READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and
follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has
not read these instructions to assemble, light, adjust or operate the heater.
UNVENTED LP-GAS FIRED ROOM HEATER
HSSVFRD20LPBT
HSSVFRD30LPBT
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for
Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is
not convertible for use with any other gas.
Enerco Technical Products, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 866-447-2194
Unvented Liquid Propane Fired Room Heater
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
Plaque Heaters
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Blue Flame Heaters
1
Installation Instructions and Owner's Manual
Model #
HSSVFRD20LPBT
HSSVFRD30LPBT
HSSVFBF20LPBT
HSSVFBF30LPBT
HSSVFBF20LPBT
HSSVFBF30LPBT
Advertisement
Table of Contents
Related Manuals for HeatStar HSSVFRD20LPBT
Summary of Contents for HeatStar HSSVFRD20LPBT
- Page 1 OPERATING INSTRUCTIONS Model # HSSVFRD20LPBT HSSVFRD30LPBT AND OWNER’S MANUAL HSSVFBF20LPBT HSSVFBF30LPBT READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the heater.
- Page 2 Install external regulator with the vent pointing down. Pointing the vent down protects it from freezing rain or sleet. SOCIAL MEDIA In order to provide the best service possible HEATSTAR is now giving you more ways to get in touch with us: WEBSITE: Heatstar Products’s full line of product are now at: WWW.HEATSTARBYENERCO.COM YouTube: youtube.com/heatstarTV Unvented Liquid Propane Fired Room Heater Installation Instructions and Owner’s Manual...
-
Page 3: Table Of Contents
10,000 BTU (2931 W) (i.e. the signs, the heater may not be working properly. Get fresh HSSVFRD20LPBT, HSSVFRD30LPBT, HSSVFBF20LPBT, and air at once! Have heater serviced. Some people are more HSSVFBF30LPBT) shall not be installed in a bedroom or affected by carbon monoxide than others. -
Page 4: Ignition System Battery Installation
PRODUCT FEATURES FRESH AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall not be installed in a confined Ignitor Button Fan Blower space or unusually tight construction unless provisions are Switch* provided for adequate combustion and ventilation air. Read Control Knob (located on back of heater) the following instructions to insure proper fresh air for this... -
Page 5: Determining The Type Of Heater Location Space
DETERMINING THE TYPE OF HEATER LOCATION C. Install a lower Btu/hr heater if lower Btu/hr size makes room unconfined. SPACE: If actual Btu/hr used is less than the maximum Btu/ Use this method to determine if you have a confined or hr the space can support, the space is an unconfined unconfined space. -
Page 6: Installation
WARNING: Never install the heater: This will help circulate the heat throughout the house. In • In a bedroom (HSSVFRD20LPBT, HSSVFRD30LPBT, the event of a power outage, you can use this heater as HSSVFBF20LPBT, HSSVFBF30LPBT) your primary heat source for the duration of the outage. -
Page 7: Fastening Heater To Wall
Attaching to Wall Stud: This way is the best providing the strongest mounting in wood frame houses. Attaching to Wall Anchor: 10”(25.4cm) 36”(91.4cm) from sides This way allows you to attach mounting bracket to hollow min from ceiling walls (wall areas between studs) or to solid walls (concrete or masonry). -
Page 8: Floor Mounting Away From Wall
2. Mark screws locations on wall. 3. Remove heater from mounting bracket. 4. If installing bottom mounting screw into hollow or solid wall, install wall anchors. Follow steps 1 Figure 8. through 4 under Attaching to Wall using Anchor. If installing bottom mounting screw into wall stud, 3. -
Page 9: Connecting To Gas Supply
CONNECTING TO GAS SUPPLY WARNING: A qualified service person must connect HEATER CABINET heater to gas supply. Follow all local codes. 3/8” NPT Pipe Nipple Pressure WARNING: This appliance requires a 3/8” NPT Regulator (National Pipe Thread) inlet connection to the pressure Ground Joint Union regulator. -
Page 10: Operating Your Heater
Low Pressure ELECTRICAL WIRING DIAGRAM: Test Pressure Equal To or Less Than ½ psig (3.5 kPa) MOTOR 1. The appliance must be isolated from the gas supply SWITCH, TEMP piping system by closing its equipment shutoff valve OPERATION during any pressure testing of the gas supply piping system at test pressures equal to or less than ½... - Page 11 LIGHTING INSTRUCTIONS THERMOSTAT CONTROL OPERATION 1. STOP! Read the all safety information included with and FOR HSSVFRD20LPBT / HSSVFRD30LPBT: on the side of heater. The thermostatic control used simply turns on and off the 2. Check that gas supply to heater is on.
-
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE Pilot Air Inlet Hole WARNING: Turn off heater and let cool before servicing. For maintenance of the inside cabinet or to access the burner Pilot Assembly and pilot assembly for cleaning or service. Remove the four screws(two located on each side) that secure the front shell Figure 18 to the unit (Figure 6). - Page 13 PAGE LEFT INTENTIONALLY BLANK Unvented Liquid Propane Fired Room Heater Installation Instructions and Owner’s Manual...
-
Page 14: Troubleshooting
TROUBLESHOOTING NOTE: All troubleshooting items are listed in order of operation and likely occurrence. WARNING: Only a qualified service person should service and repair heater. CAUTION: Never use a wire needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Make sure grille guard is in place before running heater. - Page 15 OBSERVED SYMPTOM POSSIBLE CAUSE REMEDY Burner orifice is clogged Clean burner orifice (see Cleaning and Maintenance on page 1 1), or replace burner orifice Burner does not light after Burner orifice diameter to small Replace burner orifice ODS/pilot is lit Inlet gas pressure is too low Contact local gas company Manifold pressure is too low...
-
Page 16: Parts List And Diagram
PARTS LIST AND DIAGRAM MODEL: HSSVFRD20LPBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80094 Wire Guard 70640 Thermostat Valve Thermostat Valve Mounting 80096 Front Panel 80010 Bracket 80086 Reflector 80011 Igniter Module Mounting Bracket ODS Assembly w/ Thermocouple 80056 80058 Floor Mounting Feet... - Page 17 PARTS LIST AND DIAGRAM MODEL: HSSVFRD30LPBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80041 Wire Guard 70640 Thermostat Valve Thermostat Valve Mounting 80065 Front Panel 80010 Bracket 80023 Reflector 80011 Igniter Module Mounting Bracket ODS Assembly w/ Thermocouple 80056 80058 Floor Mounting Feet (LP) 80109 Burner Assembly...
- Page 18 PARTS LIST AND DIAGRAM MODEL: HSSVFBF20LPBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80122 Wire Guard 70640 Thermostat Valve 80096 Front Panel 80014 Igniter Wire 80086 Reflector 80019 Igniter Module 80088 Front Heat Shield 80011 Igniter Module Mounting Bracket Thermostat Valve Mounting 80093 Glass 80010...
- Page 19 PARTS LIST AND DIAGRAM MODEL: HSSVFBF30LPBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80123 Wire Guard 70640 Thermostat Valve 80065 Front Panel 80014 Igniter Wire 80025 Reflector 80019 Igniter Module 80029 Front Heat Shield 80011 Igniter Module Mounting Bracket Thermostat Valve Mounting 80039 Glass 80010...
-
Page 20: Warranty
LIMITED WARRANTY Enerco Group, Inc. (EGI) warrants Heatstar Vent free heaters to be free from defects in material and workmanship for a period of five years from the date of manufacture. • During the first two years, EGI will repair or replace this product if it is proven to be defective within the first two years and it is returned at customer expense with proof of purchase to the location of EGI’s choice.
