..... Saving support information for switch:ras015, module:SSHOW_SEC......... Saving support information for switch:ras015, module:SSHOW_NET......slot 4-dp0 support file transfer done. Saving support information for switch:ras015, module:SSHOW_FICON... Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 116 Saving support information for switch:ras015, module:MP_LOG... Saving support information for switch:ras015, module:DM_FTR_FFDC......Saving support information for switch:ras015, module:CORE_FFDC... No core or FFDC data files found! Saving support information for switch:ras015, module:RAS_POST....Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 117: Tempshow

    Sensor index (when command issued with the --detail option) • Sensor state (OK or absent) • Temperature in both Centigrade and Fahrenheit Following is an example of tempShow output. chassisX6-8:admin> tempshow Sensor Slot Sensor State Centigrade Fahrenheit Index =================================================================== Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 118: Running Diagnostic Tests

    For more information about diagnostic tests and how to run them, refer to the Brocade Fabric OS Administration Guide and the Brocade Fabric OS Command Reference. For information about system error messages (errShow or errDump), refer to the Fabric OS Troubleshooting and Diagnostics Guide. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 119: Port And Extension Blades

    For details on interpreting LED operation, refer to Interpreting port blade LEDs on page 85. FC32-48 blade port numbering and trunking The following illustration shows how ports are numbered and port trunking groups are arranged on the blade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 120 Ports belonging to the same ASIC are indicated by a border with a similar color tone. • 0–7 • 8–15 • 16–23 • 24–31 • 32–39 • 40–47 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 121: Extension Blade Overview

    For details on interpreting LED operation, refer to Interpreting extension blade LEDs on page 87. All features are supported on this blade with no license requirements. Extension features The SX6 Extension blade supports the following extension features. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 122: Sx6 Blade Port Numbering And Trunking

    FCIP and hybrid mode (FC + IP) modes. SX6 blade port numbering and trunking The following illustration shows how ports are numbered on the blade. Ports are labeled as 10GE, 40 GbE, and FC on the blade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 123 0 or port group 1. You cannot use ports from each port group for the trunk. • You can use from 1–8 ports in a port group to form a trunk. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 124: Precautions Specific To The Blade

    The status LED on the blade is lit steady amber, or the power LED is not illuminated. • The slotShow command does not show that the blade is enabled. • errShow - Displays error log messages one at a time. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 125: Time And Items Required For Removal And Installation

    (xx-xxxxxxx-xx), serial numbers, and additional status. Ensure that traffic is not flowing through the blade (port status LED should be off) prior to disconnecting cables. Disconnect all cables and remove transceivers from the blade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 126 CAUTION To avoid damaging blade and chassis, do not push the blade into a slot or pull the blade from a slot using the ejector handles. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 127: Installing A Blade

    Rotate the ejector handles away from center of blade completely - approximately 45 degrees. Do not support the blade using ejector handles. Orient the blade so that the handles are toward you and the flat metal side is facing left. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 128: Verifying Blade Operation

    Check the LED indicators on the blade's front panel. For information on interpreting LED patterns, refer to one of the following sections of this guide:. • Interpreting port blade LEDs on page 85. • Interpreting extension blade LEDs on page 87. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 129 For output examples and additional information on Fabric OS commands, refer to Using monitoring commands on page 99 and the Brocade Fabric OS Command Reference. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 130 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 131: Core Routing Blades

    12 directors in a core-to-edge topology. Each transceiver provides four 32 Gbps FC links for a total of 128 Gbps per connection. This core switch blade is compatible only with the Brocade X6-8. Core routing blades contain the following LED indicators: •...
  • Page 132 Each numbered QSFP port on the blade provides four 32 Gbps FC ports to obtain a total link speed of 128 Gbps. The following table shows the mappings from the numbered QSFP ports on the face of the core blade to the individual FC port numbers. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 133: Icl Trunking Groups

    QSFPs within a port trunk group on a core blade installed in one device must be connected to a pair of QSFPs within a trunk group on a core blade in another device using ICLs. Each CR32-8 blade on the Brocade X6-8 Director has four ICL trunking groups consisting of the following QSFP ports. •...

