Changing The Radio Station - Fusion Apollo MS-SRX400 Owner's Manual

Changing the Radio Station

1
Select an applicable source, such as FM.
2
Select to select a tuning mode.
You can use Auto mode to scan stations, Manual mode to
manually tune to a station, and Preset mode to select the
next preset station.
3
Select or to tune to the station.
Presets
You can save your favorite AM stations and FM stations as
presets for easy access.
Saving a Station as a Preset
1
With an applicable source selected, tune the stereo to a
station or a channel.
2
Press and hold the dial to select the PRESETS tab.
3
Select .
TIP: You can quickly save the selected station or channel as a
preset by holding .
Selecting a Preset from a List
1
With an applicable source selected, press and hold the dial to
select the PRESETS tab.
2 Select a preset from the list.
Removing Presets
1
With an applicable source selected, press and hold the dial to
select the PRESETS tab.
2 Select .
3
Select each preset you want to remove.
4 When you are finished removing presets, select .
Apple AirPlay
Setting the Apollo SRX400 Zone Stereo as a
Wireless Access Point
If the zone stereo is not connected to a FUSION PartyBus
network and you want to connect mobile devices to the zone
stereo using Wi‑Fi technology, you must configure the zone
stereo as a wireless access point. This allows you to connect an
Apple device and stream media using the AirPlay feature.
1 Select > SETTINGS > NETWORK > WI-FI ACCESS
POINT.
2
Select SSID, and change the default SSID, or name, for the
wireless access point (optional).
3
Select AP SECURITY, and change the security type for the
access point (optional).
NOTE: It is strongly recommended that you use the default
WPA2 PERSONAL AP SECURITY setting. It is the most
widely-used and secure wireless security protocol.
4
Select PASSWORD, and change the default password for
the access point (optional).
5
If necessary, select COUNTRY, and select your region.
6
Select CHANNEL, and select a channel range for the access
point (optional).
7
Select SAVE.
You can adjust the wireless access point configuration at any
time (Wireless Access Point Settings, page
Connecting an Apple Device Using AirPlay
1 From the settings menu on your Apple device, connect to the
same wireless network as your compatible FUSION stereo.
Apple AirPlay
®
2
3
4
Setting an AirPlay Password
You can set a password that a user must enter when connecting
to the stereo using the AirPlay feature.
1
2
When connecting to this stereo using the AirPlay feature, the
user must enter the password on their Apple device.
The FUSION PartyBus networking feature allows you to connect
multiple compatible stereos and zone stereos together on a
network, using a combination of wired or wireless connections.
A FUSION PartyBus stereo, such as an Apollo RA770 stereo,
can stream sources to other FUSION PartyBus devices
connected to the network. Connected FUSION PartyBus
devices can also control media playback on the FUSION
PartyBus stereo. A FUSION PartyBus zone stereo, such as an
Apollo SRX400 zone stereo can stream from a FUSION
®
PartyBus stereo, but cannot stream sources to other FUSION
PartyBus devices on the network.
You can connect up to eight FUSION PartyBus devices on a
network wirelessly.
In the image above, one Apollo RA770 stereo
wireless router
The two FUSION PartyBus stereo zone stereos can stream
sources from the FUSION PartyBus stereo.
A FUSION PartyBus zone stereo is not the same thing as a
speaker zone. It is an independent stereo that can either play
media from connected sources or stream from a FUSION
PartyBus stereo on the network. You can connect a FUSION
PartyBus zone stereo, such as an Apollo SRX400 zone stereo,
to a single speaker zone
PartyBus stereo, such as an Apollo RA770 stereo, to multiple
speaker zones
5).
FUSION PartyBus devices cannot control the speaker volume of
another stereo. You can adjust the volume of speakers or
speaker zones connected directly to the stereo only.
NOTE: You can connect some Apple devices to the network
using a wired Ethernet connection, if applicable. Go to the
Apple website for more information.
On your Apple device, open the music app you want to
stream to the stereo.
From the music app or program, select
the name of the stereo.
If necessary, start playing music on the app.
The stereo changes to the AIRPLAY source automatically
and plays audio from your Apple device.
NOTE: On some AirPlay devices, adjusting the volume on
the device affects the volume level on the stereo.
Select > SETTINGS > AirPlay PASSWORD.
Enter a password.
NOTE: The AirPlay password is case-sensitive.
FUSION PartyBus Networking
and to two Apollo SRX400 zone stereos
. You can connect a FUSION
to cover a larger area with that stereo.
or , and select
connects to a
.
3
