NEC Express5800/E120f-M Maintenance Manual

NEC Express5800/E120f-M Maintenance Manual

Express5800 series dual-socket modular server exp701; exp702
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Maintenance Guide
NEC Express Server
Express5800 Series
Express5800/ E120f-M
EXP701, EXP702
Chapter 1 Maintenance
Chapter 2 Useful Features
Chapter 3 Appendix
10.108.01-104.01
September 2014
© NEC Corporation 2014

Advertisement

Table of Contents
loading

Related Manuals for NEC Express5800/E120f-M

Summary of Contents for NEC Express5800/E120f-M

  • Page 1 Maintenance Guide NEC Express Server Express5800 Series Express5800/ E120f-M EXP701, EXP702 Chapter 1 Maintenance Chapter 2 Useful Features Chapter 3 Appendix 10.108.01-104.01 September 2014 © NEC Corporation 2014...

  • Page 2: Documents For This Product

    Chapter 2: Useful Features The detail of system BIOS settings, RAID Configuration Utility, and EXPRESSBUILDER Chapter 3: Appendix Error messages and Windows Event Logs Other documents Provides the detail of NEC ESMPRO, Universal RAID Utility, and the other features. Express5800/E120f-M Maintenance Guide...

  • Page 3: Table Of Contents

    When Using Internal Devices and Other Hardware ................. 39 When OS is in Operation ......................... 40 When Running EXPRESSBUILDER on Windows ................41 5.10 For Bundled Software ........................41 5.11 For Optical Disk Drives ........................42 5.12 When Powering Off .......................... 42 Express5800/E120f-M Maintenance Guide...
  • Page 4 3.1.3 Use in EXPRESSBUILDER ....................116 Power Control Feature ..........................117 Supported OS ............................ 117 Notes on Using Windows Server 2008 R2 / 2012 / 2012 R2 ............. 117 RAID System Configuration .......................... 118 Off-line Utility and Universal RAID Utility ................... 118 Express5800/E120f-M Maintenance Guide...
  • Page 5 Installing EXPRESSBUILDER ......................124 CLI for EXPRESSBUILDER ....................... 124 EXPRESSSCOPE Engine 3 ......................... 125 NEC ESMPRO .............................. 126 NEC ESMPRO ServerAgentService (for Windows) ................126 NEC ESMPRO Manager ........................126 NEC ESMPRO Agent Extension ......................126 Server Configuration Utility ........................ 126 NEC ExpressUpdate Agent ........................

  • Page 6: Notations Used In This Document

    Unless otherwise stated, hard disk drive described in this document refer to both of the following. • Hard disk drive (HDD) • Solid state drive (SSD) Removable media Unless otherwise stated, removable media described in this document refer to both of the following. • USB flash drive • Flash FDD Express5800/E120f-M Maintenance Guide...

  • Page 7: Abbreviations Of Operating Systems (Windows)

    Windows Server 2012 R2 Standard Windows Server 2012 R2 Windows Server 2012 R2 Datacenter Windows Server 2012 Standard Windows Server 2012 Windows Server 2012 Datacenter Windows Server 2008 R2 Standard Windows Server 2008 R2 Windows Server 2008 R2 Enterprise Express5800/E120f-M Maintenance Guide...

  • Page 8: Trademarks

    Trademarks Trademarks EXPRESSSCOPE and ExpressUpdate are registered trademark of NEC Corporation. Microsoft, Windows, Windows Server, Windows Vista, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States.

  • Page 9: License Notification

    Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Express5800/E120f-M Maintenance Guide...
  • Page 10 BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Express5800/E120f-M Maintenance Guide...

  • Page 11: Warnings And Additions To This Document

    4. If you have any concerns, or discover errors or omissions in this document, contact your sales representative. 5. Regardless of article 4, NEC Corporation assumes no responsibility for effects resulting from your operations. 6. The sample values used in this document are not actual values.

  • Page 12: Chapter 1 Maintenance

    Describes how to reset or clear the server. See this section if the server is not working or if you want to restore BIOS settings to the factory settings. 8. System Diagnostics Describes the system diagnostics of this server. 9. Offline Tools Describes tools for preventive maintenance of the server. Express5800/E120f-M Maintenance Guide...

  • Page 13: Relocation

    When storing the server, monitor the environmental conditions of the storage area. temperature: −10°C to 55°C, humidity: 20% to 80% (No dew condensation is permitted) Tips Make backup copies of important data stored in the hard disk drive. Express5800/E120f-M Maintenance Guide...
  • Page 14 • Check and adjust the system clock before operating after relocating or storing Note the server. • If the system clock time is significantly delayed or advanced over time in spite of adjustment, contact your sales representative. Express5800/E120f-M Maintenance Guide...

  • Page 15: Daily Maintenance

    NEC recommends that you back up data for a rainy day before applying the latest update. Checking Alerts Use NEC ESMPRO Manager (for Windows) to constantly verify that no abnormalities are discovered on the monitored server and that no alerts have been issued. Example image of NEC ESMPRO Manager...

  • Page 16: Checking Status Led

    Be sure to observe the following precautions to use the server safety. Failure to observe the precautions may cause death or serious injury. For details, refer to Safety Precautions and Regulatory Notices. • Do not disassemble, repair, or alter the server. • Disconnect the power plug before cleaning the server. Express5800/E120f-M Maintenance Guide...

  • Page 17: Cleaning The Server

    POWER LED is off. An optical mouse does not work properly if the lens area is not clean. Wipe the sensor with a dry cloth to remove any dirt or dust. Express5800/E120f-M Maintenance Guide...

  • Page 18: User Support

    User Support Before getting after-sales service, check the contents of the warranty and service. Maintenance Services Service representatives from NEC subsidiary companies or companies authorized by NEC provide maintenance services. For the services, contact your sales representative. Before Asking for Repair If you think that a failure occurred, follow the steps below: 1.

  • Page 19: Collecting Failure Information

    4.1.1 Windows Server 2012 R2 / Windows Server 2012 Click [Settings] from Charms bar. (Or, right-click the left bottom of screen, and click Event Viewer from the menu displayed. The screen shown in Step 4 appears.) [Settings] [Event Viewer] Express5800/E120f-M Maintenance Guide...
  • Page 20 Chapter 1 Maintenance 4. Collecting Failure Information Click Control Panel from Settings. Click System and Security → View event logs on Control Panel. Express5800/E120f-M Maintenance Guide...
  • Page 21 Click Save All Events As... from Action menu. Type the file name of the archived log in File name. Select the type of the log file you want to save in Save as type, and then click Save. Express5800/E120f-M Maintenance Guide...