  • Page 134: Icl Cabling Configurations

    Up to six directors are recommended in a full-mesh topology if connecting a mixture of X6 and GEN5 directors. • Up to 12 directors can be connected in a core-to-edge topology. FIGURE 41 ICL cable connections for Brocade X6 Director (sample configuration) Chassis 1 - X6-8 Chassis 2 - X6-4 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 135: Precautions Specific To The Blade

    The Brocade X6 Director can be connected in a core-edge configuration. The following figure shows two core and four edge devices. Although X6-8 Directors are shown in the figure, the device can be either X6-4 or X6-8 Directors. The cabling scheme should follow the parallel example shown in the previous figure.

  • Page 136: Faulty Core Routing Blade Indicators

    99 and the Brocade Fabric OS Command Reference for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 137: Time And Items Required

    Ensure that Lossless Dynamic Load Sharing is enabled on each logical switch that resides on each physical switch that has ICL connections through the core blades. Log into each logical switch using an account with admin permissions, and then enter dlsShow. "DLS is set with Lossless enabled" should display if Lossless is enabled. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 138: Removing A Core Routing Blade

    As you move the handles, you will hear connectors disengaging from the backplane connector and possibly a slight popping noise. This is normal and is due to the dense backplane. The blade will move out approximately 1.27 cm (.5 in.) from the slot when fully disengaged. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 139: Installing A Core Routing Blade

    13. If the blade is not being replaced by another blade, install a filler panel and reinstall the chassis door. The filler panel is required for proper chassis cooling. The door is required to meet EMI compliance. Installing a core routing blade Complete the following steps to install a core routing blade into an empty slot. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 140 Group and route the cables through the cable management comb. Allow sufficient time for blade to initialize and for all ports to transition online. Reinstall the chassis door. The door is required to meet EMI compliance. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 141: Verifying Blade Operation

    For output examples and additional information on Fabric OS commands, refer to Using monitoring commands on page 99 and the Brocade Fabric OS Command Reference. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 142 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 143: Control Processor Blades

    Control processor blade overview The CPX6 control processor blades are half the slot height of other Brocade X6-8 Director blades. Two CPX6 control processor blades are stacked vertically in the half slots on the left side of the chassis to provide CP redundancy. CP0 is installed in slot 1, while CP1 is installed in slot 2.

  • Page 144: Cpx6 Port Identification

    This document describes how to remove and replace a control processor (CP) blade. Each device has two CPX6 blades located in slots 1 and 2. Observe the following precautions when replacing these blades: • The CPX6 blade is compatible only with the Brocade X6 Director. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 145: Blade Fault Indicators

    Configuration loader messages or "Sys PCI config" messages – Generic system driver messages ("FABSYS") – Platform system driver messages ("Platform") – EM messages that indicate a problem with a CP blade – Function fail messages for the CP master Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 146: Blade Replacement Task Guide

    Installing a blade on page 156. Verify firmware installation by following all steps under Completing the replacement on page 158. Verify operation of replacement blade by following steps under Verifying blade operation on page 158. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 147: Time And Items Required For Replacement

    HA Enabled, Heartbeat Up, HA State Synchronized Enter all remaining commands from the serial console for the active CP blade, unless otherwise indicated. For more information about commands, refer to the Brocade Fabric OS Command Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 148: Replacing A Cp Blade

    You can prevent failover by entering the haDisable command. To replace both CP blades with power off, refer to the cold-swap replacement procedures. Removing a blade Complete the following steps to remove a CP blade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 149 CAUTION To avoid damaging blade and chassis, do not push the blade into a slot or pull the blade from a slot using the ejector handles. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 150 CP blade, determine the version of firmware on the replacement CP blade and upgrade it if necessary. Complete the following steps to install a CP blade. If a protective sleeve is covering the blade connectors remove the sleeve. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 151 If the standby CP is unresponsive, you can try unplugging the new CP blade, running haDisable on the active CP blade, and plugging the new CP blade back in. At that point, you can repeat step 1 to begin the verification process again. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 152 The final message is similar to the following and will appear with a date and time stamp. Slot 1 (CP0, active): Firmwaredownload command has completed successfully. Use firmwareshow to verify the firmware versions. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 153 Log in to the active CP blade as admin if you are not still logged in and enter usbStorage -e to enable the USB device. Remove the serial cable from the active CP blade and attach it to the standby CP blade and log in as admin. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 154: Cold-Swap Procedure

