Kusam-meco KM 3600 Operation Manual

An ISO 9001:2008 Company
This instrument is a 4½ digit, compact-sized portable digital temperature
calibrator designed to use external K/J/T/E/R/S/N/L/U/B/C type thermocouples
as temperature sensor.The calibrator features a dual thermocouple input, an
adjustable T/C offset. The thermocouples types comply with the (N.I.S.T.
Monograph 175 Revised to ITS 90 standard).
GENERAL SPECIFICATIONS :
Display : There are three LCD displays : Main, Second and Third.
The Main and second displays are 4½ digit with maximum reading of 19999.
The main displays the value of T1, T2 or output setting. The second displays T1 or T2 readings and
the third T1-T2 and groups settings.
Auto Power Off.
MAX / MIN / MAX-MIN / AVG / REL / HOLD Function.
Battery : Standard 9V battery.
Low Battery Indication : The "
Dimension : 192(H) X 91(W) X 52.5(D) mm
Weight : 318g. Approx
ACCESSORIES :
1) Two type "K" thermocouple bead wires.
2) A 9 volts battery.
3) Instruction manual, Holster.
TEMPERATURE SCALE : Celsius or Fahrenheit user-selectable.
Measurement
o
K-TYPE (0.1 )
-200 C to 1372 C or -328 F to 2501 F
o
J-TYPE (0.1 )
-210 C to 1200 C or -346 F to 192 F
o
T-TYPE (0.1 )
-250 C to 400 C or -418 F to 752 F
o
E-TYPE (0.1 )
-250 C to 1000 C or -418 F to 1832 F
o
R-TYPE (1 )
0 C to 1767 C or 32 F to 3212 F
o
S-TYPE (1 )
0 C to 1767 C or 32 F to 3212 F
ACCURACY
K/J/T/E/L/U-TYPE
o
±(0.05% rdg + 0.5 C) -50 C to 1372 C
o
±(0.05% rdg + 1.0 C) -50 C to -250 C
o
±(0.05% rdg + 1.0 F) -58 F to 2501 F
o
±(0.05% rdg + 2.0 F) -58 F to -346 F
Thermocouple Simulate Range
o o
Resolution : 0.1 (1 for R/S/B/C-TYPE)
o
Accuracy : ± (0.3 C + 10 V)
Accuracy : Specified for operating temperatures
o
over the range of 18 C to 28 C (64 F to 82 F),
for 1 year, not including thermocouple error.
®
An ISO 9001:2008 Company
Chhaya Computer/D:/Chhaya/Coreldraw Files/New catlogs Dec 2011/KM 3600.cdr
®
" is displayed when the battery voltage drops below the
operating level.
4) Two type "K" thermocouple calibration bead wires. Maximum insulation
o
temperature 260 C (500 F). Wire accuracy ± 2.2 C or ± 0.75% of
reading (whichever is greater) from 0 C to 800 C.
ELECTRICAL SPECIFICATIONS : KM 3600
Range
o o o o
o o o o
o o o o
o o o o
o o o o
o o o o
N-TYPE
o o
±(0.05% rdg + 1.0 C) -50 C to 0 C
o o
±(0.05% rdg + 0.5 C) 0 C to 1300 C
o o
±(0.05% rdg + 2.0 F) -58 F to 32 F
o o
±(0.05% rdg + 1.0 F) 32 F to 2372 F
mV Range
Range : -25.00mV to 75.00mV
Resolution : 10 V
Accuracy : ± (0.025% + 1 digit)
o o o
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct : 022 - 24156638.
Email : kusam_meco@vsnl.net,
TEMPERATURE CALIBRATOR
(THERMOCOUPLE) WITH 3 DISPLAY
o o
o o
Measurement
(resolution)
o
N-TYPE (0.1 ) o
-200 C to 1300 C or -328 F to 2372 F
o
L-TYPE (0.1 ) o
-200 C to 900 C or -328 F to 1652 F
o
o
U-TYPE (0.1 )
-200 C to 600 C or -328 F to 1112 F
o
B-TYPE (1 ) o
600 C to 1820 C or 1112 F to 3308 F
o
C-TYPE (1 ) o
0 C to 2316 C or 32 F to 4200 F
R/S/B/C-TYPE
o o o
±(0.05% rdg + 2 C) 0 C to 1767 C
o o o
±(0.05% rdg + 4 F) 32 F to 3212 F
o o o
o o o
Temperature Coefficient
0.1 times the applicable accuracy
specification
per C from 0 C to 18 C and 28 C to 50 C
o
(32 F to 64 F and 82 F to 122 F).
Note: All Specification are Subject to change without prior notice.
Tel.: 022 -24124540, 24181649
9 FUNCTIONS 22 RANGES
Model-KM 3600
Range
o o o
o o o
o o o
o o o
o o o
o o o
o o o
o o o o
o o o