  • Page 22: Windows Server 2008 R2

    3. Click Save All Event As... from Action menu. 4. Type the file name of the archived log in File name. 5. Select the type of the log file you want to save in Save as type, and then click Save. Express5800/E120f-M Maintenance Guide...

  • Page 23: Collecting Configuration Information

    [Search] [Run] 2. Type msinfo32.exe, and then press <Enter> key. [Search] [Run] 3. System Information starts. 4. Click Export from File menu. 5. Type a file name to save in File Name, and then Click Save. Express5800/E120f-M Maintenance Guide...

  • Page 24: Windows Server 2008 R2

    Important A message indicating insufficient virtual memory may appear when restarting the system due to an error. Ignore this message and proceed. Restarting the system may result in an inability to properly dump the data. Express5800/E120f-M Maintenance Guide...

  • Page 25: Troubleshooting

    POWER switch. The screen is not displayed.  Wait until the NEC logo appears. The screen display is replaced by no indication (black screen) during a POST several times.  When the option ROM development of more than one on-board LAN is made effective, a screen is sometimes switched over to a black screen several times.
  • Page 26 → Check if the value specified for “Power Threshold (Pa)” is appropriate for normal startup.To operate the server with “Shutdown System” being enabled, the value of “Power Threshold (Pa)” must be fully considered. Express5800/E120f-M Maintenance Guide...

  • Page 27: Upon Starting Expressbuilder

    Error [Message ID:Z3002]: Failed to detect a DVD drive or a flash drive. Action: Check if hardware is properly connected. Error [Message ID:Z3003]: Failed to read a file. Action: Check if DVD is damaged or not. Express5800/E120f-M Maintenance Guide...
  • Page 28 <F12> Network", appears on screen after starting up, press <F3> to start EXPRESSBUILDER from Internal Flash Memory. While running EXPRESSBUILDER, the server reboots after a certain time has elapsed:  Is Boot Monitoring enabled? → Boot Monitoring option of BIOS SETUP must be disabled while running EXPRESSBUILDER. Express5800/E120f-M Maintenance Guide...

  • Page 29: Upon Installing Os

    Terminate installation once, and start installation again. At this time, remove the partition created in previous installation, and create it again. If data disk is connected, pay strict attention to the partition you are going to remove. Express5800/E120f-M Maintenance Guide...
  • Page 30 If installing using an OS media other than the backup DVD-ROM, a screen for entering the product key is displayed twice, during OS installation, and, before the MICROSOFT SOFTWARE LICENSE TERMS dialog box, which displays after OS installation. Follow the on-screen instructions to enter the product key. Express5800/E120f-M Maintenance Guide...
  • Page 31 − Process Model − Configuration APIs  Remote Server Administration Tool − Role Administration Tools − Web Server (IIS) Tools → The features listed above are activated because they are required for the installation of IIS basic features. Express5800/E120f-M Maintenance Guide...
  • Page 32 The screen turns solid black or processing stops with 0x0000005C error while installing Windows Server 2008 R2 or Windows Server 2008:  Is x2APIC feature of the processor disabled? → Disable x2APIC feature of the processor. [Advanced] → [Processor Configuration] → [X2APIC] → [Disabled] Express5800/E120f-M Maintenance Guide...

  • Page 33: When Os Is Started

    Either remove the cartridge or change the boot order in BIOS Setup.  Is Disk Array unit connected to the PCI card? → Change the boot device configuration from HDD Drive BBS Priorities of the BIOS Setup Boot menu. Express5800/E120f-M Maintenance Guide...
  • Page 34 The service did not respond to the start or control request in a timely fashion. 7009 Source: Service Control Manager Level: Error Description: A timeout was reached (30000 milliseconds) while waiting for the Alert Manager Main Service service to connect. Express5800/E120f-M Maintenance Guide...

  • Page 35: When Stop Error Occurs

     Is the Logical Drive Critical or Degraded? → Replace the failed Hard Disk Drive with new one, and then perform Rebuild.  Is the Logical Drive RAID0? → RAID0 has no data redundancy, and therefore, Consistency Check is disabled in the RAID0 configuration. Express5800/E120f-M Maintenance Guide...
  • Page 36 If the battery is not recognized although the above action has been taken, the additional battery may be faulty. Contact the maintenance service company with which you signed up or the dealer where you purchased the product. Express5800/E120f-M Maintenance Guide...
  • Page 37  DISK LED flashes frequently even while the Hard Disk Drive is not accessed. → When Patrol Read is running, the DISK LED flashes even if the Hard Disk Drive is not being accessed. If SATA Hard Disk Drive is used, the DISK LED may stay on. Express5800/E120f-M Maintenance Guide...
  • Page 38 To display correct controller name, run the following command stored in the EXPRESSBUILDER DVD and reboot the system. Windows Server 2012 R2: EXPRESSBUILDER DVD: \008\win\winnt\ws2012r2\elxfc\friendlyname.exe Windows Server 2012: EXPRESSBUILDER DVD: \008\win\winnt\ws2012\elxfc\friendlyname.exe Windows Server 2008 R2: EXPRESSBUILDER DVD: \008\win\winnt\ws2008r2\elxfc\friendlyname.exe Express5800/E120f-M Maintenance Guide...

  • Page 39: When Using Internal Devices And Other Hardware

    Unable to access the Hard Disk Drive  Is the Hard Disk Drive supported by the server? → Operation of any device that is not authorized by NEC is not guaranteed.  Is the Hard Disk Drive properly installed? →...

  • Page 40: When Os Is In Operation

    Although there may be RX dropped packets when the system is started, there is no operational problem. Check the system and network environment when there are RX dropped packets during operation or when there is no communication. Express5800/E120f-M Maintenance Guide...

  • Page 41: When Running Expressbuilder On Windows

    ServerAgentService Installation Guide (Windows)" in EXPRESSBUILDER. NEC ESMPRO Manager → For details of NEC ESMPRO Manager, see "NEC ESMPRO Manager Installation Guide" in EXPRESSBUILDER or its help. The installer was displayed by a wrong language or resulted in an error.