    Use this procedure to replace both CP blades while the device power is off. You must power off the device to replace both CP blades. To replace a single blade, refer to the hots-swap replacement procedures. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 155 CAUTION To avoid damaging blade and chassis, do not push the blade into a slot or pull the blade from a slot using the ejector handles. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 156 Rotate the ejector handles away from center of blade completely - approximately 45 degrees. Do not support the blade using ejector handles. Orient the blade so that the handles are toward you and the flat metal side is facing left. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 157 The device becomes fully functional with the new CP blades. 14. Verify that each blade's power LED is green. If not, ensure that the CP blade has power and is firmly seated and that the ejectors are in the locked position. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 158: Completing The Replacement

    Perform the following tasks to verify operation of new blade: Check the LED indicators on the blade's front panel. For information on interpreting LED patterns, refer to Interpreting control processor blade LEDs on page 90. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 159 99 and the Brocade Fabric OS Command Reference for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 160 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 161: Wwn Cards

    WWN card are located behind the WWN bezel (logo bezel) on the nonport side of the device between the power supplies. The bezel must be removed to access the card trays. The following figure illustrates WWN card location and numbering. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 162: Precautions Specific To Wwn Cards

    For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. CAUTION Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 163: Wwn Card Fault Indicators

    [EM-1036], <sequence-number>, WARNING, <system-name>, <FRU Id> is not accessible. Writing to the FRU history log 0x24c (fabos): Switch: (hilSetFruHistory) has failed. switchname, Error EM-HIL_FAIL, 2, HIL Error: hilSetFruHistory failed, rc=-3 for SLOT 3 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 164: Wwn Card Replacement Task Guide

    165 and WWN card fault indicators on page 163 before replacement. The following items are needed to replace the WWN cards: • Electrostatic discharge (ESD) grounding strap • #1 Phillips screwdriver • Workstation computer Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 165: Using The Wwnrecover Utility

    Verify that you are logged in to the active CP blade. Run the haShow command to determine the active CP blade. Run the supportSave command on the active CP blade to capture all settings. These settings will be referenced to verify the settings have been correctly programmed after WWN replacement. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 166 Supportsave data taken in the previous step so that the replacement cards can be reprogrammed prior to shipping to the partner or your site. If Brocade support has determined that both WWN cards need replaced, you must replace both WWN cards as a matched pair. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 167: Hot-Swap Replacement

    This command is necessary so that the correct IP address for the new card displays for the ipaddrshow command. For more information on these commands, refer to the Brocade Fabric OS Command Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 168: Cold-Swap Replacement

    There are two WWN card assemblies located behind the WWN bezel (logo plate). As you are facing the bezel, WWN 1 is located on the left side, and WWN 2 is on the right. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 169 Insert and tighten both screws using a Phillips screwdriver. 15. Pack faulty WWN card assemblies in the packaging provided with the replacement cards, and return them to Brocade Support for failure analysis (FA). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 170: Removing The Wwn Card And Bezel

    Depending on the WWN card assembly removed, label the assembly with #1 for the left-side assembly and #2 for the right- side assembly for future reference. Set the WWN card assembly on a static-free surface, such as a grounding pad. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 171: Configuring Airflow Direction On Wwn Cards

    WWN units should indicate "Non-portside Intake." POWER SUPPLY Unit: 1 Power Source: Fan Direction: Non-portside Intake Unit: 2 Fan Direction: Non-portside Intake Unit: 1 System AirFlow: Non-portside Exhaust Unit: 2 System AirFlow: Non-portside Exhaust Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 172: Verifying Wwn Card Operation

    Interpreting WWN card LEDs on page 93. Enter the errDump command. This displays the system error log. Refer to the Brocade Fabric OS Message Reference for more information on the messages in this log. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 173: Power Supply Assemblies

    VAC). This assembly has two fans that move the air from the port side to the nonport side of the device. The following figure illustrates power supply assembly components. FIGURE 49 AC power supply assembly Fan 1 AC power cable receptacle Fan 2 Airflow label Handle Captive screw Status LED Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 174: Hvac/Hvdc Power Supply Overview

    HVAC/HVDC power supply overview The Brocade X6-8 Director can have three or four power supplies installed, depending on the quantity ordered. Use of the high-voltage line (200 to 240 VAC) is highly recommended because of better power conversion efficiency. Refer to "Power Supply Requirements" in...
  • Page 175 Consider the following information when connecting AC power: • The Brocade X6-8 Director can have three or four power supplies installed, depending on the quantity ordered. Use of the high-voltage line (200 to 277 VAC) is highly recommended because of better power conversion efficiency. Refer to "Power Supply Requirements"...

