Anybus Communicator PROFINET IRT User Manual page 29

Anybus Configuration Manager
6.1.5 Options Dialog
Fig. 24 Options dialog tabs
Application
Warning on Delete
Warning on Unsaved
Configuration
Show Wizard ...
Select Language
Module
Size of logbuffer
Firmware Download
Factory Restore
Block Configuration
Create Error Log
®
Anybus Communicator ™ PROFINET
A confirmation dialog will be displayed when something is deleted.
A confirmation dialog is displayed when closing Anybus Configuration
Manager without saving the configuration.
Open a wizard when creating a new configuration
The language to use in Anybus Configuration Manager. The program
must be restarted for the new language seting to become active.
The number of entries logged in each direction by the Data Logger. Can
be set between 0 (no logging) and 512 (default).
Used for updating the firmware in the PROFINET IRT interface.
Use with caution!
Resets the Anybus Communicator to the factory default settings.
The settings in the PROFINET IRT interface are not affected.
Prevents the downloaded configuration from being used by the Anybus
Communicator. Use with caution!
Create an error log file for troubleshooting.
®
