An ISO 9001:2008 Company
SPECIAL FEATURES :
Microprocessor controlled with
advanced safety features.
2 lines X 16 Characters large
LCD display.
Bar-graph indicates test voltage-rise
& decay can be observed during tests.
Display and sound warning if external
voltage is present.
ELECTRICAL SPECIFICATIONS: KM 2803IN
Test Voltage (DCV)
Measuring Ranges
(Auto-Range)
Accuracy
80
Pollution Degree
Altitude
Operating Temperature & Humidity
Storage Temperature & Humidity
Power Source
Weight (battery included)
Dimensions
Accessories
AL-50 TestLead standard
®
An ISO 9001:2008 Company
Navin.com/D.drive/sandeep gupta/New catlog Dec 2011/KM-2803IN.cdr
®
DIGITAL INSULATION RESISTANCE TESTER
Continuous battery monitoring.
Auto-ranging / Auto Power-off.
Battery life is extended by "Enersave " feature.
Built-in carrying case. Test leads in separate
pouch.
Large LCD Show test time duration (up to 99.9s)
for Easy Comparison.
IEC 1010-1 CAT III 300V.
0.5 KV
0-25G
0-50G
0-50G : ± 3% of reading
50-250G : ± 5% of reading
2
upto 2000 meter
0 ~ 40°C; 80% max. R.H.
-10°C ~ 65°C; 80% R.H.
1.5V (AA) x 8 Alkaline Batteries
930g Approx.
170(L)x120(W)x95(D) mm.
Test leads-AL-50 (3 meter), AL-30 (1.25 meter),
AL-30C (1.25 meter), Shoulder belt (BET-2800),
Instruction Manual, Batteries
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022 -24156638,
Email : kusam_meco@vsnl.net,
Model- KM - 2803IN - 5KV DC
TM
1 KV
2.5 KV
5 KV
0-125G
0-250G
AL-30 TestLead
All Specifications are subject to change without prior notice
Tel. : 022-241224540, 24181649,
HIGH VOLTAGE 5 KV
LCD DISPLAY
Fax : 022 - 24149659
Website : www.kusamelectrical.com