  • Page 176: Power Supply Assembly Numbering

    "fault" status. However, LED operation for the power supply will not indicate a fault. If airflow direction for a fan assembly does not match the chassis airflow direction, the fan LED will indicate a fault condition. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 177 WWN units should indicate "Non-portside Intake". POWER SUPPLY Unit: 1 Power Source: Fan Direction: Non-portside Intake Unit: 2 Fan Direction: Non-portside Intake Unit: 1 System AirFlow: Non-portside Exhaust Unit: 2 System AirFlow: Non-portside Exhaust Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 178: Precautions Specific To Power Supply Assembly

    99 and the Brocade Fabric OS Command Reference for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 179: Power Supply Assembly Task Guide

    If your chassis is up and running, but you want to power down the chassis to install additional power supply assemblies or replace failed power supply assemblies, complete the following steps. Shut down the system using the sysShutdown command. Unplug power cords from all power supply assemblies. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 180: Time And Items Required

    Loosen the captive screw on the right side of the power supply assembly until the screw releases from the chassis. The captive screw is located just below the airflow label on the right side of the power supply assembly. If necessary use a Phillips screwdriver. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 181: Installing A Power Supply

    If a filler panel is installed over the slot where you are installing the power supply, remove the panel by loosening the captive screw located on the right side of the panel. When the screw releases from chassis, pull on the screw to lift the panel from the chassis slot. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 182: Verifying Power Supply Operation

    - Displays current temperature and status of fan and power supply sensors located on the chassis. • errDump - Displays all system error log messages. • errShow - Displays error log messages one at a time. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 183 99 and the Brocade Fabric OS Command Reference for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 184 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 185: Fan Assemblies

    Fan assemblies can be removed and replaced without special tools. • The chassis can continue operation while one fan assembly is replaced if the fan assembly is replaced immediately. The following figure illustrates fan assembly components. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 186: Fan And Power Supply Airflow

    P/N, located on the top of the FRU, contains either NPI or NPE. If a mismatched power source or fan assembly is installed by mistake, a RASlog message occurs indicating that a mismatch in fan or power supply airflow has occurred and the FRU is faulted. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 187 Airflow direction can be verified by entering the chassisShow command. Following is an example from command output indicating mis- matching airflow. WWN units should indicate "Non-portside Intake". POWER SUPPLY Unit: 1 Power Source: Fan Direction: Non-portside Intake Unit: 2 Fan Direction: Non-portside Intake Unit: 1 System AirFlow: Non-portside Exhaust Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 188: Fan Assembly Numbering

    FRUs from chassis connectors. Fan assembly numbering The following figure illustrates the location and number identification of fan assemblies in the chassis. FIGURE 57 Fan assembly numbering Fan assembly 1 Fan assembly 3 Fan assembly 2 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 189: Precautions Specific To Fan Assemblies

    Each fan assembly contains 3 fans for a total of 6 fans for three installed fan assemblies. The chassis requires 5 fans out of 6 functioning fans for operation. If hot-swapping a fan assembly, be sure to have the replacement fan assembly ready to install before removing a faulty fan assembly and replace as soon as possible. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 190: Replacing Fan Assembly (Hot-Swap)

    Complete the following steps to remove a fan assembly from the chassis. Before removing a fan assembly, Verify if you can remove a power supply and leave the chassis operating (hot swap replacement), by referring to Precautions specific to fan assemblies on page 189. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 191 Grasp the handle and pull, sliding the fan assembly from the chassis while supporting the fan assembly from beneath as you remove it. FIGURE 58 Removing and installing a fan assembly If leaving power on for replacement (hot swap), be sure to replace the fan assembly as soon as possible. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 192: Installing A Fan Assembly

    99 and the Brocade Fabric OS Command Reference for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 193: Blade Filler Panels

    Pull out the spring-loaded latch release on the latch at each end of the cover using your thumb and forefinger and slide the latches toward the center of the cover. This moves the latches away from the ends of the slot to unlatch the cover from chassis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 194: Installing A Filler Panel