  • Page 42: For Optical Disk Drives

    The power is not turned off  Is the suppression feature of the power switch enabled? → Restart the system once and start the BIOS setup utility. The menu to be confirmed: Server → Power Switch Inhibit Express5800/E120f-M Maintenance Guide...

  • Page 43: Windows System Recovery

    Recovery of Windows Server 2008 R2 If the Windows does not start correctly, you can recover it using the system recovery option. We recommend that this option is performed by the system administrator. For details, refer to Windows Help. Express5800/E120f-M Maintenance Guide...

  • Page 44: Resetting And Clearing The Server

    BMC. Note Do not shut down the server, restart the server, or perform any switch operation after pressing BMC Reset Switch at least three minutes. Tips BMC RESET Switch does not restart the server. BMC RESET Switch Express5800/E120f-M Maintenance Guide...

  • Page 45: Forced Shutdown

    If the remote power-on feature is used, cycle the power once to load the OS after the power has been forcibly turned off, and then turn off the power again by shutting down the OS. POWER Switch (Keep pressing for at least four seconds) Express5800/E120f-M Maintenance Guide...

  • Page 46: Clearing Bios Settings (Cmos Memory)

    To clear the password or the CMOS memory, use the corresponding jumper switch illustrated in the figure below. Important Do not change any other jumper switch settings. Any change may cause the server to fail or malfunction. 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 Express5800/E120f-M Maintenance Guide...
  • Page 47 Press<F1> to resume, <F2> to Setup 8. Press <F2> key to start BIOS Setup Utility, and then run Load Setup Defaults from Save & Exit menu. Tips When the CMOS data is cleared, the server may reboot before the OS starts. Express5800/E120f-M Maintenance Guide...
  • Page 48 5. POST halts with the following error message. ERROR 8007: Password Cleared By Jumper. Press<F1> to resume, <F2> to Setup 6. Turn off the power and return the jumper switch to Default by following steps 1 to 3. 7. Reassemble the server. Express5800/E120f-M Maintenance Guide...

  • Page 49: System Diagnostics

    Before executing the System Diagnostics, be sure to disconnect the LAN cable and external I/O devices (such as Fibre Channel or iStorage device). Executing the System Diagnostics with them connected may affect the network. Tips No data is written to the disk on checking hard disk drives. Express5800/E120f-M Maintenance Guide...

  • Page 50: Startup And Exit Of System Diagnostics

    Move the cursor to the test that detected the error, and press <Enter > key. Take notes about the error message that has been output to the Detail Information screen and contact the store where you purchased the product or your maintenance service company. Express5800/E120f-M Maintenance Guide...
  • Page 51 To save it, connect a FAT formatted removable media, and then select [Save(F)]. <Option> Optional features can be used from this menu. <Reboot> Reboots the server. 5. Select Reboot in Enduser Menu. The server restarts. Remove EXPRESSBUILDER DVD from the drive. System Diagnostics is now completed. Express5800/E120f-M Maintenance Guide...

  • Page 52: Offline Tools

    The following menu is displayed after choosing a keyboard type from the menu. Off-line TOOL MENU Maintenance Utility Server Configuration Utility Exit 4. Choose a feature from the menu. See (9.2 Features of Offline Tools) for more information. Express5800/E120f-M Maintenance Guide...

  • Page 53: Features Of Offline Tools

    The Off-line Maintenance Utility is started when Maintenance Utility is selected. The Off-line Maintenance Utility is used for preventive maintenance and failure analysis for this product. When you are unable to start NEC ESMPRO due to a failure, the Off-line Maintenance Utility can be used to check the cause of the failure.

  • Page 54: Console-Less Feature

    You can also control Off-line Tools remotely by using BIOS Console Redirection. Preparation 9.3.2 Set the remote management feature of EXPRESSSCOPE Engine 3 in advance to check hardware error information during console-less operation. For settings information, see "EXPRESSSCOPE Engine 3 User's Guide" or NEC ESMPRO Manager online help. Express5800/E120f-M Maintenance Guide...

  • Page 55: Chapter 2 Useful Features

    Describes the EXPRESSBUILDER attached to the server. 7. EXPRESSSCOPE Engine 3 Describes EXPRESSSCOPE Engine 3. 8. NEC ESMPRO Describes NEC ESMPRO used to manage and monitor the server. 9. NEC Product Info Collection Utility Describes the NEC Product Info Collection Utility. 10. Universal RAID Utility Describes Universal RAID Utility, an application to manage or monitor the RAID Controller.

  • Page 56: System Bios

    The SETUP utility has the following six major menus. • Main menu • Advanced menu • Security menu • Server menu • Boot menu • Save & Exit menu These menu has submenus for relevant items. Selecting submenus allows you to configure further detailed parameters. Express5800/E120f-M Maintenance Guide...

  • Page 57: Main

    SETUP, and you can change the language setting. System Date WWW MM/DD/YYYY Set the system date. System Time HH:MM:SS Set the system time ]: Factory settings Express5800/E120f-M Maintenance Guide...
  • Page 58 (an NTP server) is recommended. If the system time becomes considerably slow or fast over time even though you regularly adjust it, contact the dealer where you purchased the server or the maintenance service company for maintenance. Express5800/E120f-M Maintenance Guide...

