- Page 1 EN - Instructions and warnings for FLOR installation and use Receiver FLOXR family www.ApolloGateOpeners.com | (800) 878-7829 | Sales@ApolloGateOpeners.com...
-
Page 3: Product Description And Intended Use
1 – PRODUCT DESCRIPTION AND ENGLISH INTENDED USE Original instructions This receiver is part of the “Flor” series by Nice spa. This series of receivers is intended for use on the Control units featured in automated systems for gates, garage doors and WARNINGS road barriers. - Page 4 Fig. 1 illustrates the electrical connections on the connector: Opening of the box for receivers with universal connection: L1 P1 BM relay 1 relay 2 ––– Electrical connections ––– Make the connections as follows (fig. 2): A = not used B = electricity supply L1 P1 BM C = relay 1 output...
- Page 5 2): terminal 1 = sheath; terminal 2 = core. 01. Disconnect the electrical power supply to the receiver. – Aerial connection for models with Nice connector: 02. Remove the board carefully and turn it over: the side connect the aerial cable to the purpose-provided terminals with the welding should be facing you.
- Page 6 relay 2 relay 1 NA NC relay 2 relay 1 CHANNEL CHANNEL CHANNEL CHANNEL ––– Selecting the channel on the transmitter ––– On the FLOR series of transmitters, the association of the transmitter key with the receiver channel can be modified: •...
- Page 7 4 – PROGRAMMING –– FAST 1/4 second FLASH –– • During initialisation: Warnings 1 ✺ = A BM60 memory is present The programming featured in this chapter requires the 2 ✺ = A BM250 memory is present use of key P1 and of LED L1 on the receiver (fig. 1). To 3 ✺...
- Page 8 4.1 – Storage of a transmitter 04. Press and keep any key on the transmitter pressed, to send the code, until LED L1 on the receiver is turned off; A transmitter (its code) can be stored in the memory of a the LED will emit three flashes to indicate that the receiver in two ways: process was successful;...
-
Page 9: Other Functions
03. On the NEW transmitter, press the same key as in step If this does not happen, then repeat the process from step 01. 01 once and then release it. 5 – OTHER FUNCTIONS 4.2 – Total deletion of the receiver memory WARNING! –... - Page 10 tion (electric jumper 3, fig. 5). If - during programming - you 5.3 – BURGLAR ALARM Function prefer the relays not to be activated, you will need to remove Activate this function to obtain the combined function of the electric jumper for the channel selection temporarily. relays 1 and 2.
- Page 11 5.4 – Locking the memory need to have a transmitter that has already been stored in the receiver to deactivate it. There are two ways to do this: – Locking the memory via the hardware (paragraph 5.4.1) • Activating the memory lock –...
- Page 12 If this does not happen, then repeat the process from step 01. The memory lock can also be activated in a safer and more controlled way: using a “PASSWORD”: this method can only be implemented with the use of the BUPC and OBox pro- grammers.
-
Page 13: Disposing Of The Product
WARNINGS: • All technical specifications are referred to a and should therefore be disposed of together with it. room temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to make any changes deemed necessary to the prod- As for the installation operations, even at the end of this... -
Page 14: Ec Declaration Of Conformity
Note – This Declaration of Conformity gathers the contents of all the individual declarations of conformity of each prod- uct mentioned herein; it is updated to the date of publication of this manual and was re-adapted for publishing purposes. A copy of the original declaration for each product can be requested from Nice S.p.a. (TV) I. Number: 201/FLOX...