    Pull out the spring-loaded latch release on the latch at each end of the cover using your thumb and forefinger and slide the latches toward the center of the cover. Orient the filler panel over the empty slot and slide into the slot. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 195 Be sure filler panels are securely latched. If not, high pressure from fan operation may unseat blade from chassis connectors. FIGURE 60 Removing and installing the blade filler panel Latch pull tab Latch release Reinstall the chassis door. The door must be installed to meet EMI compliance. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 196 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 197: Cable Management Comb

    Installing cable management comb................................198 Cable management comb overview Use the cable management comb to organize and route cables attached to blade ports. The Brocade X6-8 Director can continue to operate while removing or installing the cable management comb. Time and items required for removal and installation The replacement procedure for the cable management comb takes less than five minutes.

  • Page 198: Installing Cable Management Comb

    Complete the following steps to replace the cable management comb. Position and tighten the four (4) screws to secure the cable management comb to the chassis. Arrange the cables along the cable management comb. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 199: Chassis Door

    The door assembly is packaged separately from the chassis. Removing a chassis door Support the door to prevent it from falling. Pull and remove the door. It will pop off the ball studs. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 200: Installing A Chassis Door

    Installing a chassis door FIGURE 62 Removal and replacement of the chassis door Installing a chassis door Complete the following steps to install the door on the port side of the chassis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 201 Do not remove the bezel mounting bracket (1) from the chassis. Save the bezel and screws for future installation. FIGURE 63 Removing logo bezel from Brocade X6-8 chassis Chassis mounting bracket for logo bezel 6-32 x 3/8 in. panhead Phillips with a square cone sem...
  • Page 202 Align the ball stud attachment holes located vertically on each side of the rear of door with the ball studs on each chassis mounting ear. Push door onto chassis to snap onto the studs. FIGURE 64 Removal and replacement of the chassis door Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 203: Replacing The Chassis

    Observe the following precautions when replacing the chassis. When removing components, Wear a wrist grounding strap connected to bench ground. DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 204: Chassis Replacement Task Guide

    Intermittent FAULTY codes for blades. Reseat the blade and visually inspect the ejector stiffening rails for possible wear or damage. It is important that the blade ejector handles not slip out during blade installation. If this happens, it is usually due to excessive wear or damage to the ejector stiffening rails. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 205: Time And Items Required

    • licenseShow • supportShow Before beginning replacement, you must also properly shut down the device and disconnect from the fabric and power using procedures under Disconnecting from network and fabric on page 209. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 206: Recording Critical Device And San Information

    New factory serial number New serial number (if available) Open a telnet session and log into the device as admin. The default password is password. Enable the logging function on your telnet or serial console connection. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 207 "Factory Serial Num" and "Serial Num" are listed under "Chassis/WWN Unit 1" and "Chassis/WWN Unit 2". If the current WWN cards are the original cards, the factory serial number listed is the same as the chassis serial number. For example output from the chassisShow command, refer to chassisShow on page 99. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 208 Record the cable connections between the chassis and the target device and ports. 10. Run supportSave on the active CP blade. The information recorded can be very important in case you have difficulties during the replacement process. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 209: Disconnecting From Network And Fabric

    199) if not already removed. Remove the cable management comb. Remove the port, extension, blades or filler panels (Removing a blade on page 125 and Removing a filler panel on page 193). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 210: Installing The Replacement Chassis

    Installing components into the chassis Follow electrostatic discharge (ESD) precautions when installing new components. Wear a wrist grounding strap connected to chassis ground (if the device is plugged in) or a bench ground. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 211: Synchronizing Airflow Direction On Wwn Cards

    If the chassisShow command or RASlog messages indicate a mismatch between system airflow direction and airflow direction of fan in power supply or fan assemblies refer, to Configuring airflow direction on WWN cards on page 171 for instructions on configuring correct airflow direction on WWN cards. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 212: Downloading The Configuration

    Establishing an Ethernet connection to the device on page 58. NOTE Once an Ethernet connection is established, the device can be accessed by remote connection using any of the available management tools, such as Telnet or Web Tools. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 213: Verifying Correct Operation Of System