  • Page 59: Advanced

    When [Legacy] is selected for Boot Mode: Note Network Stack Configuration submenu and UEFI Driver Configuration submenu cannot be selected if Legacy is specified for Boot Mode. They can be selected only when UEFI is selected for Boot Mode. Express5800/E120f-M Maintenance Guide...
  • Page 60 This option is displayed only when the installed processor supports this feature. PPIN Support [Disabled] Enable or disable Protected Processor Inventory Enabled Number (PPIN), This option is displayed only when the installed processor supports this feature. Express5800/E120f-M Maintenance Guide...
  • Page 61 Windows Server 2008 R2 VMware ESXi 5 See Chapter 1 Installing Windows in Installation Guide, and determine whether this feature is enabled or disabled according to description in "Before Starting Setup" appropriate to your OS. ]: Factory settings Express5800/E120f-M Maintenance Guide...
  • Page 62 Shows the revision of the microcode applied to (Display only) Processor 2. EMT64 Supported is shown when the processor 2 supports (Display only) Intel 64 architecture. Hyper-Threading Supported is shown when the processor 2 supports (Display only) Hyper-Threading Technology. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 63 The screen shown below is when Custom is selected for Power Management Policy. If any other parameter than Custom is selected for Power Management Policy, the parameter values are fixed as shown below: When Energy Prefeered (default) is selected: When Performance Preferred is selected: Express5800/E120f-M Maintenance Guide...
  • Page 64 Management Policy. Turbo Boost Disabled Enable or disable the Turbo Boost [Enabled] Technology feature. This option is displayed only when the installed processor supports this feature. This item becomes selectable when Custom is selected for Power Management Policy. Express5800/E120f-M Maintenance Guide...
  • Page 65 [Disabled] Use this option to adjust uncore Coordination Enabled frequency between processors. This option is displayed when Uncore Frequency Scaling is Enabled. This item becomes selectable when Custom is selected for Power Management Policy. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 66 Access feature. This option is displayed only [Enabled] in multi-processor configuration.. Enable or disable memory RAS feature (Patrol Patrol Scrub Disabled Scrubbing). [Enabled] Enable or disable memory RAS feature Demand Scrub Disabled (Demand Scrubbing). [Enabled] ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 67 CPU2_DIMM1-8 Status Number: Indicates memory capacity and DIMM is working normally. Number (Error): Indicates memory capacity and failed DIMM. Disabled: Indicates DIMM is degraded due to memory error. Not Present: Indicates no DIMM is installed. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 68 Specify the Completion Timeout value for 16 msec to 55 msec PCIe device. 65 msec to 210 msec [260 msec to 900 msec] 1 sec to 3.5 sec 4 sec to 13 sec 17 sec to 64 sec ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 69 ]: Factory setting Note For a RAID Controller, LAN card (network boot), or Fibre Channel controller, if no Hard Disk Drive on which an OS is installed is connected, set the option ROM for that slot to Disabled. Express5800/E120f-M Maintenance Guide...
  • Page 70 PCI 1/2 Slot Link Speed Limit 2.5 GT/s Specify the upper limit of link speed of PCI 5.0 GT/s device in each PCI slot in the range not exceeding the value specified in Target Link [8.0 GT/ｓ] Speed Limit. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 71 Enabled ]: Factory setting Note If the AC power is turned off, the Wake on Ring feature is not available on the next system boot after AC power-on. Press the Power switch to boot the system. Express5800/E120f-M Maintenance Guide...
  • Page 72 Hard Disk Pre-Delay [Disabled] Specify delay time before HDD is accessed 3 Seconds during POST. 6 Seconds 9 Seconds 12 Seconds 15 Seconds 21 Seconds 30 Seconds ]: Factory setting Note NEC has not verified AHCI driver support. Express5800/E120f-M Maintenance Guide...
  • Page 73 For details about the options, see the table below. Option Parameter Descriptions SATA Port0 (Display only) Shows a device connected to each port. Not Present is shown when no device is SATA Port1 connected to SATA port. SATA Port2 SATA Port3 ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 74 POST according to support status of OS. Disabled Auto: Enables USB3.0 after the OS that supports USB3.0 is started. Enabled: Enables USB3.0. Disabled: Disables USB3.0. Disabled XHCI Hand-off Enable or disable XHCI Hand-off feature. [Enabled] ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 75 From the Advanced menu, select Serial Port Configuration and then press the <Enter> key to display the menu screen shown below. From BIOS Redirection Port, select Serial Port A or Serial Port B and then press the <Enter> key to display the menu screen shown below. Express5800/E120f-M Maintenance Guide...
  • Page 76 Specifying Serial Port B Serial Port A or Serial Port B allows direct connection via terminal unit such as NEC ESMPRO Manager. The screen size of terminal unit must be 80 x 25. The option items shown below are displayed.
  • Page 77 PXE Configuration – – Network Mode Disabled Specify the PXE network mode. [IPv4] IPv6 Specify the number of times trying to detect media at Media detect count [0]-50 PXE connection. iSCSI Configuration – – ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 78 IQN format (iSCSI Qualifier Name). The menu items below can be selected when iSCSI Initiator Name is specified. Add an Attempt – – Attempt [XX] – – Delete Attempts – – Change Attempt Order – – ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 79 Chapter 2 Useful Features 1. System BIOS Add an Attempt submenu ① Note MAC address is displayed when onboard LAN controller or UEFI driver for PCI device is loaded. Option Parameter Descriptions MAC [XX:XX:XX:XX:XX:XX] – – Express5800/E120f-M Maintenance Guide...
  • Page 80 Initiator Subnet Mask IP Address Specify subnet mask of initiator. This item is not displayed when Enabled is selected for Enable DHCP. Gateway IP Address Specify gateway. This item is not displayed when Enabled is selected for Enable DHCP. Express5800/E120f-M Maintenance Guide...
  • Page 81 This item is displayed when CHAP is selected for Authentication Type and Mutual is selected for CHAP Type. Save Changes – Save the current settings. Back to Previous Page – Return to iSCSI Configuration submenu. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 82 Select Enabled for an iSCSI attempt you want to delete. Enabled Commit Changes and Exit – Save the current setting and return to iSCSI Configuration submenu. Discard Changes and Exit – Discard the current setting and return to iSCSI Configuration submenu. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 83 <+> or <–> key. Commit Changes and Exit – Save the current setting and return to iSCSI Configuration submenu. Discard Changes and Exit – Discard the current setting and return to iSCSI Configuration submenu. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 84 For details about the options, see the table below. Option Parameter Descriptions (UEFI Driver Name) – This item is displayed when onboard LAN controller or UEFI driver for PCI device is loaded. The on-screen menu depends on the specified UEFI driver. Driver Health – – Express5800/E120f-M Maintenance Guide...
  • Page 85 For details about the options, see the table below. Option Parameter Descriptions (UEFI Driver Name) (Display only) Displays status of UEFI Driver Heaalth. This item is displayed when onboard LAN controller or UEFI driver for PCI device is loaded, and UEFI driver supports Driver Health. Express5800/E120f-M Maintenance Guide...

