INSTALLING THE BATTERY

The Sightmark Signal RT uses four AA batteries. It is recommended to use batteries of the same type and same charge for
best performance. It is safe to use rechargeable batteries with the Signal RT.
To install a new battery:
1. Slide forward and open the battery cover (12).
2. Insert the batteries into the battery container. Make note that the battery polarity matches the positive and negative
symbol marked on the battery cover.
3. Slide back the battery cover to its original position.
Note: the battery charge icon on the display will show current charge level of the batteries. When the batteries are near depletion
the battery indicator light will turn red and flash.

EXTERNAL POWER SUPPLY

The Sightmark Signal RT can be powered by an external power supply such as a 5V power bank or even your
personal computer.
To connect the Signal RT to external power:
1. Connect the provided micro USB cable to the USB port (9).
2. Connect the other end of the USB cable to a power bank or PC.
3. On the unit's display two icons will appear, plug icon (power) and computer icon (storage device). Using the
navigation buttons (3,5) select the plug icon and confirm selection by pressing the zoom button (4).
4. The battery icon on the display will switch to the plug icon. The unit is now operating using the external power only.
Note: When AA batteries are in the unit and an external power source is used, the unit operates on the external power source only.
When the unit is disconnected from a power bank or external power supply, the Signal RT will automatically switch to internal
batteries. When using rechargeable AA batteries in the Signal RT, plugging the Signal RT into an external power source DOES NOT
recharge the batteries in the unit.
4

DESCRIPTION OF CONTROLS

Button Operating Mode 1st Short Press
ON The unit is off Turns the unit on
Display off mode Turns the display on
The unit is in Video/Photo Turns the Wi-Fi on
mode
The unit is in Review mode File deletion prompt
Zoom Video
Review Switch between files–rightwards navigation
Return to the beginning of file under review
REC Video Start video recording
Photo Image capture
Review Recorded video review
IR Video
Switch between IR Illuminator modes
Review Switch between files - leftwards navigation.
2nd Short Press Long Press
Turns the Wi-Fi on
Turns the display off
Turns the Wi-Fi on/off
(hold longer than 1 sec)
Turns the Wi-Fi off
Turns the unit off
(hold longer than 3 sec)
See description of Review mode
Digital zoom activation Enter/Exit the menu
Stop video recording Switch to Photo mode
Image capture Switch to Review mode
Pause video review Switch to Video Mode
Turns the IR illuminator off
Return to file currently viewed
–
–