    Configuring airflow direction on WWN cards on page 171 for instructions on configuring correct airflow direction on WWN cards. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 214 State Proto ======================================================= 010000 Online F-Port 20:00:00:27:f8:f3:15:80 010100 Online F-Port 20:01:00:27:f8:f3:15:80 010200 Online F-Port 20:02:00:27:f8:f3:15:80 010300 Online F-Port 20:03:00:27:f8:f3:15:80 010400 Online F-Port 20:04:00:27:f8:f3:15:80 010500 Online F-Port 20:05:00:27:f8:f3:15:80 010600 Online F-Port 20:06:00:27:f8:f3:15:80 (output truncated) Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 215: Verifying Correct Configuration Of The Fabric

    <output truncated> switch:admin>lscfg --show Created switches: 128(ds) 1 2(bs) Port ------------------------------------------------------------------- 1 | 1 | 1 | 1 | 1 | 128 | 128 | 128 | 128 | 128 | <output truncated> switch:admin> Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 216 If there are any mechanical problems, try reseating the associated component. • If the configuration information is not correct for the device, modify as required. • If other issues exist, contact your support provider. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 217: Brocade X6 Directors Technical Specifications

    Brocade X6-4 Director: 8 Tbps per chassis (192 ports with 32 Gbps data rate plus 16 4x32 Gbps ICLs) Brocade X6-8 Director: 16 Tbps per chassis (384 ports with 32 Gbps data rate plus 32 4x32 Gbps ICLs) ISL trunking Can use up to 8 ports in a trunk group to form a 256-Gbps trunk.
  • Page 218 Brocade X6-4 Director: 8 Tbps when populated with 192x32 Gbps ports and using 16 ICL ports at 128 Gbps (including 2 Tbps of ICL bandwidth) Brocade X6-8 Director: 16 Tbps when populated with 384x32 Gbps and using 32 ICL ports at 128 Gbps (including 4 Tbps of ICL bandwidth) FC32-48 blade: <900ns (including FEC) any port to any port local switching and 2.7 μsec blade to blade...

  • Page 219: Fibre Channel

    Fibre Channel ports Brocade X6-4 Director: Up to 192 32-Gbps ports, universal (F_Port, E_Port, EX_Port, M_Port, D_Port, FICON) Brocade X6-8 Director: Up to 384 32-Gbps ports, universal (E_Port, F_Port, EX_Port, M_Port, D_Port, FICON) Classes of service Class 2, Class 3, Class F (interswitch frames)

  • Page 220: Other

    13.44 inches 1.43 inches 10.75 lb FC32-48 port blade 48-port Brocade port blade 42.06 cm 34.13 cm 3.63 cm 4.35 kg (without media) supporting 4/8/10/16/32 16.56 inches 13.44 inches 1.43 inches 9.6 lb Gbps Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 221: Environmental Requirements

    Brocade X6-4: refer to Watts and Btu/hr values under VAC inputs in Typical, Idle, and Maximum Power Consumption tables. Brocade X6-8: refer to Watts and Btu/hr values under VAC inputs in Typical, Idle, and Maximum Power Consumption tables. Operating noise Brocade X6-4: 64.2 dB...

  • Page 222: Power Supply Requirements

    384 32 Gbps ports and QSFP 100–120 VAC (low line) Not supported ICLs 200–240 VAC (high line) 3 (N+1) 200–277 HVAC (high line) 240–380 HVDC 200–240 VAC (high line) 4 (N+N) 200–277 HVAC (high line) 240–380 VDC Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 223: Power Consumption For Ac Power Supplies (Typical Configuration)

    Brocade X6-4 fully 120 VAC) loaded: 2 CP blades, 2867 BTU/hr 2806 BTU/hr 2 CR blades, 1 power supply for AC high line (200– 4 FC32-48 port blades, 240 VAC) 2 fan assemblies Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 224: Power Consumption For Ac Power Supplies (Maximum Configuration)

    1 power supply for DC input (192-400 VDC) Brocade X6-4 fully loaded: 2 CP blades, 4645 BTU/hr 4546 BTU/hr 2 power supplies for AC low line (100–120 VAC) 2 CR blades, 1 power supply for AC high line (200–277 VAC) Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 225: Power Consumption For Hvac/Hvdc Power Supplies (Idle Configuration)

    The maximum power consumption configuration features fans at maximum speed and the FC32-48 blade installed with optics. Traffic is at full-line rate, smallest packet is 64-bytes, 40°C (104°F) ambient temperature, and maximum power for all supported optics. Does not include the power draw for the SX6 extension blade. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 226: Power Consumption (Modules)

    Core Routing Blade for Brocade X6-4 Idle = 95 W Typical = 160 W Maximum = 244 W CR32-8 Core Routing Blade for Brocade X6-8 Idle = 180 W Typical = 342 W Maximum = 450 W Extension Blade Idle = 300 W...

