Nice TT2Z K User, Installation And Safety Instructions

4.1.2 - Mode 1 procedure, to memorise the FIRST
TRANSMITTER only (transmitter with PRG but -
ton)
01.
ON
If no transmitters 2
are memorised, TT2Z K
flashes 2 times
02.
3
PRG
PRG
7 sec
4.1.4 - Mode 1 procedure, to memorise an ADDITION -
AL TRANSMITTER or a CLIMATE SENSOR (for
transmitters without PRG button)
01. Wait at least 20 seconds from when the TT2Z K is
switched on before initiating this procedure
02.
NEW
10 sec
03.
x 3
OLD
04.
3
x 1
NEW
5.1.2 - Procedure for memorising a transmitter in
Mode 2 (for transmitters without PRG button)
01. Wait at least 20 seconds from when the TT2Z K is
switched on before initiating this procedure
02.
NEW
10 sec
03.
4
x 1
OLD
04.
In Table B, select
the desired com -
x N
mand
OLD
N = number of button presses indicated in Table B,
next to the selected command.
05.
?
3
NEW
5 sec
? = a desired button, to be associated with the com -
mand selected in Table B.
4.1.3 - Mode 1 procedure, to memorise an ADDITION -
AL TRANSMITTER or a CLIMATE SENSOR (for
transmitters with PRG button)
01. Wait at least 20 seconds from when the TT2Z K is
switched on before initiating this procedure
02. 2
PRG
3 sec
OLD
5 sec
2
03.
PRG
2
NEW
5 sec
04.
2
PRG
OLD
5.1.1 - Procedure for memorising a transmitter in
Mode 2 (for transmitters with PRG button)
01. Wait at least 20 seconds from when the TT2Z K is
switched on before initiating this procedure
02. 2
PRG
3 sec
OLD
5 sec
2
03.
PRG
2
NEW
5 sec
04.
In Table B, select
the desired com -
mand
OLD
10 sec
N = number of button presses
(and feedback quantity) indicated
N
in Table B, next to the selected
command.
(feedback)
05.
?
NEW
5 sec
? = a desired button, to be associated with the com -
mand selected in Table B.
TABLE B – Commands available during memorisation of a transmitter button, in
Mode 2.
? Command Number of but-
Command that is memorised
number ton presses
No. 1 1 press Open > Stop > Close > Stop > ...
No. 2 2 presses Open > Stop > ...
No. 3 3 presses Close > Stop > ...
No. 4 4 presses Stop
1(A) - Connections of the outputs for DRY-CONTACT
It is possible to link to the dry contact output up to 8 motors maximum
PRG
1(B) - Connections of the outputs for MECHANICAL MOTORS
(with 3 wires)
PRG
1(C) - Connections of the outputs for 2 independent
SWITCHES
PRG
PRG
5.2.1 - Procedure for DELETING THE ENTIRE MEM-
ORY of the TT2Z K device, using a memorised
transmitter (with PRG button)
x N 01.
PRG
x 1
02.
PRG
x 1
03.
PRG
x 1
04.
?
PRG
x 1
05.
PRG
x 1
TABLE A – Pairings that occur automatically between buttons and commands, during memorisation of transmitters in Mode 1, in relation to the type of device connected to the
TT2Z K and the scheme used for this connection (1A, 1B or 1C).
Motor connection modes
Motor connected with "Dry Contact"
(see scheme 1A)
Motor connected with 3 wires plus the earth wire
("mechanical"-type motor)
(see scheme 1B)
Two independent "Switches"
(see scheme 1C)
Nice
TT2Z K
1 - White
2 - White-black
3 - White-orange
Radio receiver
User, installation and safety instructions
www.niceforyou.com
5.2.2 - Procedure for DELETING THE ENTIRE MEMO-
RY of the TT2Z K device, using a NON-memo-
rised transmitter (with PRG button)
01. OFF
2
(TT2Z K)
5 sec
2
02. within 10 seconds:
2
3
NEW
5 sec
03. OFF
4
(TT2Z K)
5 sec
5
04. continue the procedure by completing all the
steps of the procedure indicated in Paragraph
5.2.1
Transmitter button
s
n
t
s
n
t
s
n
t
IS0487B00MM_26-10-2017
EN
Nice S.p.A.
Via Pezza Alta, 13
31046 Oderzo (TV), Italy
info@niceforyou.com
ON
(TT2Z K)
ON
(TT2Z K)
Memorised command
Command: UP
Command: STOP
Command: DOWN
Command: UP
Command: STOP
Command: DOWN
Switching On / Off of SWITCH 1
Switching off of SWITCH 1 and of SWITCH 2
Switching On / Off of SWITCH 2