  • Page 86: Security

    • Do not set any password before installing OS. • If you have forgotten any password, contact the store where you purchased the product or your maintenance service company. If you want to clear password, refer to Chapter 1 (7. Resetting and Clearing Server). Express5800/E120f-M Maintenance Guide...
  • Page 87 POST is running. Front + Internal If the internal USB port is disabled, Internal Flash Memory is also disabled. Remote Keyboard and Mouse Disabled Enable or disable the remote keyboard and [Enabled] mouse supported by BMC. ]: Factory setting Express5800/E120f-M Maintenance Guide...

  • Page 88: Server

    Enable or disable the boot monitoring feature 5-60 minutes and specify the timeout period in 5-minute unit. To use this feature, NEC ESMPRO ServerAgentService must be installed. If starting up an OS on which it is not installed, disable this feature...
  • Page 89 Boot Variable data" is displayed on command line, and you are unable to open or change the Boot menu. Reduce the number of bootable devices by disconnecting unnecessary USB device, or change Option ROM Scan of onboard devices or PCI slots to Disabled. Express5800/E120f-M Maintenance Guide...
  • Page 90 Defaults is executed. If you intend to measure the power by this setting, do not use the power control feature that limits power consumption. See Chapter 2 (4. Power Control Feature) for more information. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 91 Shows the revision of Sensor Data Record. NM Firmware Version (Display only) Shows the firmware version of Intel Node Manager. Descriptor Revision (Display only) Shows the revision of descriptor. Chipset Revision (Display only) Shows the revision of chipset. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 92 POWER switch twice to power on the server. Cold Redundant Mode [Disabled] Enable or disable Cold Redundancy feature. Enabled For details, see Chapter 2 (1.14 Cold Redundant Feature) in User's Guide. ]: Factory setting Express5800/E120f-M Maintenance Guide...
  • Page 93 * Continue pressing the POWER switch for at least 4 seconds to forcibly turn off the power. Tips • If an uninterruptible power supply (UPS) is used for automatic operation, set the AC-LINK to Power On. • AC-LINK option becomes valid when next time POST is running. Express5800/E120f-M Maintenance Guide...

  • Page 94: Boot

    Enable or disable the feature to display logo during [Enabled] POST. When this option is set to Disabled, the results of POST execution are displayed instead of the NEC logo. If BIOS Redirection Port is enabled, this option is shown as Unavailable and inaccessible (run with...
  • Page 95 When executing Load Setup Defaults in Save & Exit menu, the highest priority within "CD/DVD ROM Priorities" is assigned to AMI Remote CD/DVD device. (*1) Refer to EXPRESSSCOPE Engine 3 User's Guide for details of Remote Management Extended License. Express5800/E120f-M Maintenance Guide...

  • Page 96: Save & Exit

    Reconfigure each item according to your environment by referring to the list of settings in this section. • The values of iSCSI Configuration submenu and UEFI Driver Configuration submenu do not return to the default value. Express5800/E120f-M Maintenance Guide...

  • Page 97: Bmc Configuration

    Keyboard type selection menu 2. When you select a type of keyboard that is connected to the server, the Off-line TOOL MENU appears. Off-line TOOL menu 3. Selecting Server Configuration Utility in Off-line TOOL MENU starts Server Configuration Utility. Express5800/E120f-M Maintenance Guide...

  • Page 98: Server Configuration Utility Main Menu

    You can view or set information concerning ME (Management Engine). See Chapter 2 (2.8 ECO) for details. (c) Help You can open help screen of Server Configuration Utility. (e) Return to the previous menu You can exit Server Configuration Utility, and return to Off-line TOOL MENU. Express5800/E120f-M Maintenance Guide...

  • Page 99: Expressscope Engine 3

    See Chapter 2 (2.5 Clear BMC SEL) for details. (c) Reset You can reset BMC without changing configuration information. See Chapter 2 (2.6 Resetting BMC) for details. (d) Configuration Initialization You can initialize BMC configuration information. See Chapter 2 (2.7 Initializing BMC Configuration) for details. Express5800/E120f-M Maintenance Guide...

  • Page 100: Setting Bmc Configuration

    (e) System Operation You can set parameters for remote KVM console and remote media. See Chapter 2 (2.4.5 System Operation) for details. Miscellaneous You can set various features of BMC. See Chapter 2 (2.4.6 Miscellaneous) for details. Express5800/E120f-M Maintenance Guide...

  • Page 101: Network

    Dynamic DNS Determine whether to enable/disable of Dynamic DNS. Disable DNS Server Specify the DNS Server. 0.0.0.0 Host Name Specify the Host Name. Blank Domain Name Specify the Domain Name. Blank Express5800/E120f-M Maintenance Guide...
  • Page 102 *11: Port number can be specified only when the relevant port is set to "Enable". The port number must be unique. *12: Can be specified only when IPv6 is set to "Enable". *13: Displayed only when "Dynamic" is specified for Address Assignment Mode. Express5800/E120f-M Maintenance Guide...

  • Page 103: User Management

    Specify IP address of Domain Controller Server 3. *5 *10 Blank Active Directory (Group) Group Name Specify group name of Active Directory. Blank Group Domain Specify group domain of Active Directory. Blank Privilege Specify privilege of group of Active Directory. Administrator Administrator Operator User Express5800/E120f-M Maintenance Guide...
  • Page 104 *12: Characters in the range between 4 and 62 including alphanumeric, hyphen, underscore, period, comma, and equal sign can be used. *13: Alphanumeric characters in the range between 4 and 31 excluding ", #, and ¥ can be used. Express5800/E120f-M Maintenance Guide...

  • Page 105: Mail Alert

    Enable *6 *7 LOGIN Select Enable/Disable of LOGIN authentication. Enable *6 *7 PLAIN Select Enable/Disable of PLAIN authentication. Enable *6 *8 User Name Specify the SMTP User Name. Blank *6 *9 Password Specify the SMTP Password. Blank Express5800/E120f-M Maintenance Guide...
  • Page 106 Up to 19 alphanumeric characters can be used excluding " " blank, ",?, =, <, >, #, and ¥. *10: Be sure to perform Alert Test after all the parameters are configured appropriately. Alert feature may fail depending on configuration made for network or alert receiver. Express5800/E120f-M Maintenance Guide...