  • Page 227: Fibre Channel Data Transmission Ranges

    32 Gbps (E, F, D, M, and EX) Fibre Channel ports using four 48-port 32 Gbps Fibre Channel port blades. Brocade X6-8 32 Gbps (E, F, D, M, and EX) Fibre Channel ports using four 48-port 32 Gbps Fibre Channel port blades. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 228: Class 1M Transceiver Specification

    None NOTE Flow control on customer terminal servers. Memory specifications (per CP blade) Memory Type Size Main memory DDR3 MiniDIMM 16 GB Boot flash On-board NAND 4 MB Compact flash eUSB 16 GB Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 229: Regulatory Compliance (Emc)

    Section 1502 of the Dodd-Frank Wall Street Reform and Consumer Protection Act of 2010 - U.S. Conflict Minerals. • 30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 230 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 231: Regulatory Statements

    European Council directives, laws, and standards: • Electromagnetic Compatibility (EMC) Directive 2014/30/EU • Low Voltage Directive (LVD) 2014/35/EU • EN 55032/EN 55024 (European Immunity Requirements) – EN61000-3-2/JEIDA (European and Japanese Harmonics Spec) – EN61000-3-3 Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 232: China Rohs

    Machine noise information regulation - 3. GPSGV, the highest sound pressure level value is 68.2 dB(A) in accordance with EN ISO 7779. Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 68.2 dB(A) gemäss EN ISO 7779. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 233: Cautions And Danger Notices

    Si se realizan cambios o modificaciones en este dispositivo sin la autorización expresa de la parte responsable del cumplimiento de las normas, la licencia del usuario para operar este equipo puede quedar anulada. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 234 Never leave tools inside the chassis. VORSICHT Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE Ne laissez jamais d'outils à l'intérieur du châssis PRECAUCIÓN No deje nunca herramientas en el interior del chasis. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 235: Electrical Cautions

    Es empfiehlt sich die Installation eines separaten Stromkreiszweiges für jede Elektroschnur als Redundanz im Fall des Ausfalls eines Stromkreises. MISE EN GARDE Utilisez un circuit de dérivation différent pour chaque cordon d’alimentation ainsi, il y aura un circuit redondant en cas de panne d’un des circuits. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 236 La electricidad estática puede dañar el chasis y otros dispositivos electrónicos. A fin de impedir que se produzcan daños, conserve los dispositivos susceptibles de dañarse con la electricidad estática dentro de los paquetes protectores hasta que esté listo para instalarlos. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 237: Cautions Related To Equipment Weight

    être endommagé. PRECAUCIÓN No utilice las pestañas de la tapa del puerto para levantar el módulo. No están diseñadas para soportar el peso del módulo, por lo que este podría caerse y resultar dañado. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 238: Danger Notices

    Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over. GEFAHR Stellen Sie sicher, dass das Gestell für die Unterbringung des Geräts auf angemessene Weise gesichert ist, so dass das Gestell oder der Schrank nicht wackeln oder umfallen kann. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 239: Electrical Dangers

    à la source d'alimentation. PELIGRO Verifique que circuitos de la fuente de corriente están conectados a tierra correctamente; luego use el cordón de potencia suministrado con el instrumento para conectarlo a la fuente de corriente Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...
  • Page 240 Hoher Ableitstrom. Vor Anschluss ans Netz Schutzerdung herstellen. DANGER Courant de fuite élevé. Mise à la terre obligatoire avant la connexion de l'alimentation. PELIGRO Alta tensión al tacto. La conexión a tierra es esencial antes de conectar la alimentación. Brocade X6-8 Director Hardware Installation Guide 53-1004105-07...

  • Page 241: Laser Dangers

    Todas las interfaces de fibra óptica utilizan láser de clase 1. DANGER Use only optical transceivers that are qualified by Brocade Communications Systems, Inc. and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

Table of Contents
