Is there a development process for the HI-3717 chip? Or develop a DEMO?
1 comments:
Mr. Anderson
May 24, 2025
The development process for the HOLT HI-3717 chip does not require software development tools to run the demo. The demo code is pre-programmed into the microcontroller flash, making the demo operational out of the box. Users can use the included CD-ROM for additional support materials and software. For more advanced use, the demo project is compatible with Freescale CodeWarrior.
Hi-8400 isolated discrete sensor with ±800v isolation (19 pages)
Summary of Contents for HOLT HI-3717
Page 1
August 18, 2011 Introduction: The Holt HI-3717 Evaluation Board demonstrates most of the features of the HI-3717 ARINC 717 Protocol IC. ARINC 717 is a communication protocol used between the Digital Flight Data Acquisition Unit (DFDAU) and the Digital Flight Data Recorder (DFDR) used on commercial aircraft.
KIT CONTENTS • This Quick Start Guide. • General Purpose SPI Evaluation board and schematic. • HI-3717 Evaluation Board (daughter card) and schematic. • HI-3717 Data Sheet. • RS-232 9 Pin Serial Cable. • Demo Project compatible with Freescale™ CodeWarrior™.
Page 3
Demonstration Board Set Up 1. Connect a +3.3V power supply to TP1 and ground to TP6. This is the only power supply needed since the HI-3717 includes an on-chip DC-DC converter which generates +5V and -5V to meet the ARINC transmit levels.
For normal operation ensure SW2 – 4 (MRST) is in the open position, otherwise the MCU is held in the reset state. Main Board Jumpers Some jumpers do not apply to the HI-3717 so they will typically be shown as NA. JP1 - NA, JP2 - NA JP3 - VDD jumper to J5 VLOGIC. Remove JP3 to measure ICC.
Page 5
A message is also sent to the Console Port. Some of the displayed information reflects the options selected by the Dip switches. After resetting the board the program sends information to the console to summarize the configuration, Receiver Mode, Word Rate and Slew Rate. HOLT INTEGRATED CIRCUITS...
Page 6
Match Word Count Register set to = 0x0005 Press S1 to start The HI-3717 has been successfully initialized and the program is waiting for the S1 push button to be pressed before continuing on. After pressing S1 the transmitter begins transmitting SYNC words and incrementing data words. The receiver FIFO is checked for data at the same time, and captured data is displayed on the console.
Page 7
TX FIFO FULL LED7 PROCESSOR RUNNING FLASHES 1HZ LED8 (Red) HI-3717 INTIALIZED, DATA COMPARE FAIL While the program is transmitting and receiving data, pressing the S1 switch stops the program and displays the HI-3717 status and control registers. HI-3717 Status, Control Registers...
Page 8
This quick demo exercises just one demo mode. To learn and use more features of the demo program, refer to the AN-170 User’s Guide. To learn more about the demo software project and how to get setup with the Freescale Codewarrior IDE, refer to the AN-171 Software Application Note on the CD-ROM. HOLT INTEGRATED CIRCUITS...
Need help?
Do you have a question about the HI-3717 and is the answer not in the manual?
Questions and answers
Is there a development process for the HI-3717 chip? Or develop a DEMO?
The development process for the HOLT HI-3717 chip does not require software development tools to run the demo. The demo code is pre-programmed into the microcontroller flash, making the demo operational out of the box. Users can use the included CD-ROM for additional support materials and software. For more advanced use, the demo project is compatible with Freescale CodeWarrior.
This answer is automatically generated
