Setting the strobe candela setting
1. The jumpers are factory set to FACP. Use this setting when programming the candela setting at the
4100ES FACP. The candela setting is visible through the strobe lens.
2. For manual selection, pull up the jumper and position the pins to select the correct candela setting: 15,
75, WP75, WP185 candela or FACP.
Note: To avoid a programming mismatch trouble, an authorized service personnel must program one
of the four candela outputs for each appliance. For additional information, see the 4100ES Programmer's
Manual (574-849).
Setting the device configuration
Use the Device Configuration switch (SW3), on the back of the device, to configure certain options for the
horn and strobe directly on the device. See Figure 6.
A/V only
Configuration Control: OFF to enable Local Audible control (positions 2-7 below),
Position 1
ON for Panel control.
Position 2 Audible Volume: High (OFF), Low (ON).
Position 3 CAN Horn mode: switch must be set to OFF.
Position 4 Legacy NAC mode: switch must be set to OFF.
Position 5, 6, 7 These switches must be set to OFF.
Position 8 Strobe Clear/Color domes: switch must be set to OFF.
Device specifications
Rated voltage range
Temperature range
Humidity range
Connections
Angle
WP75 minimums (over temperature range)
WP 75 typical CD (at 25°C)
WP185 minimums (over temperature range)
WP185 typical CD (at 25°C)
Reverberant room at ten feet in accordance with UL464 (See Note 2)
High volume setting using addressable controller (See Note 3)
Low volume setting using addressable controller (See Note 3)
Anechoic room at 10 feet in accordance with ULC S525
High volume setting
Low volume setting
Note
1. The coded category covers both Temporal and March time cadences.
2. Reverberant dBA measurements are a minimum UL rating based on sound power level measurements made in UL's
reverberant test chamber.
Page 3
Table 1: Environmental specifications
Special application 23-31 VRMS
WP75/WP185: -31
Other: 32°F to 120°F (0°C to 49°C)
10% to 98%, non-condensing at 104°F (40°C)
Terminal for 18 AWG to 12 AWG (0.82 mm² to 3.31 mm²)
Table 2: UL1638 candela (CD) ratings
Straight out from unit Vertical below unit
0° 45°
75 69
165 86
185 90
220 112
Table 3: Sound pressure level measurement (dBA)
Voltage (Vrms)
23 (Min.)
31 (Max.)
23 (Min.)
31 (Max.)
23 (Min.)
31 (Max.)
23 (Min.)
31 (Max.)
To Access Switches:
Candela
Selection Jumper
(and Candela rating)
CD 7 ( - )
CD 6 ( - )
CD 5 ( FACP )
CFIG1
CD 4 ( 15 )
CD 3 ( 75 )
CD 2 ( WP75 )
CD 1 ( WP185 )
Fig 6: Setting the strobe and device configuration
o o o o
F to 151 F (-35 C to +66 C)
90°
17
22
21
27
Horn Mode Steady
81.3
82.1
73.8
77.0
87.4
89.2
81.0
84.0
3. High and low volume settings are configured with DIP Switch (SW4) on the
controller.
4. Settings with ratings below 75dB should only be used for Private Mode Notification.
AV Device
Configuration Switch
Not Used 0 = ALARM /
1 = ALERT
(Left/right) horizontal)
45° 90°
60 28
74 35
81 40
101 50
Horn Mode Coded (See Note 1)
76.4
78.8
69.9
72.2
87.2
89.2
80.6
82.8
