Sight mark SIGNAL N320RT User Manual page 8

OPERATING MODES continued
Photo Mode
Photo mode allows for image capture of what is
seen on the display. When the Signal is photo mode,
the (camera) icon is shown on the display.
To take a photo:
1. Briefly press the record button (5).
2. The Signal will save a jpeg image of the current view
on the display.
Note: Sound is not recorded in photos.
Review Mode
Review mode is designed to playback photo and video
files saved on the internal memory. When the Signal is in
review mode, the display always shows the last recorded
file. When in Review mode the (picture) icon will be
shown on the display if a photo is being displayed and
the (video) icon will be shown if a video is being
displayed.
To navigate files:
1. To navigate to the next file to the left, press the IR
button (3).
2. To navigate to the next file to the right, press the
zoom button (4).
12
VIDEO mode
counter*
999
9x
04:23pm
Mode
REVIEW-PHOTO
File counter
2/123
File navigation File navigation
arrow (left) arrow (right)
2016.08.05 Time and date
Photo resolution 22:18 of photo file
960p
Delete current file
Video duration
00:05
Video review mode
File counter
2/123
File navigation
File navigation
arrow (right)
arrow (left)
Time and date
2016.08.05
of video file
Photo resolution 480p
22:18
Play current file Delete current file
To play a video file:
1. When the desired video file is on the display, press the
record button (5) to start playing. The video length
countdown timer will start.
2. To pause the video, press the record button again. The
pause indicator will appear at the bottom in place of
the play indicator. Also the video length countdown
timer will stop.
3. To resume play, press the record button again.
4. To return to the start of the current video file, press the
IR button (3).
5. To review the next file, press the record button.
Video countdown timer
Video
00:05
review
mode
5/123 File
counter
File
File
navigation navigation
arrow (right)
arrow (left)
2016.08.05
Time and
Video 480p
22:18
date of video
resolution
file
Pause the Delete
current file current file
File deletion:
1. When the desired video file is on the display, press
the on/off button (4).
2. The display will show a yes and no option.
3. To select yes, press the zoom button (4).
4. To select no, press the on/off button (2).
00:05
5/123
Confirm
Cancel
deletion
file
deletion
YES NO
2016.08.05
480p
22:18
Delete current file
Note: During file review some control functions are not
available such as menu, zoom control, and IR illuminator
control. If the IR was on, it will turn off when entering
review mode. The IR illuminator power level is saved and
will return to the same power upon exiting review mode.
13
