DISCO-B5-MAGNET H
5 DISCO-B5-MAGNET APPLICATION INTERFACE
5.1
Power supply
The DISCO-B5-MAGNET is powered by a 5x2250 mAh Li-Ion rechargable battery pack. Before
using the DISCO-B5-MAGNET device you will need to recharge the internal battery of the
device even if it may be shipped pre-charged from the factory. Because it may has been some
time in transit and storage before reaching you, it is recommended to charge the battery while
turned off for approx. 24 hours before the first use. DISCO-B5-MAGNET uses a special cable
called KA33 "Service and Charging Cable" for charging the internal battery. This cable is not
included in the DISCO-B5-MAGNET package, so it should be ordered separately. The power
supply for recharging internal battery pack has to be a single voltage source of V
+32.0 V DC.
The operating voltage (V
but not against continuous-overvoltage.
NOTE: Operating voltage range must never be exceeded; care must be taken in order to fulfill
min/max voltage requirements.
5.1.1 Power supply pins (1 and 2) on the 8-pin connector
One +IN pin on the 6/8-pin double row connector is dedicated to connect the supply voltage,
and the GND pin for grounding. Both +IN and GND pins serve for charging the internal Li-Ion
battery pack.
Signal name
I/O
Parameter
+IN
I
+10.8V...+32.0VDC. The operating
voltage must never be exceeded.
GND
-
0 V
5.1.2 Automatic shutdown
Automatic shutdown takes effect if:
•
Battery voltage level runs low and external power supply is disconnected.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
M
ARDWARE
ANUAL
and GND) is protected against voltage spikes and reverse polarity,
+IN
Description
Positive operating voltage.
For security reason, it is recommended to integrate externally
a 2A fuse link between interconnection plug and d.c.-power
source.
Ground
V
1.0.1
ERSION
= +10.8 V...
+IN
Page 17 of 35