  • Page 107: Snmp Alert

    Can be specified only when each Alert Receiver is set to "Enable". Be sure to perform Alert Test after all the parameters are configured appropriately. Alert feature may fail depending on configuration made for network or alert receiver. Express5800/E120f-M Maintenance Guide...

  • Page 108: System Operation

    – Memory (Remote CD/DVD port number + 2) (Encryption) Remote FD Display the port number of remote FD when encryption is enabled. (Remote – CD/DVD port number + 3) (Encryption) Port numbers must be the unique one. Express5800/E120f-M Maintenance Guide...

  • Page 109: Miscellaneous

    When this item is changed to/from "Overwrite oldest SEL", all log records in the SEL Repository are cleared. Disabling Platform Event Filter also disables SNMP alert. When BMC can be managed directly from NEC ESMPRO Manager (Ver.5.4 or later), this item must be set to "Enable". If it is set to "Enable", Authentication Key is required.

  • Page 110: Clear Bmc Sel

    <ESC> key: Aborts processing and returns to BMC Configuration menu. <Enter> key: Resets BMC. It takes about several minute to restart BMC. Note Do not shutdown the system, reboot the system, or perform any switch operation while BMC is being reset (for approximately 3 minutes). Express5800/E120f-M Maintenance Guide...

  • Page 111: Initializing Bmc Configuration

    Initializes BMC configuration settings and restores the default value. After initialization, it takes several minutes to restart BMC. Note Do not shutdown the system, reboot the system, or perform any switch operation while BMC is being initialized (for approximately 3 minutes). Express5800/E120f-M Maintenance Guide...

  • Page 112: Eco

    (in seconds) depends on system. system value Shutdown System Enable or disable the feature to shutdown the system when power Disable consumption exceeds the time specified in Correction time limit. Non- Aggressive Enable or disable Non-Aggressive Mode. Disable Mode Express5800/E120f-M Maintenance Guide...
  • Page 113 CPU/memory reaches 100%, the power value cannot be reduced no longer. • If the value specified for Power Threshold (Pa) for Aggressive Mode is lower than the power required for system startup and the parameter "Shutdown System" is enabled, the server might not start normally. Express5800/E120f-M Maintenance Guide...

  • Page 114: Initializing Eco Setting

    If you select Configuration Initialization on ECO menu, the confirmation message as show below appears. Confirmation message (Initialization) <ESC> key: Aborts processing and returns to Main menu. <Enter> key: Initializes ECO settings and restores the default value. Express5800/E120f-M Maintenance Guide...

  • Page 115: Flash Fdd

    Be extremely careful not to lose Flash FDD or have it stolen. If Flash FDD is lost, stolen, misappropriated, or fraudulently obtained, there is a risk of leaking confidential information to a third party. NEC assumes no responsibility for damages caused by leaking confidential information in this way.

  • Page 116: Notes On Using Flash Fdd

    Flash FDD is only intended as a temporary means of recording a driver, so do not use it to back up data. 3.1.1 Compensation for recorded data NEC will not pay compensation for data recorded on Flash FDD if the data is lost. 3.1.2 Handling Flash FDD •...

  • Page 117: Power Control Feature

    Power consumption of the server can be controlled through the Web console of EXPRESSSCOPE Engine 3 (BMC) or by using NEC ESMPRO Manager. This feature curves the upper limit of the power consumption, which allows more servers to be installed in the environment where the power consumption is limited.

  • Page 118: Raid System Configuration

    Starts from 0 Starts from 1 Drive Group (Disk Array) Starts from 0 Starts from 1 To be assigned based on an enclosure that Drive (Physical Device) Starts from 0 contains the physical device and its slot number. Express5800/E120f-M Maintenance Guide...
  • Page 119 Consistency Check priority Middle Tips • Off-line Utility can specify the background initialization priority, but Universal RAID Utility cannot. • Although Universal RAID Utility can specify the priority of initialization (Slow Initialize), this server does not support this function. Express5800/E120f-M Maintenance Guide...

  • Page 120: Details Of Expressbuilder

    Windows Application: If EXPRESSBUILDER is installed to the server, you can run EXPRESSBUILDER as a Windows application. Choose "NEC" from Windows Start Menu and run "NEC EXPRESSBUILDER". See Chapter 2 (6.4 Installing EXPRESSBUILDER) for how to install EXPRESSBUILDER. When EXPRESSBUILDER is launched as Windows application, Autorun Menu shown in Chapter 2 (6.2 Menus of EXPRESSBUILDER) - (4) Autorun Menu appears.

  • Page 121: Menus Of Expressbuilder

    OS installation *** default *** Tool menu When OS installation is chosen or no key is pressed, Home Menu shown in (2) Home Menu appears. Tool Menu shown in (3) Tool Menu appears when you choose Tool menu. Express5800/E120f-M Maintenance Guide...
  • Page 122 Return to the previous menu The system diagnostics, which is used to analyze and diagnose the server and check the cable connection, can be started from Tool Menu. For details about system diagnostics, see Chapter 1 (8. System Diagnostics). Express5800/E120f-M Maintenance Guide...
  • Page 123 Applications Installs or executes applications individually. e) Files for Setup Creates the file for Windows installation. f) Maintenance Maintains Internal Flash Memory. g) Exit Closes the menu. Express5800/E120f-M Maintenance Guide...

  • Page 124: Utilities In Expressbuilder

    Saves or loads the configuration data on a RAID controller. File execution Directly runs an external utility on removable media. Use this feature only for utilities provided by NEC. Note Do not run the file provided by the third party.

  • Page 125: Expressscope Engine 3

    * In order to activate these features, the optional N8115-04 Remote KVM and Media License are required. To actualize these features, virtual USB mass storage (Remote FD, Remote CD/DVD, Remote USB Memory, or Virtual Flash) is always connected as USB mass storage. Express5800/E120f-M Maintenance Guide...

  • Page 126: Nec Esmpro

    Installation Guide (Windows)" in EXPRESSBUILDER. NEC ESMPRO Manager NEC ESMPRO Manager can remotely control and monitor the hardware and the RAID system of the server. To use these features, install the bundled software for the server such as NEC ESMPRO ServerAgentService.

