Simplex TrueAlert ES Installation Instructions Manual page 4

Application
o
UL1638, to -35 C
o
UL1638, to 0 C
o
UL1971 (0 TO 49 C)
Vertical dispersion
Y-plane angle UL Req output
0 100%
5 90%
10 90%
15 90%
20 90%
25 90%
30 90%
35 65%
40 46%
45 34%
50 27%
55 22%
60 18%
65 16%
70 15%
75 13%
80 12%
85 12%
90 12%
© 2017 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice. Additional listings may be applicable, contact your local Simplex® product supplier for
the latest status. Listings and approvals under Simplex Time Recorder Co. Simplex, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. NFPA 72 and National Fire Alarm Code are registered
trademarks of the National Fire Protection Association (NFPA).
Candela selection
WP75
WP185
WP75
WP185
15
75
Table 5: Percent of rated light output at any candela setting (room temperature) (15cd and 75 cd only)
Typical output
249%
168%
145%
164%
160%
138%
143%
180%
165%
147%
150%
141%
147%
137%
133%
105%
85%
61%
36%
Table 4: Current draw
Appliance type
VO
A/V
VO
A/V
VO
A/V
VO
A/V
VO
A/V
VO
A/V
Horizontal dispersion
X-Plane angle
0
±5
±10
±15
±20
±25
±30
±35
±40
±45
±50
±55
±60
±65
±70
±75
±80
±85
±90
Maximum RMS operating current
212 mA
238 mA
239 mA
274 mA
160 mA
163 mA
185 mA
189 mA
60 mA
80 mA
160 mA
165 mA
UL Req output Typical output
100% 249%
90% 176%
90% 157%
90% 167%
90% 165%
90% 152%
75% 167%
75% 167%
75% 148%
75% 129%
55% 117%
45% 113%
40% 112%
35% 99%
35% 95%
30% 91%
30% 89%
25% 80%
25% 60%
579-1032 Rev F
