ADK-8400 Evaluation Board

Quick Start Guide:

HI-8400 Isolated Discrete Sensor
with ±800V Isolation
July 2018
QSG-8400 Rev. New
Holt Integrated Circuits

Advertisement

loading

  Related Manuals for HOLT ADK-8400

  Summary of Contents for HOLT ADK-8400

  • Page 1: Quick Start Guide

    ADK-8400 Evaluation Board Quick Start Guide: HI-8400 Isolated Discrete Sensor with ±800V Isolation July 2018 QSG-8400 Rev. New Holt Integrated Circuits...
  • Page 2: Revision History

    REVISION HISTORY Revision Date Description of Change QSG-8400, Rev. New 07-25-18 Initial Release...
  • Page 3 Airbus ABD0100H levels, an SPI port is used to read sensor data. A second board is also included to allow users to evaluate the daisy chain feature. Figure 1 – Top View of HI-8400 Evaluation Set Up including Daisy Chain Board Holt Integrated Circuits...
  • Page 4 Always discharge the high voltage from components or terminals by using a safety probe. Do NOT hold the test probe when circuits over 300 volts are tested. Always use equipment certified for operation at or above the peak voltages being tested. Holt Integrated Circuits...
  • Page 5: Kit Contents

    KIT CONTENTS ● This User Guide. ● HI-8400 Evaluation Board. ● USB Flash drive with HI-8400 software ● USB to Mini USB Serial Cable. Demonstration Set-up Holt Integrated Circuits...
  • Page 6: Software Control

    1. Connect the mini USB lead to your PC and then to the console connector J15 on the HI-8400 board; your PC should automatically install the driver. If not the driver FT231 can be installed from the Holt Flash drive. If you have problems installing the driver, please refer to the FTDI website below: 2.
  • Page 7 3. SPI data from the HI-8400 is read through the ‘Control Console’. This requires use of a terminal emulator for communication, such as HyperTerminal or Tera Term. Tera Term is used with Windows versions of Vista or later and is supplied on the Holt Flash drive. To install Tera Term: ●...
  • Page 8 To create this set up on the board just connect the 28V1 to 28V and GND1 to 0V, this produces an Open (high) in the GND/Open sensor 1, the other sensors will default to ‘0’. 8. To continually monitor the four outputs then use the key ‘z’, this will show a screen similar to below: Holt Integrated Circuits...
  • Page 9 The screen above is monitoring U3 sensors, ‘0000’ means all sensors are reading low. 2. Now increase the voltage source up to 9V, then increase the voltage slowly, to 10.5V, LED1 and LED S1 on the board should be lit, the screen should now read 1000, as shown below: Holt Integrated Circuits...
  • Page 10 ‘0000’ as shown below: 4. Increase the voltage source up to 10.5V, then increase the voltage slowly, to 12V, LED1 and LED S1 on the board should be lit, the screen should now read 1000, as shown below: Holt Integrated Circuits...
  • Page 11 28V supply and sensor voltage. Connector J7 links the SPI connections of the two devices; the SO pin of Board1 is linked to the SI pin of Board2. The software has commands that read both devices through the SO pin of Board2. Holt Integrated Circuits...
  • Page 12 J7, using the following pin connections: SPI Connector (J7) Label Description Number VLOGIC 3.3V or 5V Logic supply SPI Chip Select SPI Serial Clock Input SPI Serial Data Input SPI Serial Output from U3 INTB Interrupt output from U3 Low voltage Ground Holt Integrated Circuits...
  • Page 13 Output Enable (active low) Sense Output 1 Sense Output 2 Sense Output 3 Sense Output 4 Debug connector (for Freescale Processor) (J2) Label Description Number BKGD Debug data Ground Not Connected nRESET Reset Target Not Connected Not Connected Holt Integrated Circuits...
  • Page 14 Link 3:2 Selects 28V/Open type for Sensor 1 Link 2:1 Selects GND/Open type for Sensor 1 Link to use USB 5V supply Open Link 1:2 Selects non maskable interrupt Link 2:3 Selects maskable interrupt Closed Link 1:2 Enables SENSEOUT [1:4] OF U3 Holt Integrated Circuits...
  • Page 15 Low voltage Ground Parallel Data out connector (J22) Label Description Number Low voltage Ground INTB Interrupt output from U4 Not Connected Output Enable (active low) Sense Output 1 Sense Output 2 Sense Output 3 Sense Output 4 Holt Integrated Circuits...
  • Page 16 Link 2:3 Selects GND/Open type for Sensor 2 Link 1:2 Selects 28V/Open type for Sensor 1 Link 2:3 Selects GND/Open type for Sensor 1 Closed Link 1:2 Enables SENSEOUT [1:4] OF U4 Link 2:3 Selects GND/Open type for Sensor 1 Holt Integrated Circuits...
  • Page 17 TP10 VLOGIC VLOGIC F-BEAD 1.4A VLOGIC VLOGIC 100K nRESET LINK FOR TO USE MISO2 SS1/PP3 USB 5V SUPPLY MOSI2 SCK1/PP2 SCK2 MOSI1/PP1 MISO1/PP0 .1uF IOC7/PT7 VLOGIC 10uF,16V 68uF 16V .1uF 3.3K nRESET IOC6/PT6 RESET POWER IOC5/PT5 Green LED9 .1uF "HOLD IN IOC4/PT4 SCK0 RESET"...
  • Page 18 TP12 CHANNEL 4 SENSE4 HIGH VOLTAGE 10uF,16V VLOGIC AREA .1uF SEL 4 VLOGIC SEL 3 SENSE3 28V3 SENSE3 SEN_SEL3 GNDA3 GNDA3 SEL3 SENSE3 SENSEOUT4 VDD28_3 SENSEOUT3 HI-8400PQI CHANNEL 3 SENSEOUT2 VDD28_2 SENSEOUT1 SENSE2 SENSE2 GNDA2 28V2 SEN_SEL2 SENSE2 GNDA2 SEL2 TP11 INTB VLOGIC...
  • Page 19 Holt Integrated Circuits, Inc. Bill of Materials May 21, 2018 PCB P/N: HE035 HI-8400 4-Input Discrete Evaluation Board Rev. A Description Reference Item Digikey P/N Mfg P/N PCB, Bare, Evaluation Board Jet Tech 42737 Capacitor 68uF,20%, 16V Tant SMD 6032 C1...
