TECHNICAL SPECIFICATIONS

Sensor Resolution, pixels
Display Type
Display Resolution, pixels
Magnification
Lens Diameter, mm
Digital Zoom
Field of View, ft@100yd
Eye Relief, in/mm
IR Emitter
IR Wavelength, nm
Range of Detection, yd/m
Battery Type
Battery Life (with IR), hour
Dimensions, in/mm
Weight (with batteries), oz
2
N320 (SM18024) N340 (SM18025)
640x480 640x480
LCD LCD
640x480 640x480
4.5/9 4.5/9
30 30
2x 2x
40.2 22.5
.5/14 2.76/70
LED LED
850 940
380/350 300/330
4xAA 4xAA
3 3
6.61x4.37x 2.2 / 6.61x4.37x 2.2 /
168x111x56 168x111x56
12.3 12.3
DIAGRAM
1. Objective lens
2. On/off button
3. IR button
4. Zoom button
5. Record button
6. IR illuminator
7. Eyepiece
8. Weaver rail
9. Micro USB port
10. Tripod mount
11. Neck strap eyelets
12. Battery cover
13. Microphone
