True-Marine™ Products - Fusion Apollo MS-SRX400 Owner's Manual

download the app and update the device software, go to the
Apple App Store or the Google Play store.
True-Marine ™ Products
True-Marine products are subjected to rigorous environmental
testing under harsh marine conditions to surpass industry
guidelines for marine products.
Any product that bears the True-Marine stamp of assurance has
been designed for simplicity of use and combines advanced
marine technologies to deliver an industry leading entertainment
experience. All True-Marine products are supported by the
FUSION 3-year worldwide limited consumer warranty.
Specifications
General
Weight
Water resistance
Operating temperature range
Storage temperature range
Input voltage
Current (max.)
Current (muted)
Current (off, standby mode
enabled)
Current (off, standby mode
disabled)
Fuse
Wi‑Fi wireless range
Bluetooth wireless range
Wireless frequencies/protocols Wi‑Fi 2.4 GHz @ 15 dBm nominal
Compass-safe distance
On-board, Class D Amplifier
Output music power per 70 W max. x 2 at 2 ohm per channel
channel
Total output peak power 140 W max.
Output power per channel 2 x 43 W RMS at 14.4 Vdc input, 2 ohm,
10% THD*
2 x 26 W RMS at 14.4 Vdc input, 4 ohm,
10% THD*
*The stereo may limit the output power to prevent the amplifier
from overheating, and to maintain the audio dynamics.
Tuner Europe and
Australasia
FM radio 87.5 to 108 MHz
frequency range
FM frequency 50 kHz
step
AM radio 522 to 1620 kHz
frequency range
AM frequency 9 kHz
step
Troubleshooting
The stereo does not respond to key presses
• Press and hold for at least 10 seconds to reset the stereo.
My Bluetooth audio is interrupted by short breaks
• Ensure the media player is not covered or obstructed.
Bluetooth technology performs best with line-of-sight
operation.
• Bring the media player within 10 m (33 ft.) of the stereo.
6
340 g (12.0 oz.)
IEC 60529 IPX7 (front of stereo only,
when properly installed)
From 0 to 50°C (from 32 to 122°F)
From -20 to 70°C (from -4 to 158°F)
From 10.8 to 16 Vdc
8 A
Less than 400 mA
50 mA
5 mA
15 A blade type
Up to 32 m (105 ft.)
Up to 10 m (30 ft.)
Bluetooth 2.4 GHz @ 10 dBm nominal
10 cm (3.9 in.)
USA Japan
87.5 to 76 to 95 MHz
107.9 MHz
200 kHz 50 kHz
530 to 522 to
1710 kHz 1620 kHz
10 kHz 9 kHz
• Turn off the DISCOVERABLE setting after pairing a
Bluetooth device to the stereo.
The stereo does not display all song information from
my Bluetooth source
The availability of song information such as song title, artist
name, track duration, and album cover artwork depends on the
capability of the media player and music application.
Network Troubleshooting
If you cannot see or connect to FUSION PartyBus devices on
the network, check the following:
• Verify that only one device, either a stereo or a router, is
configured as a DHCP server.
• Verify that all FUSION PartyBus devices, network switches,
routers, and wireless access points are connected to the
network and turned on.
• Verify that wireless FUSION PartyBus devices are connected
to a wireless router or wireless access point on the network.
• If you configured static IP addresses, verify that every device
has a unique IP address, that the first three sets of numbers
in the IP addresses match, and that the subnet masks on
every device are identical.
• If you have made configuration changes that might be
causing networking issues, reset all network settings to
factory defaults.
The stereo keeps locking up when connected to an
Apple device
• Press and hold the power button to reset the stereo.
• Reset the Apple device. Go to
information.
• Make sure you have the latest version of iTunes
latest operating software on your Apple device.
The stereo is not finding my connected Apple device
• Make sure your Apple device supports Interface Accessory
Protocol 2 (iAP2). This stereo is not compatible with iAP1
devices.
• Make sure you have the latest version of iTunes and the
latest operating software on your Apple device.
• Make sure you have the latest version of the FUSION-Link
application on your Apple device.
• Reset the Apple device.
Go to www.apple.com for more information.
• Contact your FUSION dealer or send an email to FUSION
from www.fusionentertainment.com.
My Apple AirPlay audio is interrupted by short breaks
• Make sure the Apple device is not covered or obstructed.
• Make sure the Apple device has a good connection to the
same Wi‑Fi network as the stereo.
• Make sure the Apple device is not connected to the stereo
using Bluetooth technology and Wi‑Fi.
Using both a Bluetooth and a Wi‑Fi connection may cause
playback interruptions.
www.apple.com for more
and the
®
Appendix