  • Page 127: Nec Product Info Collection Utility

    9. NEC Product Info Collection Utility NEC Product Info Collection Utility NEC Product Info Collection Utility can collect various information related to the server all at once. You can collect the server information (Product Info) for maintenance by using this utility.

  • Page 128: Universal Raid Utility

    Creating Logical Drive of RAID 6 Four or more physical devices are needed to create a RAID 6 logical drive by using Universal RAID Utility. If you want to create a RAID 6 logical drive with three physical devices, use Off-line Utility. Express5800/E120f-M Maintenance Guide...

  • Page 129: Express Report Service / Express Report Service (Https)

    11. Express Report Service / Express Report Service (HTTPS) Express Report Service / Express Report Service (HTTPS) For details about Express Report Service / Express Report Service (HTTPS), see "Express Report Service / Express Report Service (HTTPS) Installation Guide" in EXPRESSBUILDER. Express5800/E120f-M Maintenance Guide...

  • Page 130: Express Report Service (Mg)

    Chapter 2 Useful Features 12. Express Report Service (MG) Express Report Service (MG) For details about Express Report Service (MG), see "Express Report Service (MG) Installation Guide" in EXPRESSBUILDER. Express5800/E120f-M Maintenance Guide...

  • Page 131: Chapter 3 Appendix

    2. List of Windows Event Logs Shows a list of Windows event logs Accessing Data for Electrical Power, Temperature, and Processor Utilization Describes how to check power consumption in watts, intake temperature, and logical processor utilizations. 4. Glossary Express5800/E120f-M Maintenance Guide...

  • Page 132: Post Error Message

    • Write down the displayed messages and beep code before contacting your sales representative. The messages are useful information for maintenance. • Error messages output from optional devices are not described here. For those messages, see the manual that comes with your optional devices. Express5800/E120f-M Maintenance Guide...
  • Page 133 Unsupported CPU detected on CPU #1 9002 Unsupported CPU detected on CPU #2 A CPU of which clock speed is 9021 Unsupported CPU Speed unsupported was detected. detected on CPU #1 9022 Unsupported CPU Speed detected on CPU #2 Express5800/E120f-M Maintenance Guide...
  • Page 134 AE01 CPU1_DIMM1 has been CPU1_DIMM1 has been disabled. disabled. A memory error was detected. AE02 CPU1_DIMM2 has been CPU1_DIMM2 has been disabled. disabled. A memory error was detected. AE03 CPU1_DIMM3 has been CPU1_DIMM3 has been disabled. disabled. Express5800/E120f-M Maintenance Guide...
  • Page 135 DIMM was forcibly enabled. An error in CPU2_DIMM1 occurred, AE8D CPU2_DIMM1 with error is but because all memory is currently enabled. disabled, this DIMM was forcibly enabled. Express5800/E120f-M Maintenance Guide...
  • Page 136 LAN1. Width Error Link Width error was detected on B222 Onboard LAN 2 - PCIe Link onboard LAN2. Width Error Link Width error was detected on B223 Onboard LAN 3 - PCIe Link onboard LAN3. Width Error Express5800/E120f-M Maintenance Guide...
  • Page 137 BMC IBF or OBF check failed. An error was detected while C104 accessing BMC. There is not enough space to store Run Offline Tools (Chapter 1, 9. Offline C105 BMC SEL area full. the system event log. Tools) and delete the event logs. Express5800/E120f-M Maintenance Guide...
  • Page 138 Server menu of the setup, this message appears if the configuration was changed since the previous startup. If this message appears even when no configuration change has been made, contact your service representative. Express5800/E120f-M Maintenance Guide...
  • Page 139 Unplug the power cord, wait for at least 30 C501 Intel(R) Node Manager is in Mode. seconds, then restart the server. At that Recovery Mode. time, check the jumper switch setting on motherboard. If the same error is detected repeatedly, contact your sales representative. Express5800/E120f-M Maintenance Guide...
  • Page 140 Failed to reset the system. An error was detected during allocating PCI Remove all the installed PCI boards from PCI resources. slots, and then restart the server. If the same error is detected repeatedly, contact your sales representative. Express5800/E120f-M Maintenance Guide...
  • Page 141 Uncorrectable memory error was DIMM #x Uncorrectable Error (x: detected. DIMM number) A frequent occurrence of DIMM #x Correctable Error (x: DIMM correctable memory error was number) detected. Uncorrectable error was detected Contact your sales representative. PCIx Slot Uncorrectable Error Express5800/E120f-M Maintenance Guide...
  • Page 142 Ambient Temperature Upper Non-Critical Ambient Temperature Lower Critical Ambient Temperature Upper Critical CPU1-DIMM Area Temperature Lower Non-Critical CPU1-DIMM Area Temperature Upper Non-Critical CPU1-DIMM Area Temperature Lower Critical CPU1-DIMM Area Temperature Upper Critical CPU2-DIMM Area Temperature Lower Non-Critical Express5800/E120f-M Maintenance Guide...
  • Page 143 CPU1-DIMM1. CPU1-DIMM2 Uncorrectable Error An unrecoverable error occurred for CPU1-DIMM2. CPU1-DIMM3 Uncorrectable Error An unrecoverable error occurred for CPU1-DIMM3. CPU1-DIMM4 Uncorrectable Error An uncorrectable error occurred for CPU1-DIMM4. CPU1-DIMM5 Uncorrectable Error An unrecoverable error occurred for CPU1-DIMM5. Express5800/E120f-M Maintenance Guide...
  • Page 144 Node Manager Firmware Flash Erase your sales representative. Error Node Manager Firmware Flash Corrupted Node Manager Internal Error Node Manager can't communicate Node Manager Manufacturing Error Node Manager Persistent Storage Integrity Error Express5800/E120f-M Maintenance Guide...
  • Page 145 Contact your sales representative. System Rear FAN2 Lower Non-Critical System Rear FAN3 Lower Non-Critical System Rear FAN4 Lower Non-Critical System Front FAN1 Lower Non-Critical System Front FAN2 Lower Non-Critical System Front FAN3 Lower Non-Critical System Front FAN4 Lower Non-Critical Express5800/E120f-M Maintenance Guide...

  • Page 146: List Of Windows Event Logs

    This event does not affect system operation. or applying Starter Pack Megasas Error The driver detected a controller error on \Device\RaidPort(x). This event does not affect system operation if it is logged when applying When applying Starter Pack Starter Pack. Express5800/E120f-M Maintenance Guide...
  • Page 147 1500 If this event is logged only when SNMP is enabled and does not occur repeatedly, there is no problem with system operation. When installing an OS Go to the following Microsoft website for details. http://support.microsoft.com/kb/2002303/ Express5800/E120f-M Maintenance Guide...
  • Page 148 Microsoft-Windows- License Activation (slui.exe) failed with the following error code: Error Security-SPP Error code: hr=0xC004F063 8198 Unless this event is not logged after license authentication, there is no When installing an OS problem in system operation. Express5800/E120f-M Maintenance Guide...
  • Page 149 Error AppReadiness Error: 'Class not registered' (0.0469065 sec.) If this event is logged only at the first sign-in after OS installation and When installing an OS does not occur repeatedly, there is no problem in system operation. Express5800/E120f-M Maintenance Guide...
  • Page 150 The Network List Service terminated with the following error: Error Manager The device is not ready. 7023 If this event is logged only when installing an OS and does not occur When installing an OS repeatedly, there is no problem in system operation. Express5800/E120f-M Maintenance Guide...
  • Page 151 A connection to the Windows Metadata and Internet Services (WMIS) Warning DeviceSetupManager could not be established. If it is not registered after the Internet connection is established, there is When running the system no problem with system operation. Express5800/E120f-M Maintenance Guide...
  • Page 152 This event does not affect system operation. Starter Pack Broadcom BCM57810 #xx: The network link is down. Check to make l2nd Warning sure the network cable is properly connected. When starting system, or applying This event does not affect system operation. Starter Pack Express5800/E120f-M Maintenance Guide...
  • Page 153 Primary Adapter does not sense the following Probes: iANSMiniport Warning Intel(R) ~ Possible reason: partitioned Team. This event is logged at system startup if a team is configured with When starting system Intel(R) PROSet, however, there is no problem in system operation. Express5800/E120f-M Maintenance Guide...
  • Page 154 Unless the application event is registered after license authentication, When installing an OS this event does not affect system operation. Microsoft-Windows-User Profile notification of event Create for component Warning Profiles Service {56EA1054-1959-467f-BE3B-A2A787C4B6EA} failed. 1534 When installing an OS This event does not affect system operation. Express5800/E120f-M Maintenance Guide...
  • Page 155 12289 hr = 0x80070001, function is incorrect. When you import a transportable shadow-copy to another server that has a Go to the following Microsoft website for details: floppy disk drive while operating http://support.microsoft.com/kb/2003968/en-us Windows Server 2008 R2: Express5800/E120f-M Maintenance Guide...
  • Page 156 If this event is logged when installing an OS, running an OS for the When installing an OS, running an OS for first time, or while applying Starter Pack, it does not affect system the first time, or applying Starter Pack operation. Express5800/E120f-M Maintenance Guide...

  • Page 157: Accessing Data For Electric Power, Temperature, And Processor Utilization

    'WScript.Echo " Data LS Byte = 0x" & hex(outparams.ResponseData(2)) 'WScript.Echo " Data MS Byte = 0x" & hex(outparams.ResponseData(3)) WScript.Echo " Power Consumption = " & outparams.ResponseData(3)*256 + _ outparams.ResponseData(2) & " watts" End If ' End Script Express5800/E120f-M Maintenance Guide...

  • Page 158: Intake Air Temperature

    ' (Get SDR) for each record Dim Record_LS,Record_MS, Offset, Length Dim cnt, sensorNum, sensorType ' First Record Record_LS = 0 Record_MS = 0 For cnt = 0 to RecordCount-1 Offset = 0 Length = 9 oinparams.networkfunction = &ha oinparams.lun = 0 Express5800/E120f-M Maintenance Guide...
  • Page 159 'WScript.Echo " Event Status: ok" Dim M,B,k1,k2 Dim ret M = (outtmp.ResponseData(8) And &hc0) * 4 + outtmp.ResponseData(7) B = (outtmp.ResponseData(10) And &hc0) * 4 + outtmp.ResponseData(9) call get2complement(M, M, 10) call get2complement(B, B, 10) call get2complement(outtmp.ResponseData(12) And &h0f, k1, 4) Express5800/E120f-M Maintenance Guide...
  • Page 160 ID String = CPU1_DIMM2 Temp Sensor Type = Temperature Event Status: Unavailable =========================================== Intake air temperature data can read from the sensor with an ID string that contains any of the following: Amb, Ambient, or Front Panel. Express5800/E120f-M Maintenance Guide...

  • Page 161: Processor Utilization

    Proc3 : PercentProcessorTime=0 Proc4 : PercentProcessorTime=76 Proc5 : PercentProcessorTime=0 Proc6 : PercentProcessorTime=0 Proc7 : PercentProcessorTime=0 Proc_Total : PercentProcessorTime=9 Proc 0 to Proc 7 show the utilization rate of each processor while Proc_Total shows the total processor utilization rate. Express5800/E120f-M Maintenance Guide...

  • Page 162: Linux

    In such cases, either of the following messages is displayed. Unable to send RAW command (channel=0x0 netfn=0x2c lun=0x0 cmd=0x2 rsp=0xc1): Invalid Command Unable to send RAW command (channel=0x0 netfn=0x2c lun=0x0 cmd=0x2 rsp=0xcb): Requested sensor, data, or record not found Express5800/E120f-M Maintenance Guide...

  • Page 163: Intake Air Temperature

    0.08 0.00 0.00 95.83 6.63 17:59:30 0.30 0.01 0.17 1.39 0.00 0.00 0.00 98.13 0.02 17:59:30 1.36 0.20 0.74 5.72 0.12 0.20 0.00 91.66 33.54 You can know the processor utilization rate by subtracting %idle from 100%. Express5800/E120f-M Maintenance Guide...

  • Page 164: Glossary

    Software for managing plural servers on network. NEC ESMPRO ServerAgentService Software for monitoring the server. This works with NEC ESMPRO Manager. You can choose Service Mode or Non-Service Mode when installing this software. Service Mode resides as the OS service and Non-Service Mode does not use the OS service to reduce the OS resources such as memory or CPU.
